Window type room air conditioner
Hide thumbs Also See for DWA-122C:

Advertisement

PRECAUTIONS FOR PROPER USE OF AIR CONDITIONER
Please observe the following instructions.
1. Operate the Selector Switch to run or stop the unit.
- Do not use Main Power Switch or Auxiliary Power Switch to operate unit.
2. Do not stick anything into the air outlet or inlet.
- It is dangerous and it can cause injury or damage.
3. Avoid exposing your body directly to a continuous cool air - flow for long periods.
- It is not good for your health.
4. Do not pour water on the unit to clean it.
- It is dangerous and it can cause injury or damage.
Never use solvents or harsh chemicals when cleaning the unit.
When the air inlet grill and cabinet are dirty, wipe with luke - warm water (below 40°C or 104°F)
5. Avoid placing any obstacles near the inlet or outlet.
- If the inlet or outlet is blocked with any obstacle, it may cause damage to the unit.
6. Do not run or stop the unit frequently.
- If you run or stop the unit more then 4-5 times an hour, it can cause damage to the unit.
7. Wait at least 3 minutes before restarting the unit or in the case of power failure.
- If you turn on the unit within 3 minutes after power off, this can cause damage to the unit.
8. If the air conditioner is operated without an air filter, dust is not removed from the air, and resultant
accumulation in the unit may lead to a failure.
- Do not forget to install the air filter.
9. The air filter should be cleaned at least once every two weeks.
10. When the unit is cleaned, set the Selector Switch at off position.
- And then unplug the power plug.
11. Never store gasoline or other flammable liquid near the air conditioner.
- It is very dangerous.
12. Do not force the controls on the front panel too much.
- It can cause damage the controls and the unit.
13. Set a comfortable temperature.
- Very low temperature setting considerably increase power consumption.
14. Be careful to keep room temperature comfortable.
- Avoid continuous direct air flow on you or a sick person while sleeping.
15. Do not remove the plug by pulling the power cord.
- Damage to the cord and may cause shock hazard.
16. This air-conditioner must used 20°C(min)-43°C(max) outdoor and 20°C(min)~32°C(max) indoor on the
temperature range.
17. The appliance is not intended for use by young children or infirm persons without supervision.
18. Young children should be supervised to ensure that they do not play with the appliance.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWA-122C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Daewoo DWA-122C

  • Page 1 PRECAUTIONS FOR PROPER USE OF AIR CONDITIONER Please observe the following instructions. 1. Operate the Selector Switch to run or stop the unit. - Do not use Main Power Switch or Auxiliary Power Switch to operate unit. 2. Do not stick anything into the air outlet or inlet. - It is dangerous and it can cause injury or damage.
  • Page 2: Table Of Contents

    8. BEFORE CALLING FOR SERVICE................12 GENERAL SPECIFICATIONS MODEL DWA-122C / DWA-122CS DWB-122C / DWB-122CS DWB-123C / DWB-123CS DWA-151C / DWA-151CS ITEM POWER SOURCE AC 208~230V, 60Hz SINGLE PHASE AC 220~230V, 50Hz SINGLE PHASE AC 240V, 50Hz SINGLE PHASE AC 208~230V, 60Hz SINGLE PHASE...
  • Page 3: Installation Instructions

    1. Install an exclusive main power switch (main circuit breaker) or GFI (Ground Fault Interrupted) Switch. 2. Be sure to use grounded power source. 3. Power source for DWA-122C, DWA-122CS, DWA-151C, DWA-151CS is 208~230V and DWB-122C, DWB-122CS is 220~230V and DWB-123C, DWB-123CS is 240V.
  • Page 4: How To Remove The Front Grille

    • HOW TO REMOVE THE FRONT GRILLE 1. Pull the Air-filter out of the Front Grille. 2. Loosen screw which fasten Front Grille with driver. 3. Pull knobs out of the control. (when the knobs are too tight to release, leave them.) 4.
  • Page 5 5. Reinstall the unit, side screws, front grille. CAUTION • When the front grille is reinstalled, the DOOR VENT should be in position first so that it would not be bent by grille. Door Vent...
  • Page 6: How To Install The Drain Cap

    • HOW TO INSTALL THE DRAIN CAP Install the drain cap like Fig. of the right side. There are two kinds of method to install the drain cap. The first method is that the shape of hole like The rear side of the unit It is good for the household.
  • Page 7: Names Of Major Components

    NAMES OF MAJOR COMPONENTS • DWA-122C / DWB-122C / DWB-123C / DWA-151C • DWA-122CS / DWB-122CS / DWB-123CS / DWA-151CS PART NAME PART NAME AIR FILTER BLADE HORIZENTAL GRILLE FRONT AIR VENT CABINET FRAME GUIDE TOP BLADE VERTICAL FRAME WINDOW KIT...
  • Page 8: Operating Instructions

    OPERATING INSTRUCTIONS NOTE • FOR MOST ECONOMICAL USE 1. Properly control the room temperature. 2. Avoid the unit being exposed to direct sunlight. Keep direct sunlight from the room. 3. Do not leave doors and windows open. • FAN & COOLING CONTROL The Fan Control Selector Switch has six positions.
  • Page 9: General Information

    GENERAL INFORMATION • CHANGING AIR FLOW DIRECTION Air flow deflectors divert air from center flow to left or right and up or down. Adjust deflectors for desired air flow pattern. AUTO SWING (DWA-122CS, DWB-122CS, DWB-123CS, DWA-151CS) When the auto louver switch is turned to “ON” position, the vertical louvers AUTO SWING automatically move right and left.
  • Page 10: Care And Maintenance

    CARE AND MAINTENANCE CAUTION To avoid death or personal injury due to electrical shock, turn fan control OFF and unplug power cord before cleaning or performing maintenance. After cleaning or performing maintenance, reconnect power. • AIR FILTER Clean the air filter, which removes dust inside the room. It should be washed at least once every week during operation.
  • Page 11: Electrical Requirements

    ELECTRICAL REQUIREMENTS • ELECTRICAL GROUNDING INSTRUCTIONS This appliance is equipped with a three-prong(grounding) plug for protection against possible shock hazards. If a two-prong wall receptacle is encountered, the customer is required to contact a qualified electrician and have the two-prong wall receptacle replaced with a properly grounded three-prong wall receptacle in accordance with the National Electrical Code.
  • Page 12: Before Calling For Service

    BEFORE CALLING FOR SERVICE When you find something wrong with your room air conditioner, please carefully check the following items. If you are unable to find the cause of trouble, contact your service dealer. Difficulty Possible Cause Suggested Solution • Air conditioner does •...
  • Page 13: Room Air Conditioner

    ROOM AIR CONDITIONER USE & CARE MANUAL WINDOW TYPE ROOM AIR CONDITIONER DWA-122C, DWA-122CS MODEL #: DWB-122C, DWB-122CS DWB-123C, DWB-123CS DWA-151C, DWA-151CS Please read carefully and thoroughly this manual before operating the unit. If you still have any difficulties or problems, consult your dealer for help or ELECTRONICS.
