ENC6800+ Composite Encoder and
ENS6800+ Composite Encoder Synchronizer
Installation and Operation Manual
Edition D
175-000147-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENC6800+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Harris ENC6800+

Summary of Contents for Harris ENC6800+

  • Page 1 ENC6800+ Composite Encoder and ENS6800+ Composite Encoder Synchronizer Installation and Operation Manual Edition D 175-000147-00...
  • Page 3 ENC6800+ Composite Encoder ENS6800+ Composite Encoder Synchronizer Installation and Operation Manual Edition D December 2005...

  • Page 4: Warranty Information

    RouterWORKS, Signal Quality Manager, SpyderWeb, SuiteView, TitleMotion, UNIFRAME, Velocity, VelocityHD, VideoCarte, Videotek, and X75 are trademarks of the Harris Corporation, which may be registered in the United States, Canada, and/or other countries. All other trademarks are the property of their respective owners.

  • Page 5: Table Of Contents

    Contents Preface Manual Information ................vii Purpose ................... vii Audience ..................vii Revision History ................vii Writing Conventions ..............viii Obtaining Documents ..............viii Unpacking/Shipping Information ............ix Unpacking a Product ............... ix Product Servicing ................ix Returning a Product ................ ix Restriction on Hazardous Substances (RoHS) Compliance ....x Waste from Electrical and Electronic Equipment (WEEE) Compliance xi Safety ....................
  • Page 6 Contents Chapter 2: Installation Overview ....................9 Maximum 6800+ Frame Power Ratings ..........10 Unpacking the Module ................11 Preparing the Product for Installation ..........11 Checking the Packing List ............. 11 Setting Jumpers ..................12 Jumper J3 for Local or Remote Control ......... 12 Setting Jumper J1 for Genlock Source ...........
  • Page 7 Contents Appendix A: Filters Composite Encoder Filter ..............41 NTSC/PAL-M Pass Filter ...............41 PAL-B Pass Filter ................42 Cross-Color Reduction Filter ..............43 Filter Summary ................43 Vertical High Pass Filter Frequency Response .......44 Horizontal High Pass Filters ............44 Appendix B: ENC/ENS6800+ Troubleshooting Overview ....................47 Genlock Issues ..................48 Output Issues ..................51 Appendix C: Communication and Control...
  • Page 8 Contents ENC/ENS6800+ Installation and Operation Manual...

  • Page 9: Preface

    Preface Manual Information Purpose This manual details the features, installation, operation, maintenance, and specifications for the ENC/ENS6800+ Composite Video Encoder Modules. Audience This manual is written for engineers, technicians, and operators responsible for installation, setup, maintenance, and/or operation of the ENC/ENS6800+ Composite Video Encoder Modules.

  • Page 10: Writing Conventions

    Note troubleshoot problems Obtaining Documents Product support documents can be viewed or downloaded from our Web site at www.broadcast.harris.com/leitch (go to Support > Documentation). Alternatively, contact your customer service representative to request a document. viii ENC/ENS6800+ Installation and Operation Manual...

  • Page 11: Unpacking/Shipping Information

    Preface Unpacking/Shipping Information Unpacking a Product This product was carefully inspected, tested, and calibrated before shipment to ensure years of stable and trouble-free service. 1. Check equipment for any visible damage that may have occurred during transit. 2. Confirm that you have received all items listed on the packing list. 3.

  • Page 12: Restriction On Hazardous Substances (Rohs) Compliance

    According to this EU Directive, all products sold in the European Union will be fully RoHS-compliant and “lead-free.” (See our Web site, www.broadcast.harris.com/leitch, for more information on dates and deadlines for compliance.) Spare parts supplied for the repair and upgrade of equipment sold before July 1, 2006 are exempt from the legislation.

  • Page 13: Waste From Electrical And Electronic Equipment (Weee) Compliance

    EU will affix labels indicating that such products must be properly recycled. (See our Web site, www.broadcast.harris.com/leitch, for more information on dates and deadlines for compliance.) Contact your local sales representative for information on returning these products for recycling. Equipment that complies with the EU directive will be marked with a WEEE-compliant emblem, as shown in Figure P-2.

