SMART Board® 8000i-G4 series
interactive flat panels
SETUP AND MAINTENANCE GUIDE
FOR MODELS 8070i-G4-SMP AND 8084i-G4-SMP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the board 8000i-G4 series and is the answer not in the manual?

Questions and answers

Related Manuals for SMART board 8000i-G4 series

Summary of Contents for SMART board 8000i-G4 series

  • Page 1 SMART Board® 8000i-G4 series interactive flat panels SETUP AND MAINTENANCE GUIDE FOR MODELS 8070i-G4-SMP AND 8084i-G4-SMP...
  • Page 2 © 2013–2015 SMART Technologies ULC. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language in any form by any means without the prior written consent of SMART Technologies ULC. Information in this manual is subject to change without notice and does not represent a commitment on the part of SMART.

  • Page 3: Important Information

    Do not open or disassemble the SMART product. You risk electrical shock from the high voltage inside the casing. Opening the casing also voids your warranty. Do not stand (or allow children to stand) on a chair to touch the surface of your SMART product. Rather, mount the product at the appropriate height.
  • Page 4 Avoid setting up and using the SMART product in an area with excessive levels of dust, humidity and smoke. Make sure an electrical socket is near your SMART product and remains easily accessible during use.
  • Page 5 IMPORTANT INFORMATION This SMART product should be used only with European TN and TT power distribution systems. It is not suitable for older, IT-type power distribution systems found in some European countries. "This system (IT-type) is widely used isolated from earth, in some installations in France, with impedance to earth, at 230/400V, and in Norway, with voltage limiter, neutral not distributed, at 230V line-to-line."...

  • Page 7: Table Of Contents

    Disabling the USB receptacles Chapter 4: Setting up your interactive flat panel and room computer Turning on your interactive flat panel and room computer for the first time Installing SMART software Running the connection wizard Chapter 5: Using your interactive flat panel Turning on and turning off your interactive flat panel...
  • Page 8 Resolving touch control and digital ink issues Resolving audio issues Resolving remote control issues Resolving presence detection issues Resolving issues using the SMART Connection Wizard Resolving issues using SMART Board Diagnostics Appendix A: Using the on-screen display menu Changing settings in the on-screen display menu SMART Board 8070i-G4-SMP interactive flat panel on-screen display menu...
  • Page 9 Front control panel Remote control I/O extension module Differences between models About this guide Other documentation and resources Specifications Installation instructions Cabling guides Help Training Knowledge base This chapter introduces you to your SMART Board interactive flat panel and this guide. smarttech.com/kb/170446...

  • Page 10: Chapter 1 Welcome

    WELCOME About your interactive flat panel Your SMART Board interactive flat panel features SMART’s proprietary DViT® (Digital Vision Touch) technology on an LCD screen with e-LED backlight which enables you to select, write and erase on the interactive surface. You can do everything on the interactive flat panel that you can do at your computer by touching the surface, and you can use an array of gestures within applications.

  • Page 11: Audio

    Your interactive flat panel includes two 10 W integrated front-firing speakers for presenting audio from connected input sources. SMART software You can install the following SMART software on the computers connected to your interactive flat panel to take full advantage of the interactive flat panel’s features: Software Description SMART Product Drivers...

  • Page 12: Components

    CHAPTER 1 WELCOME Components Your interactive flat panel consists of the following components: Name Screen DViT cameras and reflective tape channel Presence detection sensor (×2) Speakers Pen (×2) Eraser Color select module Front control panel Remote control NOTE Components not pictured include the I/O extension module for external PCs, connector panels (see Connector panels on page 18) and the menu control panel (see Menu control panel on page 43).

  • Page 13: Screen

    CHAPTER 1 WELCOME Screen The active screen area specifications vary by model: Models Diagonal Width Height Aspect ratio 8070i-G4-SMP 70" (178 cm) 61" (154.9 cm) 34 3/8" (87.2 cm) 16:9 8084i-G4-SMP 84" (213.4 cm) 73 1/4" (186.1 cm) 41 1/4" (104.7 cm) 16:9 For information on cleaning the screen, see Cleaning the screen on page 50.

  • Page 14: Speakers

    CHAPTER 1 WELCOME If ECO Standby mode is enabled for SMART Board 8070i-G4-SMP interactive flat panels, presence detection functionality is limited. For more information on the on-screen display menu settings relevant for presence detection, see page 72 for SMART Board 8070i-G4-SMP interactive flat panels or page 80 for SMART Board 8084i-G4-SMP interactive flat panels.

  • Page 15: Front Control Panel

    CHAPTER 1 WELCOME Name Blue pen color Right-click Orient Front control panel The front control panel contains the volume control, Mute, Input Select and Power/Standby buttons, as well as the status light and the remote control sensor. Name Volume control Mute button Input Select button Power/Standby button / power...

