8. HOW TO DISASSEMBLE

Please refer to the chapter 11 (Exploded diagram and parts list).
1 Before service of
any part.
2 Ass'y Fan Motor
- Fan Motor
- Propeller Fan
- Blower Fan
3 Ass'y Control Box
- Rotary Switch (selector)
- Thermostat
- Capacitor
- Power Cord
4 O.L.P
1. Stop the unit, remove the power cord from the receptacles.
2. Move the unit to the safe location for the suitable work.
• Only DW*-124C/CS, DWA-152C/CS
1. Remove Front Grille
- Open the grille upward by pulling out the bottom of the grille, lift it.
- Remove screw which fasten Frame Grille with driver.
- Pull knobs out of the control.
(when the knobs are too tight to release, leave them.)
- Disassemble Frame Grille from chassis.
• All models except DW*-124C/CS, DWA-152C/CS
1. Remove Front Grille.
- Remove Filter Pre.
- Remove screw(2 point) in Front Grille with driver.
- Disassemble Front Grille from chassis.
2. Remove the unit from Cabinet.
- Remove screws (2 point) from the unit's sides.
- Pull the unit from cabinet.
3. Remove Holder Scroll.
4. Remove Scroll upper
5. Remove Ass'y Control Box
- Remove screws (4 point).
- Remove wires in the each components.
6. Remove wires in the Panel Housing.
7. Remove screws (4 point) from Ass'y Fan Motor's sides.
- Ass'y Fan Motor is assembly of Fan Motor, Propeller and Blower Fan,
Orifice and Panel Housing.
8. Lift the Ass'y Fan Motor from the unit.
9. Remove Clip Fan (2 point) from the shaft of Fan Motor.
10. Remove Propeller Fan from the shaft of Fan Motor.
11. Remove Blower Fan from the shaft of Fan Motor.
12. Remove Fan Motor from Panel Housing.
- Remove screws (4 point).
1. Same as the procedure 1 to 5 in the Item 2.
1. Same as the procedure 1 to 2 in the Item 2.
2. Remove Terminal Cover from Compressor.
- Remove hex-nut (1 point).
11
(NOTE: A or B or C)
