SMART Board
880i5-SMP and 885i5-SMP
®
interactive whiteboard system
For cautions, warnings and other important product information see Important
Information for SMART Board
800i5-SMP interactive whiteboard system
®
.
users (smarttech.com/kb/131396)

Advertisement

loading
Need help?

Need help?

Do you have a question about the 880i5-SMP and is the answer not in the manual?

Questions and answers

Related Manuals for SMART 880i5-SMP

Summary of Contents for SMART 880i5-SMP

  • Page 1 SMART Board 880i5-SMP and 885i5-SMP ® interactive whiteboard system For cautions, warnings and other important product information see Important Information for SMART Board 800i5-SMP interactive whiteboard system ® users (smarttech.com/kb/131396)
  • Page 2 1016935...
  • Page 3 í kami a st ny s ur itého druhu zdiva. V p ípad , že pot ebujete nainstalovat váš produkt SMART na st ny ze železobetonu, st ny ze sádrokartonu, st ny neobvyklé konstrukce a jiné druhy st n, obra te se na váš místní...
  • Page 4 Au cas où vous deviez installer votre produit SMART sur un mur en béton armé, sur un mur de lattis, sur un mur de structure inhabituelle ou un autre type de mur, consultez votre service de l'urbanisme pour qu'il vous fournisse des instructions, des recommandations et vous dise comment travailler en toute sécurité.
  • Page 5 Seu produto SMART inclui instruções e peças para instalação em paredes de metal e viga de madeira e somente em determinados tipos de parede de alvenaria.
  • Page 6 SMART Board 880i5-SMP and 885i5-SMP interactive whiteboard system SB880/SB885 Standard cable connections SMART UX60 projector connection panel Guest laptop Dedicated in-room computer SMART UX60 projector VGA 2 Internal VGA 1 cameras (×4) SB885 Pen tray SBX800 CAT5-XT SB800 CAT5-XT Back view of pen tray SB880 a (×2)
  • Page 7 SMART UF75/UF75w projector system 94” 77” " 87” 64” " " " CR-2025 Vol. e (×2) f (×7) g (×7) h (×7) k (×3) m (×2) (×2) q (×7) n (×1) ×2 3/32" (2.5 mm) 7/32" (5 mm) 1/4" (6 mm) 1/2"...
  • Page 8 NOTES 1016935...
  • Page 9 1016935...
  • Page 10 Support +1.403.228.5940 or Toll Free 1.866.518.6791 (U.S./Canada) © 2010–2011 SMART Technologies ULC. All rights reserved. The SMART logo, smarttech and all SMART taglines are trademarks or registered trademarks of SMART Technologies ULC in the U.S. and/or other countries. All third-party product and company names may be trademarks of their respective owners.
  • Page 11 Toutes les lignes que vous tracez pour installer le SB800i5 doivent être droites et horizontales sur un mur vertical. Vous devez installer l'unité bien droite et d'aplomb pour qu'elle fonctionne correctement. Tutte le linee tracciate per installare l’SB800i5 devono essere dritte e in pari e disegnate su una parete a piombo.
  • Page 12 ≥ 50" ≥ 50" (127 cm) (127 cm) ≥ 50" (127 cm) 78 1/2" (199 cm) 1016935...
  • Page 13 1/2" (13 mm) q (×4) 1016935...
  • Page 14 1/4" (6 mm) 1/2" (13 mm) q (×7) If you have a metal stud wall, drill the holes twice according to these instructions. estli e máte kovové p í ky, vyvrtejte díry dvakrát dle tohoto návodu. Hvis du har en væg med metalstolper, skal der bores huller, som er dobbelt så store som angivet i disse instruktioner. Wenn Sie eine Metallständerwand haben, bohren Sie die Löcher dieser Anleitung gemäß...
  • Page 15 1 3/4" (45 mm) 1/4" (6 mm) f (×7) h (×2) h (×3) g (×3) k (×1) 1/4" (6 mm) 1016935...
  • Page 16 NOTES 1016935...
  • Page 17 94” 77” 87” 64” 1016935...
  • Page 18 h (×2) k (×2) h (×4) g (×4) 1016935...
  • Page 19 1016935...
  • Page 20 2× m (×2) " " " " SB880 2× " " " SB885 " SB880 SB885 1016935...
  • Page 21 n (×1) 1016935...
  • Page 22 NOTES 1016935...
  • Page 23 1016935...
  • Page 24 SB880 ×1 ×1 c (×5) y (×5) d (×5) z (×5) SB885 ×2 ×2 c (×10) y (×10) d (×10) z (×10) SB885 SB880 4″ (10.2 cm) 1016935...
  • Page 25 c (×5/×10 5×/10× 1/4" (8 mm) y (×5/×10) d (×5/×10) z (×5/×10) 1016935...
  • Page 26 4× 1016935...
  • Page 27 1016935...
  • Page 28 RJ-45 SB880 SB885 1016935...
  • Page 29 smarttech.com/kb/142552 p (×2) r (×2) 1016935...
  • Page 30 ×2 SB880 SB885 1016935...
  • Page 31 2× 1/4" (6mm) a (×2) y (×2) b (×2) z (×2) 1016935...
  • Page 32 Input Menu Hide Display Mode Mute 1016935...
  • Page 33 4× 4× 1016935...
  • Page 34 1016935...
  • Page 35 7/32" (5 mm) 1016935...
  • Page 36 2× 2× 1016935...
  • Page 37 1016935...
  • Page 38 SMART Board™ X885i5 interactive whiteboard system User’s guide RJ-45 1016935...
  • Page 39 1016935...

  • Page 40: Hardware Environmental Compliance

    There are special regulations that must be met when shipping a product that has a lithium ion battery packaged with the product or shipping a lithium ion battery. When returning a SMART Technologies product which contains a lithium ion battery or returning a lithium ion battery, call SMART Technologies RMA for information on these special shipping regulations: 1.866.518.6791, Option 4 (U.S./Canada)