  • Page 16: Remote Control

    For information on diagnosing issues using the front control panel lights, see Resolving blank screen issues on page 56. For information on disabling the front control panel for multiple interactive flat panel installations, see page 72 for SMART Board 8070i-G4-SMP interactive flat panels or page 81 for SMART Board 8084i-G4-SMP interactive flat panels. Remote control The remote control enables you to turn on and turn off your interactive flat panel, change the input source, adjust the volume, access the on-screen menu and more.

  • Page 17: About This Guide

    CHAPTER 1 WELCOME Item 8070i-G4-SMP 8084i-G4-SMP Video and audio inputs HDMI (×3) HDMI (×3) DisplayPort DispalyPort VGA (×2) DVI-D DVI-D Component video Component video Composite video Composite video S-video Stereo 3.5 mm Stereo 3.5 mm Dual RCA audio (×2) Dual RCA audio (×2) Video and audio outputs DVI-D Stereo 3.5 mm (×3)

  • Page 18: Other Documentation And Resources

    If you misplaced these installation instructions, you can download a PDF version from smarttech.com/kb/170513. To use your interactive flat panel with a connected computer, you need to install SMART software on the computer (see SMART software on page 3). If you need to deploy SMART software to multiple computers on your network, refer to the system administrator’s guide (see...

  • Page 19: Help

    2. Press Help Center. The Help appears. If you want to view the Help on your smart phone, tablet or other Internet-connected mobile device, scan the QR code that appears on the home page of the Help with your device’s camera.

  • Page 21: Chapter 2: Mounting Your Interactive Flat Panel

    Review the environmental requirements in the interactive flat panel’s specifications (see Specifications on page 10). Save all product packaging so that it’s available if you need to transport the interactive flat panel. If the original packaging isn’t available, you can purchase new product packaging from your authorized SMART reseller (smarttech.com/where). smarttech.com/kb/170446...
  • Page 22 CHAPTER 2 MOUNTING YOUR INTERACTIVE FLAT PANEL Refer to local building codes to ensure the wall can support the weight of the interactive flat panel and mounting equipment. Models Weight (lb.) Weight (kg) 8070i-G4-SMP 8084i-G4-SMP 118.3 Attach the included eyebolts and washers to assist in mounting, and remove them after you mount the interactive flat panel.

  • Page 23: Choosing A Location

    NOTE SMART recommends M8 × 30 mm mounting screws for standard installations where the total wall mount bracket and washer thickness is less than 7 mm. Because the receptacles might not be easily accessible after the installers mount the...

  • Page 24: Choosing A Height

    CHAPTER 2 MOUNTING YOUR INTERACTIVE FLAT PANEL If you mount the interactive flat panel in a recessed area, leave at least 4" (10 cm) of space between the interactive flat panel and the recessed walls to enable ventilation and cooling. Choosing a height Consider the general height of the user community when you choose the height for the interactive flat panel.

  • Page 25: Chapter 3: Connecting Power And Devices

    In a typical installation, you connect your interactive flat panel to a room computer and up to one guest laptop (SMART Board 8070i-G4-SMP interactive flat panels) or to a room computer and up to two guest laptops (SMART Board 8084i-G4-SMP interactive flat panels).

  • Page 26: Connector Panels

    There are connector panels on the top, left, right and bottom of your interactive flat panel as well as on the I/O extension module. SMART Board 8070i-G4-SMP interactive flat panel connector panels The following diagram and table present the connectors on SMART Board 8070i-G4-SMP interactive flat panels: Type...
  • Page 27 CHAPTER 3 CONNECTING POWER AND DEVICES Type Details Identifier Bottom connector panel AC power AC power pass-through AC power AC power inlet and switch USB 2.0 Type-B receptacle USB2 Room control in RS-232 connector Room control out / RS-232 connector pass-through Video in DisplayPort connector...

  • Page 28: Smart Board8084I-G4-Smp Interactive Flat Panel Connector Panels

    CHAPTER 3 CONNECTING POWER AND DEVICES SMART Board8084i-G4-SMP interactive flat panel connector panels The following diagram and table present the connectors on SMART Board 8084i-G4-SMP interactive flat panels: Type Details Identifier Top connector panel USB 3.0 Type-A receptacle Audio out Stereo 3.5 connector...

  • Page 29: Connecting Power

    Connecting power Connect the supplied power cable from the AC power inlet on the bottom connector panel (SMART Board 8070i-G4-SMP interactive flat panels) or on the back of the interactive flat panel (SMART Board 8084i-G4-SMP interactive flat panels) to a power outlet.

  • Page 30: Connecting The Room Computer

    You can then run the cables across floors or behind walls to the conference table. WARNING Ensure that any cables extending across the floor to your SMART product are properly bundled and marked to avoid a trip hazard. Connecting laptop cables to SMART Board 8070i-G4-SMP interactive flat panels...

  • Page 31: Connecting Laptop Cables To Smart Board 8084I-G4-Smp Interactive Flat Panels

    Connecting laptop cables to SMART Board 8084i-G4-SMP interactive flat panels You can connect up to two laptops to a SMART Board 8084i-G4-SMP interactive flat panel. For the first laptop: Connect a USB cable to the USB2 receptacle on the bottom connector panel.

