- Page 1 0154567en 0306 Vibroplate VP 1135R VP 1135RW OPERATOR’S MANUAL...
-
Page 3: Table Of Contents
VP 1135R/RW Table of Contents Foreword Safety Information Laws Pertaining to Spark Arresters ............5 Operating Safety .................. 6 Operator Safety while using Internal Combustion Engines ....7 Service Safety ..................8 Label Locations ..................9 Warning and Informational Labels ............10 Technical Data Engine Data .................. - Page 4 Table of Contents VP 1135R/RW Maintenance Periodic Maintenance Schedule ............18 Cleaning Plate ..................18 Drive Belt .....................19 Exciter Lubrication ................20 Spark Plug ...................21 Engine Oil ....................22 Air Cleaner ..................23 Cleaning Fuel Strainer .................24 Adjusting the Idle Speed ..............24 5.10 Adjusting the Engine Speed ..............25 5.11...
-
Page 5: Foreword
CALIFORNIA Proposition 65 Warning: Engine exhaust, some of its constituents, and certain vehicle components, contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive WARNING harm. Foreword This manual provides information and procedures to safely operate and maintain this Wacker model. -
Page 6: Safety Information
Safety Information VP 1135R/RW Safety Information This manual contains DANGER, WARNING, CAUTION, NOTICE and NOTE callouts which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. This is the safety alert symbol. It is used to alert you to potential personal injury hazards. -
Page 7: Laws Pertaining To Spark Arresters
VP 1135R/RW Safety Information Laws Pertaining to Spark Arresters Notice: State Health Safety Codes and Public Resources Codes specify that in certain locations spark arresters be used on internal combustion engines that use hydrocarbon fuels. A spark arrester is a device designed to prevent accidental discharge of sparks or flames from the engine exhaust. -
Page 8: Operating Safety
Safety Information VP 1135R/RW Operating Safety Familiarity and proper training are required for the safe operation of the machine. Machines operated improperly or by untrained personnel can be dangerous. Read the operating instructions contained in both WARNING this manual and the Engine Manual and familiarize yourself with the location and proper use of all controls. -
Page 9: Operator Safety While Using Internal Combustion Engines
VP 1135R/RW Safety Information Operator Safety while using Internal Combustion Engines Internal combustion engines present special hazards during operation and fueling. Read and follow the warning instructions in the engine Owner’s Manual and the safety guidelines below. Failure to follow the DANGER warnings and safety standards could result in severe injury or death. -
Page 10: Service Safety
Safety Information VP 1135R/RW Service Safety A poorly maintained machine can become a safety hazard! In order for the machine to operate safely and properly over a long period of time, periodic maintenance and occasional repairs are necessary. WARNING 2.4.1 DO NOT attempt to clean or service the machine while it is running. -
Page 11: Label Locations
VP 1135R/RW Safety Information Label Locations VP 1135 wpm_gr002141 wc_si000018gb.fm... -
Page 12: Warning And Informational Labels
Safety Information VP 1135R/RW Warning and Informational Labels Wacker machines use international pictorial labels where needed. These labels are described below: Label Meaning WARNING! Always wear hearing and eye protection when operating this machine. WARNING! Hot surface! Guaranteed sound power level in dB(A). - Page 13 VP 1135R/RW Safety Information Label Meaning DANGER! Engines emit carbon monoxide; operate only in well-ventilated area. Read the operator's manual for machine infor- mation. DANGER! Before fueling, stop the engine. No sparks, flames, or burning objects near the machine. Use only fresh, clean fuel.
