Contents
iv
Chapter 2: Installation
Overview ................................................................................................. 9
Maximum 6800+ Frame Power Ratings ............................................... 10
Unpacking the Module .......................................................................... 11
Preparing the Product for Installation ............................................ 11
Checking the Packing List ............................................................. 11
Setting Jumpers ..................................................................................... 12
Jumper J3 for Local or Remote Control ......................................... 12
Setting Jumper J1 for Genlock Source ........................................... 13
Setting Jumper P1 for Reclocking and IO_DELAY Output .......... 14
Installing 6800+ Modules ..................................................................... 15
Making Connections ............................................................................. 15
Removing 6800+ Modules .................................................................... 15
Chapter 3: Operation
Overview ............................................................................................... 17
Operating Notes ..................................................................................... 18
Cross-Functional Parameter Changes ............................................ 19
Changing Parameter Settings ................................................................ 20
Recalling Default Parameter Settings ............................................ 21
Reading Software and Hardware Versions .................................... 21
Setting ENC/ENS6800+ Control Parameters ....................................... 22
LEDs and Alarms .................................................................................. 30
Monitoring LEDs ........................................................................... 30
Module Status LEDs ...................................................................... 32
Alarms ............................................................................................ 33
Chapter 4: Specifications
Overview ............................................................................................... 35
Video Input ............................................................................................ 36
Serial Digital Video ....................................................................... 36
Reference Input .............................................................................. 36
Video Output ......................................................................................... 37
Composite Analog .......................................................................... 37
Serial Digital Video ....................................................................... 38
Data I/O Output .............................................................................. 38
Power Consumption .............................................................................. 38
Operating Temperature ......................................................................... 39