  • Page 32: Connecting External Speakers

    NOTES For SMART Board 8070i-G4-SMP interactive flat panel, users can specify the current audio by selecting it in the on-screen display menu or by pressing the AUDIO INPUT button on the remote control (see page 71).
  • Page 33 CHAPTER 3 CONNECTING POWER AND DEVICES To disable the USB receptacles 1. Locate the rectangular cut-out on the back of the top connector panel. 2. Remove the screw securing the cut-out with a Phillips screwdriver. Retain the screw and cut-out. 3.

  • Page 35: Chapter 4: Setting Up Your Interactive Flat Panel And Room Computer

    Turning on your interactive flat panel and room computer for the first time Installing SMART software Downloading and installing SMART software Deploying SMART software to multiple computers Running the connection wizard This chapter explains how to set up your interactive flat panel and room computer after mounting your interactive flat panel and connecting power and devices.

  • Page 36: Installing Smart Software

    You may need to deploy SMART software to multiple computers in the following situations: Your organization has multiple interactive flat panels, each with its own room computer. You want to deploy SMART software to users’ laptops so that they can use their laptops with your interactive flat panel.
  • Page 37 2. Press Connection Wizard. The SMART Connection Wizard appears. 3. Select the interactive flat panel from the list of connected SMART interactive products, and then press Next. 4. Select Product is being set up for the first time, and then press Next.

  • Page 39: Chapter 5: Using Your Interactive Flat Panel

    Chapter 5 Using your interactive flat panel Turning on and turning off your interactive flat panel Turning on and turning off SMART Board 8070i-G4-SMP interactive flat panels Turning on and turning off SMART Board 8084i-G4-SMP interactive flat panels Using presence detection Using your interactive flat panel with the room computer...

  • Page 40: Turning On And Turning Off Smart Board 8070I-G4-Smp Interactive Flat Panels

    CHAPTER 5 USING YOUR INTERACTIVE FLAT PANEL Turning on and turning off SMART Board 8070i-G4-SMP interactive flat panels To turn on your interactive flat panel 1. Turn on your computer. 2. Press the Power/Standby button on the front control panel. Press the POWER ON button on the remote control.

  • Page 41: Using Presence Detection

    CHAPTER 5 USING YOUR INTERACTIVE FLAT PANEL Turning on and turning off SMART Board 8084i-G4-SMP interactive flat panels To turn on your interactive flat panel 1. Turn on your computer. 2. Press the Power/Standby button on the front control panel. Press the POWER button or the MONITOR ON button on the remote control.

  • Page 42: Using Your Interactive Flat Panel With The Room Computer

    (see Setting up your interactive flat panel and room computer on page 27). Using SMART software The SMART software installed on the room computer allows users to do the following: Interact with objects on the screen by touching them Write, draw and erase digital ink...

  • Page 43: Using Your Interactive Flat Panel With Guest Laptops

    Connecting a guest laptop directly to your interactive flat panel When a user connects a guest laptop to the interactive flat panel, the laptop’s desktop is displayed on the interactive flat panel and touch interactivity is enabled if SMART software is installed (see Installing SMART software on page 28).

  • Page 44: Connecting A Guest Laptop Through A Smart Gowire Cable

    Connecting a guest laptop through a SMART GoWire cable If you want to connect a laptop that doesn’t have SMART software installed, you can use a SMART GoWire cable. The SMART GoWire cable enables you to have touch control of the laptop and use SMART Meeting Pro PE software without installing the software on the laptop.

  • Page 45: Changing Input Sources

    SMART Meeting Pro PE software while your laptop is connected to your interactive flat panel. To disconnect a SMART GoWire cable 1. If required, save your SMART Meeting Pro software file to your laptop. You can save the file as an .fcw file. NOTE You can open an .fcw file on a computer that has SMART Meeting Pro software or...

  • Page 46: Using The Remote Control

    CHAPTER 5 USING YOUR INTERACTIVE FLAT PANEL The remote control for SMART Board 8070i-G4-SMP interactive flat panels has buttons for each input source (HDMI1, HDMI2, HDMI3/PC and so on). Press one of these input source buttons to display the connected device’s input.

  • Page 47: Remote Control Buttons

    USING YOUR INTERACTIVE FLAT PANEL Remote control buttons The remote control enables you to access on-screen menus and to change display and input settings. SMART Board 8070i-G4-SMP interactive flat panel remote control Name Description POWER ON Turn on the interactive flat panel...
  • Page 48 CHAPTER 5 USING YOUR INTERACTIVE FLAT PANEL Name Description [Number buttons] Press buttons on the number pad to set and change passwords, change channels or customize or change settings DISPLAY Display the information menu Open a selected menu option in the on-screen display menu [Left and right buttons] Change the value of the selected menu option in the on- screen display menu AUTO SET UP...