-
Page 14: Technical Data
Technical Data VP 1135R/RW Technical Data Engine Data Item Number: VP 1135R VP 1135RW VP 1135R VP 1135RW 0009071 0009251 0009071 0009251 Rev. 102 Rev. 101 Rev. 103 Rev. 102 and lower and lower and higher and higher Engine Engine Make... -
Page 15: Machine Data
VP 1135R/RW Technical Data Machine Data Item Number: VP 1135R VP 1135RW 0009071 0009251 Plate Weight 60 (132) kg (lbs.) Water Tank Capacity 3.8 (4) l (qts.) Exciter Speed 5800 ± 100 Exciter Lubrication 207 (7) ml (oz.) Automatic transmission fluid... -
Page 16: Dimensions
Technical Data VP 1135R/RW Dimensions mm (in.) 905 (36) 521 (21) 350 (14) wpm_gr002142 wc_td000013gb.fm... -
Page 17: Operation
VP 1135R/RW Operation Operation Recommended Fuel The engine requires regular grade unleaded gasoline. Use only fresh, clean gasoline. Gasoline containing water or dirt will damage fuel system. Consult engine Owner’s Manual for complete fuel specifications. Application This plate is designed for compacting loose, granular soils, gravel, and paving stones. -
Page 18: To Start
Operation VP 1135R/RW To Start See Graphic: wc_gr000086 4.4.1 Open fuel valve by moving lever down (a1). 4.4.2 If engine is cold, move choke lever to closed position (b1). If engine is hot, set choke to open position (b2). 4.4.3 Open throttle by moving it to the right (c2). -
Page 19: Operation
VP 1135R/RW Operation Operation Run the engine at full throttle and allow the plate to pull itself along at its normal speed. When operating on an incline it may be necessary to assist the plate by pushing it forward slightly. When operating downhill hold the plate back slightly, if it begins to pick up speed. -
Page 20: Maintenance
Maintenance VP 1135R/RW Maintenance Periodic Maintenance Schedule The chart below lists basic engine maintenance. Refer to the engine manufacturer’s Operation Manual for additional information on engine maintenance. Daily After Every Every Every before first 2 weeks month year starting 20 hrs. -
Page 21: Drive Belt
VP 1135R/RW Maintenance Drive Belt See Graphic: wpm_gr002143 On new machines or after installing a new belt, check the belt tension after first 20 hours of operation. Check and adjust the belt every 50 hours thereafter. To adjust the belt: 5.3.1... -
Page 22: Exciter Lubrication
Maintenance VP 1135R/RW Exciter Lubrication See Graphic: wc_gr000133 The bearings in the exciter assembly are splash lubricated and rotate at very high speed. It is important to maintain the exciter oil at the correct level and change it regularly. Check oil level in exciter every 50 hours of operation. -
Page 23: Spark Plug
VP 1135R/RW Maintenance Spark Plug See Graphic: wc_gr000028 Clean or replace the spark plug as needed to ensure proper operation. Refer to your engine operator’s manual. The muffler becomes very hot during operation and remains hot for a while after stopping the engine. Do not touch the muffler while it is hot. -
Page 24: Engine Oil
Maintenance VP 1135R/RW Engine Oil See Graphic: wc_gr000087 5.6.1 Drain oil while engine is still warm. Note: In the interests of environmental protection, place a plastic sheet and a container under the machine to collect any liquid which drains off. Dispose of this liquid in accordance with environmental protection legislation. -
Page 25: Air Cleaner
VP 1135R/RW Maintenance Air Cleaner See Graphic: wc_gr000161 The engine is equipped with a dual element air cleaner. Service the air cleaner frequently to prevent a carburetor malfunction. NOTICE: NEVER run the engine without the air cleaner. Severe engine damage will occur. -
Page 26: Cleaning Fuel Strainer
Maintenance VP 1135R/RW Cleaning Fuel Strainer See Graphic: wc_gr000131 5.8.1 To remove water and dirt, close the fuel lever and remove the fuel strainer. 5.8.2 Inspect the fuel strainer (a) for water and dirt. 5.8.3 After removing any dirt and water, wash the fuel cup with a nonflammable solvent. -
Page 27: Adjusting The Engine Speed
VP 1135R/RW Maintenance 5.10 Adjusting the Engine Speed See Graphic: wc_gr000130 Adjust the engine to a full load speed. See Technical Data. To adjust the engine speed: 5.10.1 Set the coarse adjustment by attaching the governor spring (a) to the center hole of the throttle arm. -
Page 28: Troubleshooting
Maintenance VP 1135R/RW 5.11 Troubleshooting Problem / Symptom Reason / Remedy Plate does not develop full • Engine throttle control not completely open. speed. Poor compaction. • Throttle control not adjusted correctly. • Ground too wet, plate sticking. Allow soil to dry before compacting. -
Page 29: Lifting Machine
VP 1135R/RW Maintenance 5.13 Lifting Machine See Graphic: wpm_gr002144 See Technical Data for weight of machine. To lift machine manually: 5.13.1 Stop the engine. 5.13.2 Obtain help from a partner and plan the lift. To avoid burns or fire hazards, let the engine cool before transporting the machine or storing it indoors. -
Page 30: Transporting Machine
Maintenance VP 1135R/RW 5.14 Transporting Machine See Graphic: wpm_gr002145 To avoid burns or fire hazards, let engine cool before transporting machine or storing indoors. WARNING 5.14.1 Turn fuel valve to the off position and keep the engine level to prevent fuel from spilling. - Page 31 Vibratory Plates / Rüttelplatten Planchas Vibratorias / Plaques Vibrantes Type - Typ - Tipo - Type VP 1135R, VP 1135RW Item number of equipment / Artikelnummer / Número de referencia de la máquina / Numéro de référence du matériel : 0009071, 0009251 Net installed power / absolute installierte Leistung / Potencia instalada neta / Puissance installée nette :...
- Page 32 Wacker Construction Equipment AG · Preußenstraße 41 · D-80809 München · Tel.: +49-(0)89-354 02 - 0 · Fax: +49 - (0)89-354 02-390 Wacker Corporation · P.O. Box 9007 · Menomonee Falls, WI 53052-9007 · Tel. : +1-(1)(262) 255-0500 · Fax: +1-(1)(262) 255-0550 · Tel. : (800) 770-0957 Wacker Asia Pacific Operations ·...
