Daewoo DWA-122C Use & Care Manual

Daewoo DWA-122C Use & Care Manual

Window type room air conditioner
Hide thumbs Also See for DWA-122C:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
PRECAUTIONS FOR PROPER USE OF AIR CONDITIONER
Please observe the following instructions.
1. Operate the Selector Switch to run or stop the unit.
- Do not use Main Power Switch or Auxiliary Power Switch to operate unit.
2. Do not stick anything into the air outlet or inlet.
- It is dangerous and it can cause injury or damage.
3. Avoid exposing your body directly to a continuous cool air - flow for long periods.
- It is not good for your health.
4. Do not pour water on the unit to clean it.
- It is dangerous and it can cause injury or damage.
Never use solvents or harsh chemicals when cleaning the unit.
When the air inlet grill and cabinet are dirty, wipe with luke - warm water (below 104°F or 40°C)
5. Avoid placing any obstacles near the inlet or outlet.
- If the inlet or outlet is blocked with any obstacle, it may cause damage to the unit.
6. Do not run or stop the unit frequently.
- If you run or stop the unit more then 4-5 times an hour, it can cause damage to the unit.
7. Wait at least 3 minutes before restarting the unit or in the case of power failure.
- If you turn on the unit within 3 minutes after power off, this can cause damage to the unit.
8. If the air conditioner is operated without an air filter, dust is not removed from the air, and resultant
accumulation in the unit may lead to a failure.
- Do not forget to install the air filter.
9. The air filter should be cleaned at least once every two weeks.
10. When the unit is cleaned, set the Selector Switch at off position.
- And then unplug the power plug.
11. Never store gasoline or other flammable liquid near the air conditioner.
- It is very dangerous.
12. Do not force the controls on the front panel too much.
- It can cause damage the controls and the unit.
13. Set a comfortable temperature.
- Very low temperature setting considerably increase power consumption.
14. Be careful to keep room temperature comfortable.
- Avoid continuous direct air flow on you or a sick person while sleeping.
15. Do not remove the plug by pulling the power cord.
- Damage to the cord and may cause shock hazard.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWA-122C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daewoo DWA-122C

Summary of Contents for Daewoo DWA-122C

  • Page 1 - If you turn on the unit within 3 minutes after power off, this can cause damage to the unit. 8. If the air conditioner is operated without an air filter, dust is not removed from the air, and resultant accumulation in the unit may lead to a failure.

  • Page 2: Table Of Contents

    • CLEANING THE AIR CONDITIONER 7. ELECTRICAL REQUIREMENTS ...13 • ELECTRICAL GROUNDING INSTRUCTIONS. • USE OF EXTENSION CORDS 8. BEFORE CALLING FOR SERVICE...14 ITEM DWC-100C/DWC-100CS DWC-121C/DWC-121CS DWA-122C/DWA-122CS DWA-150C/DWA-150CS DWA-151C/DWA-151CS POWER SOURCE AC 115V, 60Hz, SINGLE PHASE DIMENSIONS WEIGHT (NET) 85.6 Ibs (38.8 Kg)-Approx.

  • Page 3: Installation Instructions

    1. Install an exclusive main power switch (main circuit breaker) or GFI (Ground Fault Interrupted) switch. 2. Be sure to use grounded power source. 3. Power source for DWC-100C, DWC-100CS, DWC-121C, DWC-121CS is 115V and DWA-122C, DWA-122CS, DWA-150C, DWA-150CS, DWA-151C, DWA-151CS is 208~230V. 4. Consumer must pay charges for wiring and installation.

  • Page 4: Before Installation

    • SAFETY INSTRUCTIONS (CONTINUED) The receptacle should be an individual branch circuit used only for this air conditioner. Be sure the electrical service is adequate for the model air conditioner you have chosen. The complete electrical rating of your air conditioner is stated on the name plate located at the unit’s side.

  • Page 5: Step1-Prepare Components For Installation

    • Step 2 - Prepare Window For Installation 1. Inspect window track, sash and sill to be sure they are strong enough to hold an air conditioner. 2. Measure width between window frame to be sure instant mount will fit in the window. Instant mount models are designed for Windows 27.5 inch (699mm) to 36 inch (914mm) wide.
  • Page 6 4. Disassemble Front Grille from Chassis. – Front Grille and chassis are fixed with snap-fit. 1) Release right-lower snap-fit. – Push the right lower side of chassis to the left, with pushing left side of Front Grille to the right until the snap-fit is released. 2) Release left-lower snap-fit.

  • Page 7: Step4-Placing Chassis

    • Step 4 - Placing Chassis 1. Insert narrow side of ‘Frame Guide Lower’ to rectangle holes located in bottom of chassis, and fasten it with Screw (Type E). 2. Insert Window Kit Frames to Top Guide and Lower Guide. 3.

  • Page 8: Step6-Recheck Installation

    • Step 6 - Recheck Installation To be sure you have correctly installed your Room Air Conditioner, review the steps and make sure all of the parts are securely fastened in the window as the instructions show. A tight seal is essential.

  • Page 9: Names Of Major Components

    NAMES OF MAJOR COMPONENTS • DWC-100C / DWC-121C / DWA-122C / DWA-150C / DWA-151C • DWC-100CS / DWC-121CS / DWA-122CS / DWA-150CS / DWA-151CS NO PART NAME AIR FILTER GRILLE FRONT CABINET BLADE VERTICAL KNOB THERMOSTAT KNOB SELECTOR NO PART NAME...

  • Page 10: Operating Instructions

    Choose one of the speed settings by rotating the fan control Selector Switch to the appropriate position. CAUTION When the air conditioner has been performing its cooling operation and is turned “OFF” or set to the ‘FAN” position, wait at least 3 minutes before resetting to the cooling operation.

  • Page 11: General Information

    Locate drain hole at the rear or on the bottom of unit. Water in base pan is picked up by the fan blade and thrown onto the warm outdoor coil where it evaporates. The air conditioner must be installed level or tilted slightly to the outside for proper water disposal.

  • Page 12: Care And Maintenance

    Have the unit inspected by an authorized service man to ensure unit is functioning properly. 2. Wash air conditioner with lukewarm, soapy water as needed. Rinse and dry thoroghly. 3. If using concentrated liquid detergent, dilute in warm water first.

  • Page 13: Electrical Requirements

    3-wire grounding type appliance extension cord rated has a 3-blade grounding plug and a 3-slot receptacle that will plug into the appliance. The marked rating of the extension cord should be 125V/13A minimum for DWC-100C, DWC-100CS, DWC-121C, DWC-121CS and 250V/10A minimum for DWA-122C, DWA-122CS, DWA-150C, DWA-150CS, DWA-151C, DWA-151CS.

  • Page 14: Before Calling For Service

    BEFORE CALLING FOR SERVICE When you find something wrong with your room air conditioner, please carefully check the following items. If you are unable to find the cause of trouble, contact your service dealer. Difficulty • Air conditioner does not operate.

  • Page 15: Limited Warranty

    Daewoo authorized service center. To establish and receive warranty service at our store, dealer or our authorized service center, a sales receipt or bill of sales is required for proof of purchase.

  • Page 16: Room Air Conditioner

    ROOM AIR CONDITIONER USE & CARE MANUAL WINDOW TYPE ROOM AIR CONDITIONER DWC-100C, DWC-100CS MODEL #: DWC-121C, DWC-121CS DWA-122C, DWA-122CS DWA-150C, DWA-150CS DWA-151C, DWA-151CS UL and CUL listed LISTED Please read carefully and thoroughly this manual before operating the unit.