  • Page 49: Smart Board 8084I-G4-Smp Interactive Flat Panel Remote Control

    CHAPTER 5 USING YOUR INTERACTIVE FLAT PANEL SMART Board 8084i-G4-SMP interactive flat panel remote control Name Description POWER Turn on or off the interactive flat panel MONITOR Alternate between different interactive flat panel modes (on, off and Standby) depending on how you configure Standby mode...
  • Page 50 CHAPTER 5 USING YOUR INTERACTIVE FLAT PANEL Name Description 1/a/A Switch the number pad between number input (1, 2, 3), lowercase letter input (a, b, c) and uppercase letter input (A, B, C) MARK/ARC Set the aspect ratio VOL +/- Increase or decrease audio output level MUTE Mute audio inputs for the interactive flat panel MENU...

  • Page 51: Menu Control Panel

    Menu control panel As an alternative to using your remote control to navigate the on-screen display menu, you can use the menu control panel located on the bottom of the interactive flat panel. SMART Board 8070i-G4-SMP interactive flat panels Name MENU...

  • Page 53: Chapter 6: Maintaining Your Interactive Flat Panel

    Opening SMART Settings Several maintenance and troubleshooting procedures in this guide require you to open SMART Settings. To open SMART Settings on Windows 7 operating systems Select Start > All Programs > SMART Technologies > SMART Tools > SMART Settings. SMART Settings appears. smarttech.com/kb/170446...

  • Page 54: Updating Software

    SMART Product Update (SPU) is included in the SMART software you installed to use your interactive flat panel (see Installing SMART software on page 28). SPU periodically checks for updates to the SMART software posted on the SMART website. You can configure SPU to prompt users to install updates or to install updates automatically.

  • Page 55: Calibrating Your Interactive Flat Panel

    DViT cameras in the corners of the interactive flat panel track the position of the pens, eraser and your finger on the interactive surface, and then send the information to the SMART software, which interprets this information as mouse clicks, digital ink or ink removal in the appropriate location.

  • Page 56: Orienting Your Interactive Flat Panel

    3. If you have more than one SMART product connected, select the interactive flat panel. If you don’t know which interactive flat panel listed in SMART Settings is the one you want to calibrate, press the interactive flat panel’s surface with your finger. The blue dot to the right of the interactive flat panel’s name in SMART Settings changes color to blue.

  • Page 57: Replacing Batteries In The Remote Control

    CHAPTER 6 MAINTAINING YOUR INTERACTIVE FLAT PANEL 2. Use an interactive flat panel pen to press the red targets as they appear. Hold the tip of the pen at the center of each target, and then lift the pen. When you lift the pen, the target moves to the next orientation point.

  • Page 58: Replacing A Pen Nib

    To prevent damage to the interactive flat panel’s anti-glare coating, replace your pen nib if it becomes worn. Four replacement pen nibs are included with the pens, and you can purchase additional replacements from the Store for SMART Parts (see smarttech.com/Support/PartsStore). To replace a pen nib 1.

  • Page 59: Cleaning The Dvit Camera Windows And Reflective Tape

    CHAPTER 6 MAINTAINING YOUR INTERACTIVE FLAT PANEL CAUTION Do not use compressed air, water, chemical agents or cleaning agents to clean the sensors. To clean the presence detection sensors Gently wipe the sensors using a clean lint-free cloth. Cleaning the DViT camera windows and reflective tape The DViT technology in your interactive flat panel uses four cameras in the corners of the frame and the reflective material between the screen and the bezels.

  • Page 60: Maintaining Ventilation

    1. Remove the humidity source from the interactive flat panel, if possible. 2. Adjust the room temperature to normal operating ranges. 3. Turn on the interactive flat panel and leave it on for 2–3 hours. 4. If the screen condensation doesn’t evaporate, contact SMART Support (smarttech.com/contactsupport). smarttech.com/kb/170446...

  • Page 61: Checking The Interactive Flat Panel Installation

    CHAPTER 6 MAINTAINING YOUR INTERACTIVE FLAT PANEL Checking the interactive flat panel installation Inspect your interactive flat panel installation frequently to ensure that it remains securely installed. Check the mounting location for signs of damage or weakness that can occur over time. Check for loose screws, gaps, distortions or other issues that could occur with the mounting apparatus.

  • Page 62: Transporting Your Interactive Flat Panel

    This packaging was designed with optimal shock and vibration protection. If your original packaging isn’t available, you can purchase the same packaging directly from your authorized SMART reseller (smarttech.com/where). CAUTION Transport your interactive flat panel only in original or replaced packaging. Transporting your interactive flat panel without correct packaging voids your warranty and could lead to product damage.

  • Page 63: Chapter 7: Troubleshooting Your Interactive Flat Panel

    SMART Support (smarttech.com/contactsupport). Locating the interactive flat panel serial number When you contact SMART Support, you might be asked to provide the interactive flat panel serial number. The easiest way to locate this serial number is using the on-screen display menu (see page 71 for SMART Board 8070i-G4-SMP interactive flat panels or page 82 for SMART Board...