  • Page 14: Safety

    Preface Safety Carefully review all safety precautions to avoid injury and prevent damage to this product or any products connected to it. If this product is rack-mountable, it should be mounted in an appropriate rack using the rack-mounting positions and rear support guides provided. It is recommended that each frame be connected to a separate electrical circuit for protection against circuit overloading.

  • Page 15: Overview

    Chapter 1 Introduction Overview The ENC/ENS6800+ SDI-to-NTSC/PAL-B encoders are compact modules for NTSC, PAL-B, and PAL-M encoding. Supporting 4:2:2 serial digital inputs, they may be used as either quality broadcast encoders or as monitoring encoders. The ENS6800+ also allows frame synchronization and cross-color reduction.

  • Page 16: Product Description

    Chapter 1: Introduction Product Description The ENC/ENS6800+ encoders and synchronizers are part of the 6800+ Series of processing and conversion modules that have the following features: ENC6800+ • Encoding of 4:2:2 digital video into a composite analog signal • 12-bit digital internal processing; output over-sampled at 54 MHz •...
  • Page 17 Chapter 1: Introduction • Automatic selection between NTSC, PAL-M and PAL-B standards, with settings shadowed and restored • Genlock input on module, or frame genlock to be used for reference • Selection between black, pass, or freeze when input signal is lost •...

  • Page 18: Module Descriptions

    Chapter 1: Introduction Module Descriptions Front Module Figure 1-1 is a generic top-front view of a typical 6800+ module and shows the general location of standard LEDs, controls, and jumpers. Remote/local control jumper Control Monitoring Module Mode select Navigation Extractor LEDs status toggle...
  • Page 19 Chapter 1: Introduction Table 1-1. Generic 6800+ Module Features Feature Description Module status Various color and lighting combinations of these LEDs LEDs indicate the module state. “Monitoring LEDs” in Chapter 3 for more information. Mode select This switch selects between various control parameters. rotary switch Navigation This switch navigates up and down through the available...

  • Page 20: Back Connector

    Chapter 1: Introduction Back Connector ENC/ENS6800+ Back Connector for FR6802+ Frame Figure 1-2 shows the double-slot back connector used by the ENC/ ENS6800+ when installed in an FR6802+ frame. SDI IN GENLOCK Genlock 1 Genlock 2 525 625 The RECLK SDI 1 RECLK can also serve as a DATA I/O output.
  • Page 21 Chapter 1: Introduction 6800/7000 Series Frame Back Connector (Overlay) Figure 1-3 shows the double-slot back connector overlay used by the ENC/ENS6800+ when installed in a 6800/7000 series frame. SDI IN Genlock 625 Genlock 525 (Genlock 2) (Genlock 1) SDI RLCK SDI RCLK or IO_DELAY COMPST VIDEO...

  • Page 22: Signal Flow

    Chapter 1: Introduction Signal Flow Figure 1-4 shows the signal flow for the ENC6800+ module, and Figure 1-5 shows the signal flow for the ENS6800+ module: outputs SDI input Composite Equalizer and Composite outputs deserializer encoder DAC NTSC reference input Front-edge CCS control/ Genlock...

  • Page 23: Overview

    “Installing 6800+ Modules” on page 15 and Operation Manual or downloadable from • “Making Connections” on page 15 www.broadcast.harris.com/ • “Removing 6800+ Modules” on page 15 leitch. This safety manual contains important information See the FR6802+ Frame Installation and Operation Manual for...

  • Page 24: Maximum 6800+ Frame Power Ratings

    Chapter 2: Installation Maximum 6800+ Frame Power Ratings The power consumption for the ENC6800+ module is 6.7 W and for the ENS6800+ is 7.5 W. Table 2-1 Table 2-2 describe the maximum allowable power ratings for 6800+ frames. Note the given maximums before installing any 6800+ modules in your frame.

  • Page 25: Unpacking The Module

    Chapter 2: Installation Unpacking the Module Preparing the Product for Installation Before you install the ENC/ENS6800+, perform the following: • Check the equipment for any visible damage that may have Note occurred during transit. • Confirm receipt of all items on the packing list. See “Checking the Contact your customer service representative if parts are...

