Quick Setup Guide
ix2600
THANK YOU!
Congratulations on your purchase.
We are sure you will be pleased with
the convenient way your new
machine performs so many tasks
with dazzling results!
3
If you have an Optional Lower
Cassette, Connect it
A. Carefully pick up the machine and place it on top of the lower cassette.
B. Plug the modular cable from the lower cassette into the modular jack on
the machine.
To select which cassette will be used for printing. See Chapter 4 in
Owner's Manual in CD-ROM.
If you move the machine after connecting the lower cassette, be sure to
carefully lift the lower cassette with the machine because they are not
attached.
5
Install Phone Line
and Power Cord
Do Not connect the Parallel or USB Cable.
Power Cord
Telephone
Line Cord
8

Set Date and Time

A. Press , , .
1 2
2.DATE/TIME
YEAR:XX
ENTER & YES
B. Enter the last two digits of the year and press Enter/Yes.
MONTH:XX
ENTER & YES
C. Enter two digits for the month and press Enter/Yes.
DAY:XX
ENTER & YES
D. Enter two digits for the day and press Enter/Yes.
TIME:XX
ENTER & YES
E. Enter the time in 24-hour format and press Enter/Yes, then
Stop.
Note: If you can't step forward, press Stop and repeat from Step A.
1

Install the Drum Unit

A. Unpack the drum unit assembly, including
the toner cartridge, and gently rock it from
side to side five
or six times to distribute the toner evenly
inside the cartridge.
To prevent damage to the drum, do not
expose it to light for longer than
a few minutes.
B. Remove the protective part.
D.
C. Open the front cover of the
machine.
E. Close the front cover.
4
A. Pull the paper cassette completely out of the
machine.
B. Slide the paper width and length adjusters of
paper cassette for the paper size you want.
6
If you are sharing one
phone line with an external
telephone answering
device, connect it now
See Chapter 2-10
in your Owner's
Manual in CD-ROM.
9

Set Machine ID

Machine ID is to print your name and fax number
on all fax pages.
A. Press ,
1
3.MACHINE ID
FAX:
ENTER & YES
B. Enter your fax number, then press Enter/Yes.
TEL:
ENTER & YES
Continue to the back side.
– 1 –
2
Push the lever up to unlock the scanner. (The blue
Scanner Lock Lever is on the back left under side of the
scanner cover.)
Insert the drum unit
assembly into the machine.

Load Paper

7
Choose the mode that best suits your needs by pressing
Answer Mode repeatedly until the screen displays the setting
you want to use.
For use with a dedicated fax line. Every call is answered as a fax.
You control the phone line and must answer every call
yourself.
TAM
If an external telephone is connected to the EXT. jack, the machine
controls the line and automatically answers every call. If the call is
TAM
a fax it will receive the fax. If the call is not a fax it will ring (double
or
ring) for you to pick up the call using an external telephone.
TAM:ANSWER MACH.
The external TAM automatically answers every call. Voice messages
are stored on the external TAM. Fax messages are printed.
For more details, see Chapter 5 in Owner's Manual in CD-ROM.
, .
3
Release the Scanner
Lock
Scanner Lock Lever
Lock Unlock
If CHECK SCAN LOCK appears on the LCD,
immediately release the scanner lock and press
Stop.
C. Load paper in the paper cassette. Press
down the paper to flatten in all four corners,
keeping the paper level below the guide.
D. Slide the paper cassette into the machine
until it locks into place.
Maximum Paper Height Guide

Select an Answer Mode

FAX ONLY
MANUAL
FAX/TEL
C. Enter your telephone number, then press Enter/Yes.
NAME:
ENTER & YES
D. Enter your name using the dial pad and the chart
below, then press Enter/Yes. Use the right arrow
to create spaces.
E. Press Stop.
For more details, see Chapter 4 in Owner's Manual.
Note: If you can't step forward, press Stop and repeat
from Step A.
Key once twice three times four times
2 A B C 2
F 3
3 D E
4 G H I 4
5 J K L 5
6 M N O 6
7 P Q R S
8 T U V 8
9 W X Y Z
five times
A
D
G
J
M
7
T
9