  • Page 64: Resolving Blank Screen Issues

    Solid green Flashing green The interactive flat panel detects a Install SMART Product Drivers or connect computer, but a SMART GoWire cable (see page 36). SMART Product Drivers isn’t installed or isn’t running (see page 60). Solid green Solid green The interactive flat panel detects a...

  • Page 65: Resolving Image Quality Issues

    Symptom Causes Solution The image is too large, too small or The computer’s video resolution The native resolution of SMART Board doesn’t completely fill the screen. settings don’t match the interactive 8070i-G4-SMP interactive flat panels is flat panel’s native resolution. 1920 × 1080 at 60 Hz.
  • Page 66 Help for more information. Select the HDTV setting (ideally 1080p for SMART Board 8070i-G4-SMP interactive flat panels or 4K UHD for SMART Board 8084i-G4-SMP interactive flat panels) from the video card driver’s advanced menu (if available). This should provide a pixel-perfect image for the interactive flat panel.
  • Page 67 You have a poor quality video 1. Replace the video cable with a better cable. quality video cable. 2. Press AUTO SETUP (on SMART Board 8070i-G4-SMP interactive flat panels) or AUTO (on SMART Board 8084i-G4-SMP interactive flat panels) on the remote control.

  • Page 68: Resolving Touch Control And Digital Ink Issues

    Symptom Causes Solution When you touch the screen, no SMART Product Drivers isn’t Start SMART Board Tools following the pointer appears and you’re unable running. steps in the Help (see page 11). to move icons. The status light is SMART Product Drivers isn’t Update SMART Product Drivers (see...
  • Page 69 For more information, see Touching and When you touch the screen the You aren’t touching the screen at a pointer appears in the wrong right angle. drawing on your SMART Board interactive whiteboard is inaccurate location. (knowledgebase.force.com/?q=13976). The interactive flat panel isn’t Orient the interactive flat panel (see oriented.

  • Page 70: Resolving Audio Issues

    The remote control batteries need Replace the batteries (see page 49). to be replaced. The remote control is damaged. Contact your authorized SMART reseller (smarttech.com/where) to inquire about a replacement remote control. Resolving presence detection issues The sensors for presence detection can detect when people are within 16' (5 m) of the interactive flat panel and automatically turn on or off the interactive flat panel.
  • Page 71 Increase the time before the interactive off when people are present. room temperature so people’s flat panel automatically turns off (see body temperature becomes part of page 72 for SMART Board 8070i-G4-SMP the ambient temperature. interactive flat panels or page 80 for SMART Board 8084i-G4-SMP interactive flat panels).

  • Page 72: Resolving Issues Using The Smart Connection Wizard

    If you touch the interactive flat panel’s surface and nothing happens, or if there is no digital ink or the ink appears in some locations and not in others, use SMART Board Diagnostics to help identify and resolve these issues.
  • Page 73 CHAPTER 7 TROUBLESHOOTING YOUR INTERACTIVE FLAT PANEL 3. Select View > SBX800/SBID8000i Bar. The SBX800 group box appears in the SMART Board Diagnostics screen. 4. Press View. The DViT camera view screen appears. 5. Click Update to display the four DViT camera views. This could take a few moments.

  • Page 75: Appendix A: Using The On-Screen Display Menu

    Appendix A Using the on-screen display menu Changing settings in the on-screen display menu SMART Board 8070i-G4-SMP interactive flat panel on-screen display menu SMART Board 8084i-G4-SMP interactive flat panel on-screen display menu You can access the on-screen display menu using either the remote control (see Remote control buttons on page 39) or the menu control panel (see Menu control panel on page 43).

  • Page 76: Smart Board 8070I-G4-Smp Interactive Flat Panel On-Screen Display Menu

    APPENDIX A USING THE ON-SCREEN DISPLAY MENU SMART Board 8070i-G4-SMP interactive flat panel on-screen display menu Option Values Function Notes (if any) PICTURE PICTURE MODE STANDARD Sets the picture mode Select USER to customize brightness, contrast, sharpness CINEMA/sRGB and other PICTURE options. SPORT Select AMBIENT to set brightness...
  • Page 77 APPENDIX A USING THE ON-SCREEN DISPLAY MENU Option Values Function Notes (if any) GREEN 0–100 Sets the amount of green in the You can modify this option only if image you select USER in COLOR TEMPERATURE . BLUE 0–100 Sets the amount of blue in the You can modify this option only if image you select USER in...
  • Page 78 APPENDIX A USING THE ON-SCREEN DISPLAY MENU Option Values Function Notes (if any) H-POSITION 0–100 Sets the horizontal position of the You can modify this option only if image within the screen area the currently selected video input is VGA. V-POSITION 0–100 Sets the vertical position of the...
  • Page 79 APPENDIX A USING THE ON-SCREEN DISPLAY MENU Option Values Function Notes (if any) LINE OUT FIXED Sets the audio line out VARIABLE FIXED Sets the audio line out for the room HDMI3/PC LINE OUT computer (HDMI3/PC) VARIABLE AUDIO INPUT DPORT Sets the audio input source Alternatively, you can press the AUDIO INPUT button on the...
  • Page 80 APPENDIX A USING THE ON-SCREEN DISPLAY MENU Option Values Function Notes (if any) SETUP POWER SAVE Enables or disables Power Save When Power Save mode is enabled mode and there isn’t video input, the interactive flat panel displays No Signal for 25 seconds before turning off.
  • Page 81 APPENDIX A USING THE ON-SCREEN DISPLAY MENU Option Values Function Notes (if any) HEAT STATUS FAN1 [N/A] Shows the status of the first fan This option only provides information. You’re unable to modify it. FAN2 [N/A] Shows the status of the second fan This option only provides information.

