Product registration number

Open the wood-burning stove door; you can then read, and make a
note of, the product registration number (see front).
Product registration number
Accessories
• Shaped floor plate in steel or glass (N/A for the Scan 53 wall-
hung model)
• Glass top plate
• Front shelf in glass, steel or stainless steel
• Fresh-air box, external combustion air (N/A for the Scan 53 wall-
hung model)
• Fresh-air connection piece
A S S E M B LY
Scan 53
527
Scan 53 wall-hung model
527
5
517
* Centre rear outlet
** Height to the beginning
of the flue pipe at top
outlet
*** Centre fresh air intake
568
* Centre rear outlet
** Height to the beginning
of the flue pipe at top
outlet
*** Centre fresh air intake
****Minimum clearance
above flammable mate
rial
