JTS IN264 User Manual

Uhf pll dual channel diversity wireless system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Music
Life
F
F
UHF PLL Dual Channel Diversity Wireless System
* The system is of the innovative design to allow changing the
transmitter's frequency by long-distance .
* IN264R with band width of 36 MHz.
* Preset 6 groups, maximum 23 channels in one group.
* Operation distance from 200~480 meters.
INFINITY
SET
▲
REMOSET
6
2 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IN264 and is the answer not in the manual?

Questions and answers

Related Manuals for JTS IN264

Summary of Contents for JTS IN264

  • Page 1 Music INFINITY Life REMOSET ▲ UHF PLL Dual Channel Diversity Wireless System * The system is of the innovative design to allow changing the transmitter’s frequency by long-distance . * IN264R with band width of 36 MHz. * Preset 6 groups, maximum 23 channels in one group. * Operation distance from 200~480 meters.
  • Page 2 Thank you for choosing the JTS wireless system. In order to obtain the best efficiency from the system, you are recommended to take a few minutes to read this instruction manual carefully.

  • Page 3: Table Of Contents

    INDEX 1. Important Caution 2. Features 3. Specification 3-1 UHF PLL Dual Channel Diversity Receiver // IN264R 3-2 UHF PLL Handheld Transmitter // IN264TH 3-3 UHF PLL Body-Pack Transmitter // IN264TB 3-4 Optional Condenser Microphone 4. Part Identification & Accessories 4-1 UHF PLL Dual Channel Diversity Receiver // IN264R 4-2 UHF PLL Handheld Transmitter // IN264TH 4-3 UHF PLL Body-Pack Transmitter // IN264TB...
  • Page 4 Pair the ID codes of the transmitter and the receiver to have proper function. 2. Features JTS IN264 wireless microphone system is designed with the world first RF remote setting func- tion (REMOSET). A user can set the receiver with desired frequency and press the “REMOSET”...

  • Page 5: Uhf Pll Dual Channel Diversity Receiver // In264R

    3. Specification 3-1 UHF PLL Dual Channel Diversity Receiver // IN264R Frequency Preparation..PLL Synthesized Control Remoset........Radio Frequency : 2.4GHz Effective distance: 10m Carrier Frequency Range 502~960 MHz S/N Ratio........>105dB T.H.D..........<0.6%@1KHz Display........... Display Contents....Channel, Antenna A/B, Mute Display, RF/AF Level Meter, Low battery, ID Number Controls........

  • Page 6: Uhf Pll Body-Pack Transmitter // In264Tb

    Music INFINITY Life 3-3 UHF PLL Body-Pack Transmitter // IN264TB Frequency Preparation.... PLL Synthesized Control Carrier Frequency Range..502~960 MHz RF Outputs........10mW / 50mW (Depend on Local Regulation) Stability..........±10KHz Frequency Deviation....±48KHz LCD Display........Channel, Battery Fuel Gauge, ID Number Controls..........
  • Page 7 Headset Microphone Model No....... CM-204 CM-204U CM-204UL Connector......4P Mini XLR 4P Mini XLR 801C3 (3 pin mini XLR) 801C4 (4 pin mini XLR) 801CS (3.5 stereo plug) Frequency Response..60~15,000 Hz 30~18,000 Hz 100 ~ 18,000Hz Polar Pattern......Omni-directional Cardioid Cardioid Sensitivity (at 1000Hz)
  • Page 8 Music INFINITY Life Ear-hook Microphone Model No....... CM-801/CM-804i CM-8015/CM-825i Connector......801C4 (4 pin mini XLR) 801C4 (4 pin mini XLR) Option Connector... 801C3 (3 pin mini XLR) 801C3 (3 pin mini XLR) 801CS (3.5 stereo plug) 801CS (3.5 stereo plug) Frequency Response..

  • Page 9: Uhf Pll Dual Channel Diversity Receiver // In264R

    4. Parts Identification & Accessories 4-1 UHF PLL Dual Channel Diversity Receiver // IN264R Front panel Power Switch Channel Select: Up button Channel Select: Down button Channel Select: Set button LCD Panel REMOSET Key: press it to send a desired channel data to a transmitter REMOSET REMOSET ▲...

  • Page 10: Uhf Pll Handheld Transmitter // In264Th

    Music INFINITY Life LCD Panel of the Receiver AF Level: display the strength of audio signal RF Level: display the strength of radio signal Antenna Status: the receiver will automatically select an antenna with stronger signal level Low battery indicator: display the low battery status of its transmitter Group &...

  • Page 11: Uhf Pll Body-Pack Transmitter // In264Tb

    4-3 UHF PLL Body-Pack Transmitter // IN264TB LCD Display Battery Tray Set button: set the configuration of bodypack transmitter Up button: select the settings of transmitter Down button: select the settings of transmitter 4 Pin mini XLR mic. input Power Switch Pad: -20dB, -6dB, 0dB LCD Panel of the Body-Pack Transmitter Battery status: display battery status...