  • Page 82: Smart Board 8084I-G4-Smp Interactive Flat Panel On-Screen Display Menu

    Values Function Notes (if any) Lync® ROOM RESET [N/A] Resets options in all menus to their default values (for a SMART Room System™ for Microsoft® Lync) [N/A] Resets options in all menus to their FACTORY RESET default values SMART Board 8084i-G4-SMP interactive flat panel on-screen display menu...
  • Page 83 APPENDIX A USING THE ON-SCREEN DISPLAY MENU Option Values Function Notes (if any) Contrast 0–100 Sets the brightness of the image in relation to the background 0–100 Sets the overall brightness of the Alternatively, you can press the Brightness image and background BRIGHTNESS buttons on the remote control.
  • Page 84 APPENDIX A USING THE ON-SCREEN DISPLAY MENU Option Values Function Notes (if any) MPEG Noise Sets MPEG image noise reduction Reduction Medium High High Sets the level of brightness in the Black Level darkest parts of the image LED Local Dimming Sets the level of LED local dimming to reduce brightness in the darkest Medium...
  • Page 85 APPENDIX A USING THE ON-SCREEN DISPLAY MENU Option Values Function Notes (if any) 300 Hz -10–10 Sets the sound equalization at You can modify this option only if 300 Hz you select User Setting in Sound Mode . 1 kHz -10–10 Sets the sound equalization at You can modify this option only if 1 kHz...
  • Page 86 APPENDIX A USING THE ON-SCREEN DISPLAY MENU Option Values Function Notes (if any) Audio Input Audio In 1 HDMI3/PC Specifies a video input to map to The video input you select must be AUDIO1 or disables AUDIO1 unique for AUDIO1. HDMI1 HDMI2 DPORT...
  • Page 87 APPENDIX A USING THE ON-SCREEN DISPLAY MENU Option Values Function Notes (if any) Month Jan.–Dec. Specifies the current month Year 2010–2040 Specifies the current year Hour 00–23 Specifies the current hour 00–59 Specifies the current minute Minute Off Time [N/A] Enables you to schedule times You must set the current time using the Clock menu to schedule off...
  • Page 88 APPENDIX A USING THE ON-SCREEN DISPLAY MENU Option Values Function Notes (if any) Input2 Specifies the second video input for You can modify this option only if fail over mode you select Manual in Mode . HDMI1 DVI-D Display Port HDMI2 HDMI3/PC Specifies the third video input for...
  • Page 89 DVI-D DPORT Disable Reset Resets options in all menus to their Lync® Room Reset default values (for a Cancel SMART Room System for Microsoft Lync) Enabled Enables or disables Consumer Electronics Control (CEC) support Disable on HDMI inputs FBC Control Enables or disables the front...
  • Page 90 [N/A] Shows the interactive flat panel’s This option only provides serial number information. You’re unable to modify it. Customer Service Center [N/A] Provides information on how to This option only provides contact SMART Support information. You’re unable to modify it. smarttech.com/kb/170446...

  • Page 91: Appendix B: Remotely Managing Your Interactive Flat Panel

    Decreasing a value for a setting Designating video control settings for a specific video input Identifying the value for a video control setting Assigning a value for a video control setting SMART Board 8070i-G4-SMP interactive flat panel commands Power state Source Video control...

  • Page 92: Connecting And Configuring A Room Control System

    APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Connecting and configuring a room control system Connect a computer to the room control input on the interactive flat panel to remotely select video inputs, turn on or turn off the interactive flat panel and request information such as contrast, power state and current settings.

  • Page 93: Power Modes

    All commands are available when the interactive flat panel is on. Some commands are available when the interactive flat panel is in Standby mode. No commands are available when the interactive flat panel is off or in ECO Standby mode. SMART Board 8070i-G4-SMP interactive flat panels only smarttech.com/kb/170446...

  • Page 94: Room Control System Programming Commands And Responses

    APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Room control system programming commands and responses To access interactive flat panel information or to adjust interactive flat panel settings using the room control system, type commands after the command prompt (>), and then wait for the response from the interactive flat panel.

