IS42S32200E6TL Terminl Function

Pin No. Signal
1 VDD
2 DATA28
3 DATA27
4 GND
5 IOVDD
6 DATA26
7 DATA25
8 DATA24
9 DATA23
10 GND
11 VDD
12 DATA22
13 DATA21
14 DATA20
15 IOVDD
16 GND
17 DATA19
18 DATA18
19 VDD
20 GND
21 DATA17
22 VDD
23 GND
24 VDD
25 GND
26 DATA16
27 DATA15
28 DATA14
29 DATA13
30 DATA12
31 IOVDD
32 GND
33 VDD
34 GND
35 DATA11
36 DATA10
37 DATA9
38 DATA8
39 DATA7
40 DATA6
41 IOVDD
42 GND
43 VDD
44 DATA4
45 DATA5
46 DATA2
47 DATA3
48 DATA0
49 DATA1
50 IOVDD
51 GND
52 VDD
Pin No. Signal
53 VDD
54 GND
55 IOVDD
56 ADDR0
57 ADDR2
58 ADDR1
59 ADDR4
60 ADDR3
61 ADDR5
62 GND
63 VDD
64 GND
65 IOVDD
66 ADDR6
67 ADDR7
68 ADDR8
69 ADDR9
70 ADDR10
71 GND
72 VDD
73 GND
74 IOVDD
75 ADDR11
76 ADDR12
77 ADDR13
78 GND
79 VDD
80 AVSS
81 AVDD
82 GND
83 CLKIN
84 XTAL2
85 IOVDD
86 GND
87 VDD
88 ADDR14
89 GND
90 IOVDD
91 ADDR15
92 ADDR16
93 ADDR17
94 ADDR18
95 GND
96 IOVDD
97 ADDR19
98 ADDR20
99 ADDR21
100 ADDR23
101 ADDR22
102 MS1
103 MS0
104 VDD
131
Pin No. Signal
105 VDD
106 GND
107 IOVDD
108 SDCAS
109 SDRAS
110 SDCKE
111 SDWE
112 WR
113 SDA10
114 GND
115 IOVDD
116 SDCLK0
117 GND
118 VDD
119 RD
120 ACK
121 FLAG3
122 FLAG2
123 FLAG1
124 FLAG0
125 DAI20
126 GND
127 VDD
128 GND
129 IOVDD
130 DAI19
131 DAI18
132 DAI17
133 DAI16
134 DAI15
135 DAI14
136 DAI13
137 DAI12
138 VDD
139 IOVDD
140 GND
141 VDD
142 GND
143 DAI11
144 DAI10
145 DAI8
146 DAI9
147 DAI6
148 DAI7
149 DAI5
150 IOVDD
151 GND
152 VDD
153 GND
154 VDD
155 GND
156 VDD
Pin No. Signal
157 VDD
158 VDD
159 GND
160 VDD
161 VDD
162 VDD
163 TDI
164 TRST
165 TCK
166 GND
167 VDD
168 TMS
169 CLK_CFG0
170 BOOTCFG0
171 CLK_CFG1
172 EMU
173 BOOTCFG1
174 TDO
175 DAI4
176 DAI2
177 DAI3
178 DAI1
179 IOVDD
180 GND
181 VDD
182 GND
183 DPI14
184 DPI13
185 DPI12
186 DPI11
187 DPI10
188 DPI9
189 DPI8
190 DPI7
191 IOVDD
192 GND
193 VDD
194 GND
195 DPI6
196 DPI5
197 DPI4
198 DPI3
199 DPI1
200 DPI2
201 CLKOUT
202 RESET
203 IOVDD
204 GND
205 DATA30
206 DATA31
207 DATA29
208 VDD