  • Page 12: Optional Condenser Microphone

    Music INFINITY Life 4-4 Optional Condenser Microphone Lavaliere Microphone // CM-501 / CM-201 / CM-125 Clip 4 Pin Mini XLR Windscreen CM-501 CM-201 CM-125...
  • Page 13 Headset Microphone // CM-204 / CM-204U / CM-204UL / CM-225 / CX-504 Gooseneck Headband 4 Pin Mini XLR Windscreen CM-204 CM-204U CM-204UL Standard : 4 Pin Mini XLR 3 Pin Mini XLR 3.5 Stereo Plug CM-225 CX-504...
  • Page 14 Music INFINITY Life Ear-hook Microphone // CM-801 / CM-804i / CM-8015 / CM-825i Boom Adjustable Headband Adjustable ear hook Detchable Cable Cable Clip CM-801 Windscreen 4 Pin Mini XLR Option 3 Pin Mini XLR 3.5 Stereo Plug Option CM-804i CM-8015 CM-825i...
  • Page 15 Compatible Instrument Microphone // CX-500 / CX-500F / CX-520 / CX-508W / CX-516W Gooseneck Clip Bracket Volume Control Windscreen 4 Pin Mini XLR CX-500 CX-500F CX-520 CX-508W CX-516W...

  • Page 16: Accessories

    Music INFINITY Life 4-5 Accessories AC/DC adaptor Switching Power Supply(100V~240V , 50~60Hz) Linear Power Supply (220V , 50Hz) Option Linear Power Supply (220V , 60Hz) Option Screwdriver RM-12 Rack mount kit Option AF output cable (with Ø6.3 plug at both ends) GC-80/GC-100 Guitar Cable Option GC-80L/GC-100L Guitar Cable...

  • Page 17: 5. Connection

    5. Connection 5-1 Receiver // IN264R (1) Connect to the subsequent unit (e.g. mixer, or amplifier) Connect one end of a proper AF cable to the AF Output or Balanced XLR Output socket , then plug another end to the “MIC IN” input socket of a mixer or a amplifier (Step 1 for Figure 1) (2) Connect the power supply unit Plug in one end of AC/DC adaptor cable...

  • Page 18: 6. Operation

    (4) Install the antennas in a vertical position 6-2 Set up ID code In order to match one receiver to only one transmitter, IN264 is designed with“ ID code”. If and only if both ID codes of a receiver and a transmitter match each other, the “REMOSET”...
  • Page 19 Handheld and BodyPack transmitter ID code ON/OFF setting (1) Press “Set” button for 3 seconds, LCD Panel will start flashing. (2) Press “Set” a couple of times until “ID Code ON/OFF” setting window shows. (3) Press“ Up ” or “ Down ”button to select between “...
  • Page 20 Music INFINITY Life 6-3 Synchronize the channel (1) Press “Set” button fon the receiver for 3 Seconds, the group (G) in the “Group & Channel” area will flash. (Figure 4) (2) Press “ Up ” or “ Down ” button to select a desired group (3) Press “Set”...
  • Page 21 6-5 Manual select channel Receiver (1) Press“Set” button for 3 seconds, the group (G) in the “Group & Channel” area will flash. (Figure 8) (2) Press “ Up ” or “ Down ” button to select a desired group. (3) Press “Set” again and the Channel(CH) in the “Group & Channel” area will flash. (4) Press “...
  • Page 22 Music INFINITY Life 6-6 Lock ON Function Receiver (1) Press “Set” button for 3 seconds to enter setting window (2) Press “Set” again until the Lock setting window shows. (Figure 10) Notice: Original setting is lock off (Lo OF). (3) Press “ Up ” or “ Down ” button to select the mode between “Lock On” and “Lock off ”.

  • Page 23: Handheld Transmitter

    6-7 Adjust the sensitivity of the microphone Handheld transmitter (1) Press “Set” button for 3 seconds to enter setting window. (Figure 12) 20 28 (2) Short press “Set” until the sensitivity setting window shows. (3) Press “ Up ” or “ Down ”button to select the sensitivity among 0db, -3db, -6db, -9db, -12db, -15db, -18db and -21db.
  • Page 24 Music INFINITY Life Handheld and Body Pack Setting List Sensitivity 0 dB is the highest sensitivity Settings Synchronization ON/OFF When ID code is OFF (id OFF), the transmitter will ID code ON/OFF accept any synchronization from any IN264R. There are 100 ID codes. ID code select button unlock Lock ON...

  • Page 25: Installation Of Condenser Microphones

    Plug the connector into input socket on the body-pack transmitter. MIC IN (3) Instrument Microphones The system is compatible with JTS various instrument microphones. For detail please refer to user’ s manuals of these microphones.
  • Page 26 Music INFINITY Life (4) Ear-hook Microphone 1. Lightweight Dual Ear Hook Microphone Try on whether the headset is fit. Adjust the headband to a suitable width. Tighten or loosen the curve of the ear-hook by twisting the loop or expanding it. Curve and bend the boom to fit your face.

  • Page 27: Important Notice

    8. Important Notice (1) JTS offers wireless systems in a selection of bands that conform to the different government regulations of specific nations or geographic regions. These regulations help limit radio frequency (RF) interference among different wireless devices and prevent interference with local public communications channels, such as television and emergency broadcasts.
  • Page 28 REMOSET ▲ 1856 59508-021-03...