  • Page 26: Setting Jumpers

    Chapter 2: Installation Setting Jumpers The ENC/ENS6800+ module has three jumpers that you need to set: • J3 (See “Jumper J3 for Local or Remote Control” on page • J1 (See “Setting Jumper J1 for Genlock Source” on page • P1 (See “Setting Jumper P1 for Reclocking and IO_DELAY Output”...

  • Page 27: Setting Jumper J1 For Genlock Source

    Chapter 2: Installation 2. Place a jumper on pins 1 and 2 to set the module for Remote control or pins 2 and 3 to set the module for Local control. See Figure 2-2. Local control setting Remote control setting Figure 2-2.

  • Page 28: Setting Jumper P1 For Reclocking And Io_Delay Output

    Chapter 2: Installation the FR6802+ frame genlock input. This is determined by the position of jumper J1 on the ENC6800+ or ENS6800+ module as shown in Figure 2-3. • Genlock 2 (labeled 625 on the rear module): If this setting is chosen, the genlock source will be taken from the Genlock 2 input of the rear module and is independent of the jumper J1 setting.

  • Page 29: Installing 6800+ Modules

    Chapter 2: Installation Installing 6800+ Modules There are two types of modules: Caution • Double-slot back connectors Before installing your modules, • Front modules see the Maximum 6800+ Frame Back connectors for this module come in the double-slot size. Up to ten Power Ratings chart at the front modules can fit in an FR6802+ frame if they are connected to beginning of this chapter.
  • Page 30 Chapter 2: Installation b. Pull the bottom lip of the back connector from its slot. c. Reinstall a new or blank back connector in the empty slot to Caution ensure proper frame ventilation. 5. Remove the back connector overlay from the back panel of a To prevent overheating during general frame operation and 6800/7000 series frame.

  • Page 31: Overview

    Chapter 3 Operation Overview This chapter describes how to operate the ENC/ENS6800+ using card-edge controls only. See the following documents for information on how to operate this product remotely: +Pilot Lite User Manual for serial interface • • CCS Pilot, CoPilot, Navigator, or RCP-CCS-1U Remote Control Panel manual for Ethernet interface The following topics are discussed in this chapter: •...

  • Page 32: Chapter 3: Operation

    Chapter 3: Operation Operating Notes When setting the control parameters on the ENC/ENS6800+, observe the following: • If you make changes to certain parameters, other related parameters may also be affected. See “Cross-Functional Parameter Changes” on page 19 for more information. •...

  • Page 33: Cross-Functional Parameter Changes

    Chapter 3: Operation Cross-Functional Parameter Changes When you configure certain parameters, you force a change in other associated parameters. The following table lists the secondary changes that occur when you make these parameter selections. Table 3-1. Cross-Functional Parameter Changes Parameter Option Affected Parameter Change...

  • Page 34: Changing Parameter Settings

    Chapter 3: Operation Changing Parameter Settings Follow these steps to change the ENC/ENS6800+ parameter settings: 1. Rotate the mode select rotary switch (hex switch) to “0.” 2. Once the hex switch is set to “0,” toggle the navigation switch up or down to select a bank.

  • Page 35: Recalling Default Parameter Settings

    Chapter 3: Operation Recalling Default Parameter Settings Table 3-2 “Parameter Options” describes all of the parameter settings for the ENC/ENS6800+, including the original factory defaults. To return this module to its default settings, you can either reset each parameter individually or do a global recall following this procedure: 1.