  • Page 95: Assigning A Specific Value

    APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Assigning a specific value You can assign a specific value for a setting within the command’s target range. In the example below, the user wants to set the contrast level for the interactive flat panel to 65. >set contrast=65 contrast=65 Increasing a value for a setting...

  • Page 96: Smart Board 8070I-G4-Smp Interactive Flat Panel Commands

    70 for the HDMI1 video input. >set contrast HDMI1=70 contrast HDMI1=70 SMART Board 8070i-G4-SMP interactive flat panel commands The following tables contain commands for SMART Board 8070i-G4-SMP interactive flat panels. Power state Use the following commands to identify power state settings. Command Response...

  • Page 97: Source

    APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Source Use the following commands to identify source settings. Command Response Possible values Standby mode input= [Value] get input VGA1 VGA2 Video S_Video DVD/HD DisplayPort HDMI1 HDMI2 HDMI3/PC videoinputs= [Value] get videoinputs VGA1 VGA2 Video...

  • Page 98: Video Control

    APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Use the following commands to assign source settings. Command Possible values Response Standby mode set input [Value] =VGA1 input= [Value] =VGA2 =DVI =Video =S_Video =DVD/HD =DisplayPort =HDMI1 =HDMI2 =HDMI3/PC set usb1source [Value] =VGA1 usb1source= [Value] =VGA2...
  • Page 99 APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Command Response Possible values Standby mode get contrast contrast= [Value] 0–100 get displaymode displaymode= [Value] DYNAMIC STANDARD sRGB CINEMA SPORT GAME USER AMBIENT get saturation saturation= [Value] 0–100 get sharpness sharpness= [Value] 0–100 tint= [Value] get tint...

  • Page 100: Audio Control

    APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Command Possible values Response Standby mode set displaymode [Value] =DYNAMIC displaymode= [Value] =STANDARD =sRGB =CINEMA =SPORT =GAME =USER =AMBIENT set saturation [Value] + [Incremental value] saturation= [Value] - [Incremental value] =0–100 set sharpness [Value] + [Incremental value] sharpness= [Value] - [Incremental value]...
  • Page 101 APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Use the following commands to assign audio control settings. Command Possible values Response Standby mode set audioinput [Value] =IN1 audioinput= [Value] =IN2 =IN3 =USB =HDMI =DPORT =HDMI3/PC_ANALOG =HDMI3/PC_DIGITAL set balance [Value] + [Incremental value] balance= [Value] - [Incremental value] =0–100...

  • Page 102: System Information

    APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL System information Use the following commands to identify system information settings. Command Response Possible values Standby mode aspectratio= [Value] get aspectratio 16:9 zoom1 zoom2 autopoweroff= [Value] get autopoweroff 15–240 get fwinfotouch fwinfotouch= [Value] [User defined value] get fwvericp fwvericp= [Value]...
  • Page 103 APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Command Response Possible values Standby mode get readystatebrightness readystatebrightness= [Value] 0–100 get resolution resolution= [Value] 800 × 600 1024 × 768 get serialnum serialnum= [Value] [Serial number] get tempsensor1 tempsensor1= [Value] [Temperature in ºC] get tempsensor2 tempsensor2= [Value] [Temperature in ºC]...
  • Page 104 APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Command Possible values Response Standby mode set language [Value] =English language= [Value] =Arabic =Danish =German =English_UK =Spanish =Spanish_MEX =French =Hindi =Hungarian =Italian =Korean =Dutch =Norwegian =Portuguese_BRA =Portuguese =Russian =Swedish =Turkish =Chinese =Chinese_SIM set monitorid [Value] + [Incremental value] monitorid= [Value]...

  • Page 105: Smart Board 8084I-G4-Smp Interactive Flat Panel Commands

    [Value] =normal set fancontrol [Value] fancontrol= [Value] =auto SMART Board 8084i-G4-SMP interactive flat panel commands The following tables contain commands for SMART Board 8084i-G4-SMP interactive flat panels. Power state Use the following commands to identify power state settings. Command Response Possible values Standby...

  • Page 106: Source

    APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Use the following commands to assign power state settings. Command Possible values Response Standby mode set intpowerstate [Value] =standby intpowerstate= [Value] =no-video =welcome =prox-reenable-wait =pre-eco =eco-standby =soft-reset =dpms =pre-standby-auto set powerstate [Value] powerstate= [Value] =standby =off...
  • Page 107 APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Command Response Possible values Standby mode get usb2source usb2source= [Value] VGA (default) DPort HDMI1 HDMI2 HDMI3/PC Disable usb3source= [Value] get usb3source DPort HDMI1 (default) HDMI2 HDMI3/PC Disable Use the following commands to assign source settings. Command Possible values Response...

