SPECIAL MODE

Special mode setting button

b Press the ON/STANDBY button to turn on while pressing both buttons A and B at the same time.
Mode
µcom/DSP Version display mode
Errors checking mode
(Displaying the protection history)
Initialization mode
Mode for switching tuner frequency step DINAMIC EQ
Mode for preventing remote control
acceptance
Panel lock mode
Panel lock mode
(Remove Master volume)
Cancellation of panel lock mode
NOTE:
If " S " is displayed on the fluorescent display, the unit is set to the special developer's mode and RS-232C
communications are not possible.
Press and hold in the "STATUS" and " i " buttons for over 3 seconds with the power turned on to turn the " S "
display off. RS-232C communications are now enabled.
ON/STANDBY
Button A Button B
STATUS DIMMER
STATUS MULTEQ
SURROUND SURROUND
MODE 0 MODE 1
DINAMIC
VOLUME
DINAMIC
RETURN
VOLUME
DINAMIC EQ ENTER
DINAMIC EQ CURSOR 1
DINAMIC EQ RETURN
DINAMIC VOLUME
DINAMIC EQ
ENTER
CURSOR 1
15
Contents
Firmware versions such as Main, Sub, DSP are displayed in
the FL manager. Errors are displayed when they occur.
(Refer to 16 page.)
Displaying the protection history
(Refer to 18 page.)
Backup data initialization is carried out.
(Refer to 5 page.)
---E2 model only---
Select with the SOURCE 0 d 1 f button.
Change tuner frequency step to AM9k/FM50kHz STEP or
AM:10k/FM:200kHz.
Operations using remote control are rejected.
(Mode cancellation: Turn off power and execute the same
button operations as when performing setup.)
Operations using main unit panel buttons or master volume are
rejected.
Operations using main unit panel buttons are rejected.
Panel lock mode is cancelled.
DIMMER
MULTEQ STATUS
RETURN
SURROUND MODE 0 1
