6800/7000 Series Frame Back Connector (Overlay)
ENC/ENS6800+ Installation and Operation Manual
Figure 1-3 shows the double-slot back connector overlay used by the
ENC/ENS6800+ when installed in a 6800/7000 series frame.
Genlock 525
(Genlock 1)
SDI RCLK or
IO_DELAY
Figure 1-3. Back Connector Overlay for the 6800 Series Frame
Chapter 1: Introduction
SDI IN
Genlock 625
(Genlock 2)
SDI RLCK
COMPST VIDEO
(PAL- B/PAL-M/NTSC)
