Denon AVR-2311CI Service Manual page 119

Ref.No. Part No. Part Name
15 963412000560D KNOB VOLUME(KD)
15 412510002038D KNOB VOLUME
16 963411003370D BUTTON 1KEY
16-1 963411003770D BUTTON 1KEY
16 963412003670D BUTTON 1KEY
17 963411003380D BUTTON CURSOR 5KEY
17 963411003680D BUTTON CURSOR 5KEY
18 00D9630364700 BUTTON 3KEY
18 00D9630364906 BUTTON 3KEY
18-1 963411001410D BUTTON 3KEY B
18-1 963411011340D BUTTON 3KEY B
18-2 963411001400D BUTTON 3KEY A
19 00D9630365002 BUTTON WIN 3KEY
19 00D9630365301 BUTTON WIN 3KEY
20 963411003400D BUTTON WIN 3KEY C
20 963411003690D BUTTON WIN 3KEY C
28 nsp HEAT SINK MAIN
32 nsp BRACKET H SINK
40 nsp CUSHION FOOT
41 963407003330D FOOT
42 nsp CHASSIS MAIN
43 nsp SUPPORTER PCB
44 nsp BRACKET SIDE
45 nsp SUPPORTER P.C.
46 963101009710S POWER TRANS MAIN
z
46 963101009720S POWER TRANS MAIN
z
46 963101009730S POWER TRANS MAIN
z
61 nsp SPACER CARD
70 nsp CHASSIS BACK
70 nsp CHASSIS BACK
70 nsp CHASSIS BACK
70 nsp CHASSIS BACK
70 nsp CHASSIS BACK
71 nsp BRACKET SMPS
72 nsp BRACKET HDMI
73 nsp BRACKET HEATSINK MAIN
74 nsp SUPPORTER PCB
76 963403011680D CABINET TOP
76 963403011690D CABINET TOP
77 963454001800D COVER HOLDER
77 963454001810D COVER HOLDER
78 963419011370D COVER SAFETY
78 963419011360D COVER SAFETY
82 nsp CUSHION SCREW
83 nsp CUSHION TOP
84 nsp CUSHION BRACKET
★ 85 nsp CLAMP CABLE
86 nsp PLATE EARTH USB
★ 87 963606010490S CABLE,FLAT CARD 1.0MM
★ 88 963606011210S CABLE,FLAT CARD 1.25MM
91 963183011000S HD-RADIO MODULE
★ 92 00D9630235204 TR 2SB1647Y
Remarks Q'ty New
BK 5080211751000SZ 1
SP 5087211891000S 1
2311CIBKE3,2311BKE2 5097213791000S 1
891BKE3,891BKEA 5097213801000S 1
2311SPE2,2311SPE1C 5097213791100S 1
BK 5097213811000S 1
SP 5097213811100S 1
2311CIBKE3,2311BKE2 5097213331000S 1
2311SPE2,2311SPE1C 5097213331110S 1
BK 5097213611000S 1
SP 5097213611100S 1
891BKE3,891BKEA 5097213601000S 1
BK 5097213371000S 2
SP 5097213371110S 2
BK 5097213831000S 1
SP 5097213831100S 1
2120211788000S 1
4010056906010S 5
4050211295000S 4
4000210261000S 4
3200213506000S 1
4070001601010S 3
4010210686000S 1
4070210192000S 2
2311CIBKE3,891BKE3 8200960660660S 1 *
2311BKE2,2311SPE2,
8200960660670S 1 *
891BKEA
2311SPE1C 8200960660680S 1 *
4300210062000S 1
2311CIBKE3 3207213516000S 1 *
891BKE3 3207213516100S 1 *
891BKEA 3207213516110S 1 *
2311BKE2/SPE2 3207213516200S 1 *
2311SPE1C 3207213516300S 1 *
4010214886000S 1
4010214896000S 1 *
4010214906000S 1 *
4070211653000S 1
BK 3000211736400S 1 *
SP 3000211736500S 1 *
2311BKE2,891BKEA 4310213701000S 6
2311SPE2,2311SPE1C 4310213701100S 6
2311BKE2,891BKEA 4310215202100S 1
2311SPE2,2311SPE1C 4310215202000S 1
4050213025000S 4
4050213155000S 1
4050213165000S 1 *
4330040343010S 8
4470211946000S 1
N711402912480S 1
2311CIBKE3 N712130824480S 1
2311CIBKE3 E908071010000S 1
Q410,422,434,446,458,
J5011647Y0170S 7
470,482
Ref.No. Part No.
★ 93 963219003340S TR 2SC KTC3964
★ 94 00D9630235301 TR 2SD2560Y
★ 95 nsp ACETATE CLOTH TAPE
★ 96 nsp INLET TAPE
SCREWS
A nsp SCREW (+2S 3*8 B-TYPE ZNW/BH)
C nsp SCREW (+2S 3*15 B-TYPE ZNW/BH)
D nsp SCREW (+2S 3*10 B-TYPE(DOT) BK/BH)
D nsp SCREW (+2S 3*10 B-TYPE(DOT) BK/BH)
D nsp SCREW (+2S 3*10 B-TYPE(DOT) BK/BH)
E nsp SCREW 2S 3*14 P(Φ6)+S-WASHER ZNY/HH)
F nsp SCREW (+2S 3*17 B-TYPE ZNW/BH)
G 00D9630048307 SCREW (+2S 4*8 B-TYPE(DOT) BK/BH)
G 00D9630048307 SCREW (+2S 4*8 B-TYPE(DOT) BK/BH)
G 00D9639004012 SCREW (+2S 4*8 B-TYPE(DOT) NI/BH)
H nsp SCREW (+3S 4*10 P+S-WASHER(ROUND)BK/BH)
I nsp SCREW (+2S 3*8 ZnY WASHER PI12)
P nsp SCREW (+2S 3*8 PI9.5 B-TYPE ZNW)
Q nsp SCREW (+M 3*6 BK/BH)
T nsp SCREW (+2S 3*8(ROUND) BK/BH)
U nsp SCREW (+2S 3*10 (BK/FH))
V nsp SCREW (+2S 3* B-TYPE(DOT) BK/BH)
119
Part Name Remarks
Q409,421,433,445,457,
J502396400010S
469,481
Q404,416,428,440,452,
J5032560Y0170S
464,476
2311CIBKE3 1220210059010S
1220210759000S
B020030081B10S
B020030151B10S
891BKE3,891BKEA B020030103B11S
2311BKE2,2311SPE2,
B020030103B11S
2311SPE1C
2311CIBKE3 B020030103B11S
B018230141H11S
B020030171B10S
for INLET 1500040083B10S
BK : for CABINET TOP 1500040083B10S
SP : for CABINET TOP 1500040084B10S
B028940101B11S
1500001456010S
1500001206010S
B000030063B10S
B020230083B10S
B020030103F10S
2311CIE3 B020930063B10S
Q'ty New
7
7
2
1
23
1
39
40
37
21
3
2
6
6
4
1
2
7
48
2
2
