High Wall Split Air Conditioners
53KHFT 12-18-24 Cool Only
53QHFT 12-18-24 Heat Pump
Carrier is committed to continuously improving its products according to national and international standards
to ensure the highest quality and reliability standards, and to meet market regulations and requirements.
All specifications subject to change without prior notice according to Carrier policy of continuous development.
03504165
220-240V ~ 50Hz 1Ph
OWNER'S M A N UA L
Quality
Enviromental
Management System
Management System
ISO 9001 : 2008
ISO 14001 : 2004
Certificate No.: QS-5519HH
Certificate No : 12 104 30334 TMS
Miraco
Miraco
MISR REFRIGERATION & AIR CONDITIONING MFG. CO.
PLUS
Safety
Management System
BS OHSAS 18001 : 2007
Certificate No : 12 116 30334 TMS
Rev. (0) - 2015
Advertisement
Table of Contents
Related Manuals for Carrier Crystal Plus 53KHFT 12
Summary of Contents for Carrier Crystal Plus 53KHFT 12
- Page 1 Carrier is committed to continuously improving its products according to national and international standards to ensure the highest quality and reliability standards, and to meet market regulations and requirements. All specifications subject to change without prior notice according to Carrier policy of continuous development. Quality...
- Page 2 Miraco Miraco MISR REFRIGERATION & AIR CONDITIONING MFG. CO. 220V ~ 50Hz 1Ph COOL EER HEAT COP PLUS High Wall Split Systems 12K - 18K - 24K Formaldehyde Tropical Super Auto Timer Easy Flexible Auto Filter Compressor Quiet Fan Speed Functions Installation Efficient...
- Page 3 PLUS High Wall Split Systems Wireless Remote Control Control Buttons DISPLAY OF SELECTED FUNCTIONS MODE selection button AUTO - COOL - DRY - HEAT - FAN Decrease temperature button Each time you press the button, the temperature decreased by 1°C Increase temperature button Each time you press the button, the temperature increased by 1°C...
-
Page 4: Wireless Remote Control
PLUS High Wall Split Systems Wireless Remote Control Display Of Remote Control Signal transmission indicator Operation MODE indicator AUTO SET TEMP. AUTO Automatic COOL HIGH COOL Cooling and dehumidification Dehumidification only HEAT TIMER ON OFF HEAT Heating Ventilation (fan only) ON / OFF indicator SET TEMP. -
Page 5: Table Of Contents
Thank you for selecting Carrier Air Conditioner Carrier Split is the optimum air conditioning solution for places which require high wall installation, elegant appearance and ultimate comfort combined with efficient, quiet operation, optimum air distribution, and efficient Indoor Air Quality (IAQ). -
Page 6: General Information
1. GENERAL INFORMATION PRECAUTIONS Installing and servicing of air conditioning equipment can be hazardous due to system pressure and electrical components. Only trained and qualified service personnel should install or service this equipment. Untrained personnel can perform basic maintenance function such as cleaning coil and filters. -
Page 7: System Safety Protections
2. SYSTEM SAFETY PROTECTIONS The air conditioner is equipped with complete safety protections to ensure safe operation of air conditioner at different operating conditions : 2.1 Safety protections for Cool Only System Auto Restart Feature with backup memory. When the power failure is happened during the air conditioner operation, the microprocessor of printed circuit board will memorize the operation setting. -
Page 8: Tips Of Energy Saving And Optimum Comfort
3. TIPS OF ENERGY SAVING AND OPTIMUM COMFORT In Summer • Keep room temperature to comfort levels. • Don’t remain in direct contact with cold air for a long period. This is harmful to health. • Don’t wait until it is too hot. Turn the air conditioner for cooling before that. - Page 9 Air Filters circulation and maximum cooling and heating efficiency. Periodic service and maintenance of the air conditioner or upon customer request through Carrier or Carrier authorized dealer to assure maximum cooling and heating efficiency.
