Daewoo DWC-121C Service Manual page 14

• HOW TO REMOVE THE FRONT GRILLE FOR ONLY DW -124C/CS, DWA-152C/CS
1. Open the grille upward by pulling out the bottom of the grille,
lift it.
2. Remove screw which fasten Frame Grille with driver.
3. Pull knobs out of the control.
(when the knobs are too tight to release, leave them.)
4. Disassemble Grille from Chassis.
Frame
– Grille and chassis are fixed with snap-fit.
Frame
1) Release right-lower snap-fit.
– Push the right lower side of chassis to the left, with pushing left side of
to the right until the snap-fit is released.
2) Release left-lower snap-fit.
– Push the left-lower side of chassis to the right, with pushing right side of
Grille to the right until the snap-fit is released.
3) Pull lower side of the
knobe remain, pull Frame
4) Push base side of the
chassis.
5) After frame grille is removed, remove two screws located in both side of
chassis.
6) Grip the handle of base pan and pull out the unit from chassis.
Frame Grille until it is separated from the chassis. (when
Grille until knobs are released from control)
Grille to upper side until it is separated from the
Frame
Frame Grille
Frame
13
Push
Push
Push
Push
