Related Manuals for Wacker Neuson VP 2050
Summary of Contents for Wacker Neuson VP 2050
- Page 1 Operator’s Manual Vibroplate VP 2050 VP 2050W 500191658 0110...
- Page 2 This publication may be photocopied by the original purchaser of the machine. Any other type of reproduction is prohibited without express written permission from Wacker Neuson Corporation. Any type of reproduction or distribution not authorized by Wacker Neuson Corporation represents an infringement of valid copyrights. Violators will be prosecuted. Trademarks All trademarks referenced in this manual are the property of their respective owners.
-
Page 3: Table Of Contents
VP 2050/W Table of Contents Foreword Safety Information Laws Pertaining to Spark Arresters ............4 Operating Safety .................. 5 Operator Safety while using Internal Combustion Engines ....6 Service Safety ..................7 Label Locations ..................8 Warning and Informational Labels ............9 Technical Data Engine Data .................. - Page 4 Table of Contents VP 2050/W Maintenance Periodic Maintenance Schedule ............18 Spark Plug ...................20 Air Cleaner ..................21 Engine Oil ....................22 Adjusting the Engine Speed ..............22 Cleaning Fuel Strainer .................23 Drive Belt .....................24 Exciter Lubrication ................25 Cleaning the Plate ................25 4.10 Lifting Machine ..................26 4.11...
-
Page 5: Foreword
Foreword This manual provides information and procedures to safely operate and maintain this Wacker Neuson model. For your own safety and protection from injury, carefully read, understand and observe the safety instructions described in this manual. Keep this manual or a copy of it with the machine. If you lose this manual or need an additional copy, please contact Wacker Neuson Corporation. -
Page 6: Safety Information
Safety Information VP 2050/W Safety Information This manual contains DANGER, WARNING, CAUTION, NOTICE, and NOTE signal words which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. This is the safety alert symbol. It is used to alert you to potential personal injury hazards. -
Page 7: Operating Safety
These areas get hot and may cause burns. 1.2.3 Do not use accessories or attachments that are not recommended by Wacker Neuson. Damage to equipment and injury to the user may result. 1.2.4 NEVER operate the machine with the beltguard missing. Exposed drive belt and pulleys create potentially dangerous hazards that can cause serious injuries. -
Page 8: Operator Safety While Using Internal Combustion Engines
Safety Information VP 2050/W Operator Safety while using Internal Combustion Engines Internal combustion engines present special hazards during operation and fueling. Read and follow the warning instructions in the engine owner’s manual and the safety guidelines below. Failure to follow the WARNING warnings and safety standards could result in severe injury or death. -
Page 9: Service Safety
A hot muffler could ignite the debris and start a fire. 1.4.6 Replace worn or damaged components with spare parts designed and recommended by Wacker Neuson Corporation. 1.4.7 Disconnect the spark plug on machines equipped with gasoline engines, before servicing, to avoid accidental start-up. -
Page 10: Label Locations
Safety Information VP 2050/W Label Locations wpmgr005945 wpm_si000312gb.fm... -
Page 11: Warning And Informational Labels
VP 2050/W Safety Information Warning and Informational Labels Wacker Neuson machines use international pictorial labels where needed. These labels are described below: Label Meaning WARNING! Hot surface! Guaranteed sound power level in dB(A). WARNING! Hand injury if caught in moving belt. - Page 12 Safety Information VP 2050/W Label Meaning Throttle control lever: Rabbit = Full or Fast Turtle = Idle or Slow DANGER! Engines emit carbon monoxide; operate only in well-ventilated area. Read the Operator’s Manual for machine infor- mation. DANGER! Before fueling, stop the engine. No sparks, flames, or burning objects near the machine.
- Page 13 VP 2050/W Safety Information Label Meaning A nameplate listing the model number, item number, revision number, and serial number is attached to each unit. Please record the infor- mation found on this plate so it will be avail- able should the nameplate become lost or damaged.