-
Page 10: Split System Description
4. SPLIT SYSTEM DESCRIPTION High Wall Split Systems 12K – 18K – 24K Return Air Indoor Unit Outdoor Unit Supply Air 1: Panel frame & Front panel 2: Chassis 3: Horizontal supply air louver 4: Vertical supply air louvers 5: Air filters 6: Manual control button 7: Power cord 8: Inter-connecting refrigerant piping and electrical cables between... -
Page 11: Considerations For Remote Control
5. CONSIDERATIONS FOR REMOTE CONTROL 5-1 HOW TO INSERT BATTERIES : (a) Remove the cover of battery compartment at the back of the remote control by pressing the tab toward outside, in the direction of the arrow. (b) Mount two batteries size AAA 1.5 Volt supplied with the remote control. - Page 12 CONSIDERATIONS FOR REMOTE CONTROL (Cont.) 5-3 Instruction for Remote Control 5-3-1 Cool Only or Heat Pump When you press Mode button and Fan button as the same time more than 2 seconds, then the remote covert to operate without Heat model to work with indoor unit cool only.
- Page 13 CONSIDERATIONS FOR REMOTE CONTROL (Cont.) 5-4 MOUNTING PLASTIC HOLDER OF REMOTE CONTROL • Fix the plastic holder of the remote control on the wall by using screws. Screw Plastic holder...
- Page 14 6. EMERGENCY FUNCTION EMERGENCY FUNCTION Emergency function can be used temporarily in case you cannot find the remote control or its batteries are exhausted. To perform Emergency function, follow below steps : 1. Open and lift the front panel up to an angle until it remains fixed with a clicking sound.
-
Page 15: Use Of Remote Control
7. USE OF REMOTE CONTROL COOL MODE START Press " Mode " button to select COOL mode on the remote control display. Press " TEMP " buttons to select the desired set temperature on the remote control display. For Egyptian Market : Set desired temp. -
Page 16: Heat Mode
USE OF REMOTE CONTROL (Cont.) HEAT MODE START 1. Press " Mode " button to select HEAT mode on the remote control display. 2. Press " TEMP " buttons to select the desired set temperature on the remote control display. For Egyptian Market : Set desired temp. -
Page 17: Auto Mode
USE OF REMOTE CONTROL (Cont.) AUTO MODE START 1. Press " Mode " button to select AUTO mode on the remote control display. 2. Press " TEMP " buttons to select desired the set temperature on the remote control display. For Egyptian Market : Set desired temp. -
Page 18: Dry Mode
USE OF REMOTE CONTROL (Cont.) DRY MODE START 1. Press " Mode " button to select DRY mode on the remote control display. 2. Press " TEMP " buttons to select desired the set temperature on the remote control display. For Egyptian Market : Set desired temp. -
Page 19: Fan Only Mode
USE OF REMOTE CONTROL (Cont.) FAN ONLY MODE START 1. Press " Mode " button to select FAN mode on the remote control display. 2. Press " Fan " button to select the desired fan speed on the remote control display. 3. -
Page 20: Air Flow Direction Control
USE OF REMOTE CONTROL (Cont.) AIR FLOW DIRECTION CONTROL Air is supplied into the room through the supply air louvers located on the bottom of the indoor unit. Air from the room is drawn into the indoor unit through the front panel and filters which are located behind the front panel. - Page 21 USE OF REMOTE CONTROL (Cont.) ↕ Swing Up and Down Function To automatically Swing the horizontal louvers for the vertical supply ↕ air direction ( Up- Down ) Perform this function while the air conditioner is in operation. • Press Swing button on the remote control more than 2 seconds, ↕...
- Page 22 USE OF REMOTE CONTROL (Cont.) ECO Function ECO function is useful when you go to sleep. Carrier air conditioner automatically controls the selected temperature and consequently controls the room temperature to avoid overcooling or overheating and to have comfortable and healthy sleep.
- Page 23 USE OF REMOTE CONTROL (Cont.) TIMER ON Function If you want to start automatically the air conditioner at the desired time ( between 0 ~ 24 hrs ), use TIMER ON function TIMER ON function is useful when you wake up in the morning or when you return home.
