Instruction Manual
5. Install and secure the retract gear into the wing.
6. Secure the wheel.
Screw
7. Secure the wheel cover.
Screw
25
26
Screw
27
Screw
28
SBD DAUNTLESS
8. Install the adjustable servo connector to the
servo arm of the servo retract gear.
Retract and the gear is opened.
6
29
30