  • Page 36: Setting Enc/Ens6800+ Control Parameters

    Chapter 3: Operation Setting ENC/ENS6800+ Control Parameters The following table lists all of the available parameters and options for Note the ENC/ENS6800+. All parameters clip unless otherwise indicated. The On/Off combinations of the control LEDs on the card-edge indicate The sequence of options the active bank number.
  • Page 37 Chapter 3: Operation Table 3-3. Card-Edge Parameter Options— ENC/ENS6800+ Modules(Continued) Bank, Rotary Parameter Name Function Parameter Option Switch 0, 6 Chroma Phase Adjust the chroma phase with respect to ±180° burst (0°) • NTSC 0, 7 Video Output Standard Sets the video standard for the (525 LED is Composite output green)
  • Page 38 Chapter 3: Operation Table 3-3. Card-Edge Parameter Options— ENC/ENS6800+ Modules(Continued) Bank, Rotary Parameter Name Function Parameter Option Switch • Free Run 0, E Genlock Mode Selects the Genlock mode • Mono Lock • Burst • Auto 0, F Factory Recall Recalls the factory settings Note: Bank 1 parameter options are available for selection on ENS6800+.
  • Page 39 Chapter 3: Operation Table 3-3. Card-Edge Parameter Options— ENC/ENS6800+ Modules(Continued) Bank, Rotary Parameter Name Function Parameter Option Switch • Pass 1, 8 Loss of Video Output Selects the output video mode when the (ENS6800+ only) input video is disrupted • Black •...
  • Page 40 Chapter 3: Operation Table 3-3. Card-Edge Parameter Options— ENC/ENS6800+ Modules(Continued) Bank, Rotary Parameter Name Function Parameter Option Switch • Pass 2, 2 Line 10 VBI Selects the processing mode for this VBI line • Luma only • Blank • Pass 2, 3 Line 11 VBI Selects the processing mode for this...
  • Page 41 Chapter 3: Operation Table 3-3. Card-Edge Parameter Options— ENC/ENS6800+ Modules(Continued) Bank, Rotary Parameter Name Function Parameter Option Switch • Pass 2, C Line 20 VBI Selects the processing mode for this VBI line • Luma only • Blank • Pass 2, D Line 21 VBI Selects the processing mode for this...
  • Page 42 Chapter 3: Operation Table 3-3. Card-Edge Parameter Options— ENC/ENS6800+ Modules(Continued) Bank, Rotary Parameter Name Function Parameter Option Switch • Pass 2, 5 Line 9 VBI Selects the processing mode for this VBI line • Luma only • Blank • Pass 2, 6 Line 10 VBI Selects the processing mode for this...
  • Page 43 Chapter 3: Operation Table 3-3. Card-Edge Parameter Options— ENC/ENS6800+ Modules(Continued) Bank, Rotary Parameter Name Function Parameter Option Switch 2, F For Future Use • Bank 0 3, 0 Bank Select Selects a bank • Bank 1 • Bank 2 • Bank 3 (These parameters wrap) •...

  • Page 44: Leds And Alarms

    Chapter 3: Operation LEDs and Alarms Monitoring LEDs The ENC6800+ has five monitoring LEDs and ENS6800+ has seven monitoring LEDs that serve as a quick monitoring reference. Figure 3-1 shows the general location of the monitoring LEDs on a generic 6800+ module.
  • Page 45 Chapter 3: Operation Table 3-6. Monitoring LEDs Color Indications Meaning Selected input standard is not D1-525 Flashing Green Selected input standard is NTSC; valid D1-525 video is not detected Green Selected input standard is NTSC; valid D1-525 video is present Flashing Orange Selected output standard is PAL-M;...

  • Page 46: Module Status Leds

    Chapter 3: Operation Table 3-6. Monitoring LEDs (Continued) Color Indications Meaning Genlock Either the Genlock Mode parameter is set to Free Run or the Frame Sync Mode parameter is set to Delay Mode Flashing Green Frame Sync Mode is set to Sync Mode and Genlock Mode is not set to Free Run, but the module’s...

  • Page 47: Alarms

    Chapter 3: Operation Alarms are usually logged and monitored within available software control applications (for example, +Pilot Lite or Pilot). See the appropriate software control user manual or online help for more information. Table 3-7. Module Status LED Descriptions Note LED Color Sequence Meaning If the LED is flashing red, There is no power to the module;...
  • Page 48 Chapter 3: Operation ENC/ENS6800+ Installation and Operation Manual...

  • Page 49: Overview

    Chapter 4 Specifications Overview The following specification tables appear in this chapter: • “Video Input” on page 36 • “Video Output” on page 37 • “Power Consumption” on page 38 Specifications and designs are subject to change without notice. ENC/ENS6800+ Installation and Operation Manual...