- Page 24 USE OF REMOTE CONTROL (Cont.) TIMER OFF Function If you want to stop automatically the air conditioner at the desired time ( between 0 ~ 24 hrs ), use TIMER OFF function TIMER OFF function is useful when you go to sleep. TO SET TIMER OFF TIME 1.
- Page 25 USE OF REMOTE CONTROL (Cont.) COMBINATION OF ON TIMER AND OFF TIMER FUNCTIONS SIMULTANEOUSLY ON TIMER → OFF TIMER ( Stop → Operation → Stop ) You can use this setting to automatically start the air conditioner when you wake up and automatically stop it when you leave the house.
- Page 26 USE OF REMOTE CONTROL (Cont.) SELF CLEAN FUNCTION / FRESH FUNCTION Self Clean function Press this button less than 2 seconds will initiate Self Clean function Then the symbol " SC " will appear on the front panel on the indoor unit The air conditioner will automatically clean and dry the Evaporator and keep it as fresh for the next operation.
-
Page 27: Follow Me Function
USE OF REMOTE CONTROL (Cont.) FOLLOW ME FUNCTION Follow Me function Press this button less than 2 seconds will initiate Follow Me function In Follow Me function, the remote control serves as a remote thermostat allowing for the precise and comfortable temperature control when you stay close to the remote control. With this technology, an efficient temperature sensor is built in the remote control. - Page 28 USE OF REMOTE CONTROL (Cont.) LED FUNCTION LED function Press this button less than 2 seconds will initiate LED function Press this button to clear or light the display on the indoor unit and display of wireless remote control.
- Page 29 USE OF REMOTE CONTROL (Cont.) TURBO FUNCTION Turbo function with COOL mode : If you want faster cooling at super high airflow, super high fan speed to reach the set temperature in the shortest time, Press TURBO button. • Turbo function will give faster cooling as super high fan speed for about 20 minutes.
-
Page 30: Air Filters Cleaning
8. AIR FILTERS CLEANING The air filters behind the front panel of the indoor unit should be checked and cleaned every month. Clogged air filters will reduce cooling and heating efficiency. WARNING: It is necessary to stop the air conditioner and disconnect the power supply before cleaning air filters. -
Page 31: Indoor Unit Cleaning
9. INDOOR UNIT CLEANING Warning! The indoor unit must be disconnected from the main supply before indoor unit cleaning. Cleaning the indoor unit and remote controller CAUTIONS • Use a dry cloth to wipe the indoor unit and remote control. •... -
Page 32: Periodical Checks
For a good operation of the air conditioner it is recommended to carry out periodic service and maintenance of the air conditioner or upon customer request through Carrier or Carrier authorized dealer. Recommended service and maintenance works and intervals may vary depending on the installation environment, e.g. -
Page 33: Considerations Before A Long Shutdown Period Of Air Conditioner
11. CONSIDERATIONS BEFORE A LONG SHUTDOWN PERIOD OF AIR CONDITIONER Keep the indoor unit in operation for half a day in the ventilation (fan only) mode in order to dry all internal parts. Switch electric mains supply off. Take batteries out of the remote control. Clean indoor and outdoor units. -
Page 34: Operation Tips
12. OPERATION TIPS The following events may occur during normal operation of the air conditioner : 1. A slight white mist (water vapor)coming out from the indoor unit during COOL mode A white mist may generate due to a large temperature difference between air inlet and air outlet on COOL mode in an indoor environment that has a high relative humidity. -
Page 35: Trouble Shooting
Carrier or Carrier certified dealer. If the abnormality persists and cannot be solved with the given instructions, turn off the air conditioner and does not try to turn it on again, call Carrier or Carrier certified dealer. TROUBLE POSSIBLE CAUSES... - Page 36 Before contacting service center of If checks are OK, call service center on the display panel & Carrier or one of Carrier authorized of Carrier or one of Carrier authorized Error Code on indoor dealers, make the following checks: dealers.
