Chapter 1: Introduction

Product Description

2
The ENC/ENS6800+ encoders and synchronizers are part of the 6800+
Series of processing and conversion modules that have the following
features:
ENC6800+
• Encoding of 4:2:2 digital video into a composite analog signal
• 12-bit digital internal processing; output over-sampled at 54 MHz
• Four composite outputs and two SDI reclocked outputs
• Automatic selection between NTSC, PAL-M and PAL-B standards,
with settings shadowed and restored
• Genlock input on module, or frame genlock to be used for reference
• Color-frame locking if used with external genlock
• Jitter removal
• EDH detection
• Vertical blanking field/line/mode control: lines 10 to 21
(NTSC/PAL-M), lines 6 to 23 (PAL-B)
• Adjustable level controls for luminance, chrominance, and black
• Adjustments for ±180 degrees chrominance phase
• SCH offset (0/180 for NTSC, 0/90/180/270 for PAL)
• Pedestal on/off selection (with starting line selection)
Full control support via +Pilot Lite
•
TM
CCS Pilot and CCS Navigator
ENS6800+
• Encoding of 4:2:2 digital video into a composite analog signal
• 12-bit digital internal processing; output over-sampled at 54 MHz
• Four composite outputs
• Two SDI reclocked outputs: one dedicated, one jumper-selectable
(for audio tracking signal with compatible audio synchronizers)
• Frame sync or delay modes
• Bypassable cross-color reduction with one-line delay
TM
(included) or optional
TM
(requires ICE6800+)
