Operator's Manual
Vibroplate
VP 1135 (RAW)
0130347en
004
0110
0
1
3
0
3
4
7
E
N

Advertisement

loading
Need help?

Need help?

Do you have a question about the VP 1135 and is the answer not in the manual?

Questions and answers

Related Manuals for Wacker Neuson VP 1135

Summary of Contents for Wacker Neuson VP 1135

  • Page 1 Operator’s Manual Vibroplate VP 1135 (RAW) 0130347en 0110...
  • Page 2 This publication may be photocopied by the original purchaser of the machine. Any other type of reproduction is prohibited without express written permission from Wacker Neuson Corporation. Any type of reproduction or distribution not authorized by Wacker Neuson Corporation represents an infringement of valid copyrights. Violators will be prosecuted. Trademarks All trademarks referenced in this manual are the property of their respective owners.
  • Page 3 VP 1135(RAW) Table of Contents Foreword Safety Information Laws Pertaining to Spark Arresters ............5 Operating Safety .................. 6 Operator Safety while using Internal Combustion Engines ....7 Service Safety ..................8 Label Locations ..................9 Warning and Informational Labels ............10 Technical Data Engine Data ..................
  • Page 4 Table of Contents VP 1135(RAW) Maintenance Periodic Maintenance Schedule ............15 Cleaning Plate ..................17 Drive Belt .....................17 Exciter Lubrication ................18 Lifting Machine ..................19 Transporting Machine ................20 Troubleshooting ...................21 Storage ....................21 wpm_bo0130347004enTOC.fm...
  • Page 5 Foreword This manual provides information and procedures to safely operate and maintain this Wacker Neuson model. For your own safety and protection from injury, carefully read, understand and observe the safety instructions described in this manual. Keep this manual or a copy of it with the machine. If you lose this manual or need an additional copy, please contact Wacker Neuson Corporation.
  • Page 6 Safety Information VP 1135 (RAW) Safety Information This manual contains DANGER, WARNING, CAUTION, NOTICE and NOTE callouts which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
  • Page 7 VP 1135 (RAW) Safety Information Laws Pertaining to Spark Arresters Notice: State Health Safety Codes and Public Resources Codes specify that in certain locations spark arresters be used on internal combustion engines that use hydrocarbon fuels. A spark arrester is a device designed to prevent accidental discharge of sparks or flames from the engine exhaust.
  • Page 8 These areas get hot and may cause burns. 1.2.3 Do not use accessories or attachments that are not recommended by Wacker Neuson. Damage to equipment and injury to the user may result. 1.2.4 NEVER operate the machine with the beltguard missing. Exposed drive belt and pulleys create potentially dangerous hazards that can cause serious injuries.
  • Page 9 VP 1135 (RAW) Safety Information Operator Safety while using Internal Combustion Engines Internal combustion engines present special hazards during operation and fueling. Read and follow the warning instructions in the engine owner’s manual and the safety guidelines below. Failure to follow the WARNING warnings and safety standards could result in severe injury or death.
  • Page 10 A hot muffler could ignite the debris and start a fire. 1.4.6 Replace worn or damaged components with spare parts designed and recommended by Wacker Neuson Corporation. 1.4.7 Disconnect the spark plug on machines equipped with gasoline engines, before servicing, to avoid accidental start-up.
  • Page 11 VP 1135 (RAW) Safety Information Label Locations wpmgr005951 wpm_si000318gb.fm...
  • Page 12 Safety Information VP 1135 (RAW) Warning and Informational Labels Wacker Neuson machines use international pictorial labels where needed. These labels are described below: Label Meaning WARNING! Always wear hearing and eye protection when operating this machine. WARNING! Hot surface! WARNING! Hand injury if caught in moving belt.
  • Page 13 VP 1135 (RAW) Safety Information Label Meaning DANGER! Before fueling, stop the engine. No sparks, flames, or burning objects near the machine. Use only fresh, clean fuel. Label-machine model A nameplate listing the model number, item number, revision number, and serial number is attached to each unit.
  • Page 14 Technical Data VP 1135 (RAW) Technical Data Engine Data Refer to engine owner’s / operator’s manual. Plate Data VP 1135 (RAW) 0008710 Plate Exciter Speed 5800 ± 100 Exciter Lubrication ml (oz.) 207 (7) Automatic transmission fluid Dextron III/Mercon or equivalent Dimensions mm (in.)
  • Page 15 VP 1135 (RAW) Operation Operation Recommended Fuel The engine requires regular grade unleaded gasoline. Use only fresh, clean gasoline. Gasoline containing water or dirt will damage fuel system. Consult engine owner’s manual for complete fuel specifications. Application This plate is designed for compacting loose, granular soils, gravel, and paving stones.
  • Page 16 Operation VP 1135 (RAW) Starting / Stopping Refer to engine owner’s / operator’s manual for starting and stopping instructions. Operation Run the engine at full throttle and allow the plate to pull itself along at its normal speed. When operating on an incline it may be necessary to assist the plate by pushing it forward slightly.
  • Page 17 VP 1135 (RAW) Maintenance Maintenance Periodic Maintenance Schedule 4.1.1 Engine Maintenance The chart below lists basic engine maintenance. Refer to the engine manufacturer’s Operation Manual for additional information on engine maintenance. Daily After Every Every Every before first 2 weeks...
  • Page 18 Maintenance VP 1135 (RAW) 4.1.2 Machine Maintenance The chart below lists basic machine maintenance. Daily After Every Every Every before first 2 weeks month year starting 20 hrs. 50 hrs. 100 hrs. 300 hrs. Check external hardware. Check and adjust drive belt.
  • Page 19 VP 1135 (RAW) Maintenance Cleaning Plate Clean plate after use to remove dirt, stones, and mud caught under the engine console. If plate is being used in a dusty area, check engine cylinder cooling fins for heavy dirt accumulation. Keep engine cylinder fins clean to prevent engine from overheating.
  • Page 20 Maintenance VP 1135 (RAW) Exciter Lubrication See Graphic: wpmgr006018 The bearings in the exciter assembly are splash lubricated and rotate at very high speed. It is important to maintain the exciter oil at the correct level and change it regularly.
  • Page 21 VP 1135 (RAW) Maintenance Lifting Machine See Graphic: wpmgr006025 See Technical Data for weight of machine. To lift machine manually: 4.5.1 Stop the engine. 4.5.2 Obtain help from a partner and plan the lift. To avoid burns or fire hazards, let the engine cool before transporting the machine or storing it indoors.
  • Page 22 Maintenance VP 1135 (RAW) Transporting Machine See Graphic: wpmgr006045 To avoid burns or fire hazards, let engine cool before transporting machine or storing indoors. WARNING 4.6.1 Turn fuel valve to the off position and keep the engine level to prevent fuel from spilling.
  • Page 23 VP 1135 (RAW) Maintenance Troubleshooting Problem / Symptom Reason / Remedy Plate does not develop full • Engine throttle control not completely open. speed. Poor compaction. • Throttle control not adjusted correctly. • Ground too wet, plate sticking. Allow soil to dry before compacting.
  • Page 24 Fax: +49 - (0)89-3 54 02-3 90 Wacker Neuson Corporation · P.O. Box 9007 · Menomonee Falls, WI 53052-9007 · Tel. : (262) 255-0500 · Fax: (262) 255-0550 · Tel. : (800) 770-0957 Wacker Asia Pacific Operations · Skyline Tower, Suite 2303, 23/F · 39 Wang Kwong Road, Kowloon Bay, Hong Kong · Tel. +852 2406 60 32 · Fax: +852 2406 60 21...