  • Page 108: Video Control

    APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL NOTE You must specify unique values for set ubs1source, set usb2source and set usb3source. Video control Use the following commands to identify video control settings. Command Response Possible values Standby mode get ambient ambient= [Value] 0–1023 blacklevel= [Value]...
  • Page 109 APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Command Possible values Response Standby mode set brightness [Value] + [Incremental value] brightness= [Value] - [Incremental value] =0–100 set brightness [Video input] [Value] + [Incremental value] brightness [Video input] = [Value] - [Incremental value] =0–100 set colortemp [Value] + [Incremental value]...

  • Page 110: Audio Control

    APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Audio control Use the following commands to identify audio control settings. Command Response Possible values Standby mode audioeq100= [Value] get audioeq100 -10–10 get audioeq300 audioeq300= [Value] -10–10 get audioeq1k audioeq1k= [Value] -10–10 get audioeq3k audioeq3k= [Value] -10–10...
  • Page 111 APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Command Response Possible values Standby mode get opsaudio opsaudio= [Value] digital analog rightspeaker= [Value] get rightspeaker get speakersw speakersw= [Value] internal external get usbaudio usbaudio= [Value] DPort HDMI1 HDMI2 HDMI3/PC Disable get volume volume= [Value] 0–100 Use the following commands to assign audio control settings.
  • Page 112 APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Command Possible values Response Standby mode set audioin2 [Value] =VGA audioin2= [Value] =DVI =Component =Composite =DPort =HDMI1 =HDMI2 =HDMI3/PC =Disable set audioin3 [Value] =VGA audioin3= [Value] =DVI =Component =Composite =DPort =HDMI1 =HDMI2 =HDMI3/PC =Disable set balance [Value]...

  • Page 113: System Information

    APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL NOTE You must specify unique values for set audioin1, set audioin2, set audioin3 and set usbaudio. System information Use the following commands to identify system information settings. Command Response Possible values Standby mode get aspectratio aspectratio= [Value]...
  • Page 114 APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Command Response Possible values Standby mode get language language= [Value] Arabic Chinese (Simplified) Danish Dutch English (UK) English (US) Finnish French French (Canada) German Hungarian Italian Japanese Korean Norwegian Portuguese (Brazil) Portuguese (Portugal) Russian Spanish Spanish (Mexico)
  • Page 115 APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Use the following commands to assign system information settings. Command Possible values Response Standby mode set aspectratio [Value] =justscan aspectratio= [Value] =16:9 =4:3 set autopoweroff [Value] + [Incremental value] autopoweroff= [Value] - [Incremental value] =15–240 set factoryreset [Value] factoryreset= [Value]...

  • Page 116: Service Information

    APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Command Possible values Response Standby mode set opsfail [Value] opsfail= [Value] =off set proximity [Value] proximity= [Value] =off set proximitydetected [Value] =yes proximitydetected= [Value] set proximityreenable [Value] proximityreenable= [Value] =1–10 set readystatebrightness [Value] =0–100 readystatebrightness= [Value] set testmode [Value]...
  • Page 117 APPENDIX B REMOTELY MANAGING YOUR INTERACTIVE FLAT PANEL Use the following commands to assign service information settings. Command Possible values Response Standby mode set failurelog [Value] =normal failurelog= [Value] set statereporting [Value] statereporting= [Value] =off smarttech.com/kb/170446...

  • Page 119: Appendix C: Hardware Environmental Compliance

    Appendix C Hardware environmental compliance SMART Technologies supports global efforts to ensure that electronic equipment is manufactured, sold and disposed of in a safe and environmentally friendly manner. Waste Electrical and Electronic Equipment and Battery regulations (WEEE and Battery Directives) Electrical and electronic equipment and batteries contain substances that can be harmful to the environment and to human health.

  • Page 121: Index

    Index reflective tape 51 screen 50 Clear Voice II 77 AAA batteries 49 color select module 6 air conditioning 15, 52 color temperature 68, 75, 90, 100 ambient lighting 69, 100 component video 19-20, 89, 98 aspect ratio 5, 70, 76, 94, 105 composite video 19-20, 89, 98 audio computer See room computer...
  • Page 122 14 gates 15 location for mounting your interactive flat gestures 2 panel 15 glass cleaner 50 GoWire See SMART GoWire cable M8 screws 15 maintenance 45 hardware installation 13, 53 markers 50 hardware removal 53 menu control panel 43...
  • Page 123 35 Picture Wizard II 76 using on the room computer 34 power 15, 21, 27, 31, 85, 88, 97 SMART Meeting Pro PE software 36 presence detection sensors SMART Meeting Pro software about 2, 5, 33 about 3...
  • Page 124 INDEX top connector panel 18, 20 training 11 transportation 54 treble 70, 92 TruMotion 76 updates firmware 46 software 46 USB cables and connectors 19, 21-22, 71, 73, 81, 89, 98 USB devices connecting 34 disabling the receptacle for 24 vacuum cleaners 52 ventilation 15, 52 VESA mounting plate 14...
  • Page 126 SMART TECHNOLOGIES smarttech.com/support smarttech.com/contactsupport smarttech.com/kb/170446...

Table of Contents
