Overview

Caution
Before installing this product,
read the 6800+ Series Safety
Instructions and Standards
Manual shipped with every
FR6802+ Frame Installation
and Operation Manual or
downloadable from
www.broadcast.harris.com/
leitch. This safety manual
contains important information
about the safe installation and
operation of 6800+ series
products.
ENC/ENS6800+ Installation and Operation Manual
This chapter describes the ENC/ENS6800+ installation process,
including the following topics:
• "Maximum 6800+ Frame Power Ratings" on page 10
• "Unpacking the Module" on page 11
• "Setting Jumpers" on page 12
• "Installing 6800+ Modules" on page 15
• "Making Connections" on page 15
• "Removing 6800+ Modules" on page 15
See the FR6802+ Frame Installation and Operation Manual for
information about installing and operating an FR6802+ frame and its
components.
See the 6800/7000 Series Frames and Power Supply Installation and
Operation Manual for information about installing and operating a
6800/7000 series frame.
Chapter 2
Installation
9
