Summary of Contents for Sartorius PMA series
- Page 1 98648-008- 1 3 Sartorius PMA Models Electronic Paint-mixing Scale for Hazardous Areas/Locations Installation Instructions and Safety Information...
-
Page 2: Table Of Contents
Contents Intended Use Warning and Safety Information Getting Started Storage and Shipping Conditions Unpacking the Scale Warranty Equipment Supplied Installation Instructions Conditioning the Scale Seal on Scales Verified for Use in Legal Metrology in the EU Connecting the Scale to AC Power 11 Setting up the Scale Care and Maintenance Service... -
Page 3: Intended Use
Intended Use The PMA7500.. or PMA 35..Series Built-in application programs EX-approved scales from Sartorius meet can be used for: all requirements for fast and reliable – Measuring in two weight units paint mixing. The scale housing – Recalculation is solvent-resistant. -
Page 4: Warning And Safety Information
Certificate KEMA 98ATEX2771 X). country. The explosion-protected equipment Before you operate your scale in of the PMA Series meets the currently a hazardous area/location, the scale valid harmonized European standards must be inspected either by a certified in compliance with CENELEC:... - Page 5 PVC materials. Chemicals that corrode these materials must be kept away from these cables. ! Use only cabling and extensions approved by Sartorius, as these are made in accordance with the restrictions on cable lengths imposed by the capacitance and inductivity values (see the attached certificate of conformity) and the requirements for electromagnetic compatibility.
- Page 6 Warning: ! Any tampering with this scale by anyone other than persons authorized by Sartorius will result in forfeiture of the approval for use in the stated hazardous area/location and of all claims under the manufacturer’s warranty.
-
Page 7: Getting Started
Do not miss out on the benefits of our full warranty. Please contact your local Sartorius office or dealer for further information. If available, complete the warranty registration card, indicating the date of installation, and return the card to your Sartorius office or dealer. -
Page 8: Equipment Supplied
– AC adapter or power supply 03stanex.eps Installation Instructions The Sartorius PMA scales are designed to provide reliable weighing results under normal ambient conditions. When choosing a location to set up your scale, observe the following so that you will be able to work with added speed and accuracy: –... -
Page 9: Conditioning The Scale
EU legislation requires that a control seal be affixed to the verified scale. The control seal consists of a sticker with the “Sartorius” logo. This seal will be irreparably damaged if you attempt to remove it. If the seal is broken, the validity of verification will become void and you must have your scale re-verified. -
Page 10: Connecting The Scale To Ac Power
Connecting the Scale to AC Power Check the voltage rating and the plug design – If they do not match the rating or standard you use, contact your Sartorius office or dealer ! Use only original Sartorius AC adapters or power supplies (outside the hazardous area/location): –... -
Page 11: Setting Up The Scale
Ground the scale inside the hazardous area/ location. Connect the cable to the equipotential bonding terminal. ! Before operating the equipment, connect the following devices to a central equipotential busbar: – Scale – Zener barrier ! Installation must be carried out by 02a.eps a certified electrician working in accordance with acknowledged technical regulations. -
Page 12: Care And Maintenance
Care and Maintenance Service Regular servicing by a Sartorius technician will extend the service life of your scale and ensure its continued weighing accuracy. Sartorius can offer you service contracts with your choice of regular maintenance intervals ranging from 1 month to 2 years. -
Page 13: Safety Inspection
– the equipment has been exposed to rough handling during shipment In this case, notify your nearest Sartorius Service Center or the International Technical Support Unit based in Goettingen, Germany. Maintenance and repair work may only be performed by service technicians who are authorized by Sartorius and who –... - Page 14 All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior written permission of Sartorius AG. The status of the information, specifications and illustrations in this manual is indicated by the date given below.