-
Page 14: Technical Data
Technical Data VP 2050/W Technical Data Engine Data Engine Power Rating Net power rating per SAE J1349. Actual power output may vary due to conditions of specific use. VP 2050 VP 2050W 0009530 0009537 Engine Engine Make Wacker Engine Model... -
Page 15: Machine Data
VP 2050 = 91 dB(A). These sound values were determined according to ISO 3744 for the sound power level (L ) and ISO 6081 for the sound pressure level ) at the operator’s location. The weighted effective acceleration value, determined according to EN ISO 5349, is approximately = 4.5 m/s... -
Page 16: Dimensions
Technical Data VP 2050/W Dimensions mm (in.) 919 (36) 500 (20) 588 (23) wpmgr005973 wpm_td000321gb.fm... -
Page 17: Operation
VP 2050/W Operation Operation Recommended Fuel The engine requires regular grade unleaded gasoline. Use only fresh, clean gasoline. Gasoline containing water or dirt will damage fuel system. Consult engine owner’s manual for complete fuel specifications. Application This plate is designed for compacting loose, granular soils, gravel, and paving stones. -
Page 18: To Start
Operation VP 2050/W To Start See Graphic: wc_gr000655 3.4.1 Open fuel valve by moving lever down (a1). Note: If engine is cold, move choke lever to close position (d2). If engine is hot, set choke to open position (d1). 3.4.2 Turn engine switch to “ON”... -
Page 19: Operation
VP 2050/W Operation Operation Run the engine at full throttle and allow the plate to pull itself along at its normal speed. When operating on an incline it may be necessary to assist the plate by pushing it forward slightly. When operating downhill hold the plate back slightly, if it begins to pick up speed. -
Page 20: Maintenance
Maintenance VP 2050/W Maintenance Periodic Maintenance Schedule 4.1.1 Engine Maintenance The chart below lists basic engine maintenance. Refer to the engine manufacturer’s Operation Manual for additional information. Daily After Every Every Every before first 2 weeks month year starting 20 hrs. - Page 21 VP 2050/W Maintenance 4.1.2 Machine Maintenance The chart below lists basic machine maintenance. Daily After Every Every Every before first 2 weeks month year starting 20 hrs. 50 hrs. 100 hrs. 300 hrs. Check external hardware. Check and adjust drive belt.
-
Page 22: Spark Plug
Maintenance VP 2050/W Spark Plug See Graphic: wc_gr000028 Clean or replace the spark plug as needed to ensure proper operation. Refer to your engine operator’s manual. The muffler becomes very hot during operation and remains hot for a while after stopping the engine. Do not touch the muffler while it is hot. -
Page 23: Air Cleaner
VP 2050/W Maintenance Air Cleaner See Graphic: wc_gr000656 NEVER use gasoline or other types of low-flash point solvents for cleaning the air cleaner. A fire or explosion could result. WARNING NOTICE: NEVER run the engine without the air cleaner. Severe engine damage will occur. -
Page 24: Engine Oil
Maintenance VP 2050/W Engine Oil See Graphic: wc_gr000087 4.4.1 Drain oil while engine is still warm. Note: In the interests of environmental protection, place a plastic sheet and a container under the machine to collect any liquid which drains off. Dispose of this liquid in accordance with environmental protection legislation. -
Page 25: Cleaning Fuel Strainer
VP 2050/W Maintenance Cleaning Fuel Strainer See Graphic: wc_gr001093 4.6.1 To remove water and dirt, close the fuel lever and remove the fuel strainer. 4.6.2 Inspect the fuel strainer (a) for water and dirt. 4.6.3 After removing any dirt and water, wash the fuel cup with a nonflammable solvent. -
Page 26: Drive Belt
Maintenance VP 2050/W Drive Belt See Graphic: wpmgr005997 On new machines or after installing a new belt, check the belt tension after first 20 hours of operation. Check and adjust the belt every 50 hours thereafter. To adjust the belt: 4.7.1... -
Page 27: Exciter Lubrication
VP 2050/W Maintenance Exciter Lubrication See Graphic: wpmgr006020 The bearings in the exciter assembly are splash lubricated and rotate at very high speed. It is important to maintain the exciter oil at the correct level and change it regularly. Check oil level in exciter every 50 hours of operation. -
Page 28: Lifting Machine
Maintenance VP 2050/W 4.10 Lifting Machine See Graphic: wpmgr006169 See Technical Data for weight of machine. To lift machine manually: 4.10.1 Stop the engine. 4.10.2 Obtain help from a partner and plan the lift. To avoid burns or fire hazards, let the engine cool before transporting the machine or storing it indoors. -
Page 29: Transporting Machine
VP 2050/W Maintenance 4.11 Transporting Machine See Graphic: wpmgr006043 To avoid burns or fire hazards, let engine cool before transporting machine or storing indoors. WARNING 4.11.1 Turn fuel valve to the off position and keep the engine level to prevent fuel from spilling. -
Page 30: Troubleshooting
Maintenance VP 2050/W 4.13 Troubleshooting Problem / Symptom Reason / Remedy Plate does not develop full • Engine throttle control not completely open. speed. Poor compaction. • Throttle control not adjusted correctly. • Ground too wet, plate sticking. Allow soil to dry before compacting. - Page 31 EC DECLARATION OF CONFORMITY WACKER NEUSON MANILA, INC., DASMARIÑAS, CAVITE, PHILIPPINES AUTHORIZED REPRESENTATIVE IN THE EUROPEAN UNION Axel Häret WACKER NEUSON SE Preußenstraße 41 80809 München hereby certifies that the construction equipment specified hereunder: Category Vibratory Plates Machine function: This plate is designed for compacting loose, granular soils, gravel, and paving stones. It is intended to be used in confined areas and areas next to structures such as walls, curbs, and foundations.
- Page 33 CE-KONFORMITÄTSERKLÄRUNG WACKER NEUSON MANILA, INC., DASMARIÑAS, CAVITE, PHILIPPINES BEVOLLMÄCHTIGTER VERTRETER FÜR DIE EUROPÄISCHE Axel Häret GEMEINSCHAFT WACKER NEUSON SE Preußenstraße 41 80809 München bescheinigt, daß das Baugerät: Art: Rüttelplatten Maschinenfunktion: Diese Platte eignet sich zum Verdichten von losen und körnigen Böden, Kies und Verbundsteinen, ebenso in engen Bereichen an Gebäuden, Randsteinen und Fundamenten.
- Page 35 DECLARACIÓN DE CONFORMIDAD DE LA CE WACKER NEUSON MANILA, INC., DASMARIÑAS, CAVITE, PHILIPPINES REPRESENTANTE AUTORIZADO EN LA UNIÓN EUROPEA Axel Häret WACKER NEUSON SE Preußenstraße 41 80809 München certifica que la máquina de construcción: Categoría: Planchas Vibratorias Función de la máquina: Esta placa está...
- Page 37 DÉCLARATION DE CONFORMITÉ C.E. WACKER NEUSON MANILA, INC., DASMARIÑAS, CAVITE, PHILIPPINES REPRÉSENTANT AGRÉÉ AUPRÈS DE L’UNION Axel Häret EUROPÉENNE WACKER NEUSON SE Preußenstraße 41 80809 München atteste que le matériel: Catégorie: Plaques Vibrantes Fonction de la machine : Cette plaque est conçue pour le compactage de la terre lâche et granuleuse, du gravier et des pavés. Elle est destinée à...
- Page 38 Wacker Neuson Production Americas LLC, N92W15000 Anthony Ave., Menomonee Falls, WI. 53051 Tel.: (262) 255-0500 Fax: (262) 255-0550 Tel.: (800) 770-0957 Wacker Neuson Limited - Room 1701–03 & 1717–20, 17/F. Tower 1, Grand Century Place, 193 Prince Edward Road West, Mongkok, Kowloon, Hongkong. Tel: (852) 3605 5360, Fax: (852) 2758 0032...