  • Page 50: Chapter 4: Specifications

    Chapter 4: Specifications Video Input Serial Digital Video Table 4-1. Serial Digital Video Input Item Specifications Standard SMPTE 259M-C, 270 Mbps, 525/625 component Connector BNC per IEC 169-8 Impedance 75Ω Return loss >18 dB to clock frequency Signal level 800 mV ±10% CMR voltage 30 V p-p, up to 60 Hz Equalization...

  • Page 51: Video Output

    Chapter 4: Specifications Video Output Composite Analog Table 4-3. Composite Analog Video Output Item Specifications Standards NTSC, PAL-B, PAL-M Impedance 75Ω Return loss >40 dB to 5.75 MHz Quantizing 12 bits Frequency response ±0.15 dB to 5.5 MHz Differential gain <1% (typically <0.5%) Differential phase <1°...

  • Page 52: Serial Digital Video

    Chapter 4: Specifications Serial Digital Video Table 4-4. Serial Digital Video Output Item Specifications Standard SMPTE 259M-C, 270 Mbps, 525/625 component Connector BNC per IEC 169-8 Impedance 75Ω Return loss >18 dB to clock frequency Signal level 800 mV ±10% DC offset 0 V ±0.5 V Rise and fall times...

  • Page 53: Operating Temperature

    Chapter 4: Specifications Operating Temperature The operating temperature for ENC/ENS6800+ modules is 41° to 113°F (5° to 45°C). ENC/ENS6800+ Installation and Operation Manual...
  • Page 54 Chapter 4: Specifications ENC/ENS6800+ Installation and Operation Manual...

  • Page 55: Appendix A: Filters

    Appendix A Filters Composite Encoder Filter NTSC/PAL-M Pass Filter Luminance This filter is an “all pass” filter. No digital filtering is done on the composite encoder. It is up to the user to supply a suitable signal that corresponds to the user’s encoder application. This is very important when the signal is being fed to a bandwidth-limited channel.

  • Page 56: Pal-B Pass Filter

    Appendix A: Filters PAL-B Pass Filter Luminance This filter is an “all pass” filter. No digital filtering is done on the composite encoder. It is up to the user to supply a suitable signal that corresponds to the user’s encoder application. This is important when the signal is being fed to a bandwidth-limited channel.

  • Page 57: Cross-Color Reduction Filter

    Appendix A: Filters Cross-Color Reduction Filter This section describes the cross-color reduction filters that are available for the ENS-6804 board. The filter responses and characteristics are limited to the structure of the custom FIR filter ASIC. These are 12-bit coefficients with 15-tap folded FIR. Filter Summary The implementation of each Cross-Color Reduction filter consists of two filters: a vertical high pass filter and a horizontal high pass filter.

  • Page 58: Vertical High Pass Filter Frequency Response

    Appendix A: Filters Vertical High Pass Filter Frequency Response Figure A-3. XCR Vertical High Pass Filter Frequency Response Horizontal High Pass Filters Filter 1 Figure A-4. XCR Filter 1 High Pass Filter Frequency Response ENC/ENS6800+ Installation and Operation Manual...
  • Page 59 Appendix A: Filters Filter 2 Figure A-5. XCR Filter 2 High Pass Filter Frequency Response Filter 3 Figure A-6. XCR Filter 3 High Pass Filter Frequency Response ENC/ENS6800+ Installation and Operation Manual...
  • Page 60 Appendix A: Filters ENC/ENS6800+ Installation and Operation Manual...

  • Page 61: Appendix B: Enc/Ens6800+ Troubleshooting

    PC that connects to the 6800+ frame via the serial port connector at the rear of the frame, and can be downloaded from www.broadcast.harris.com/leitch. Use a null modem RS-232 cable to connect between the PC and the 6800+ frame.

  • Page 62: Genlock Issues

    Appendix B: ENC/ENS6800+ Troubleshooting Genlock Issues If the ENC/ENS6800+ cannot lock to genlock, proceed through the following checklist: 1. Check that the Reference Input Select parameter is properly set. Note There are three choices: • Genlock 1/Frame Genlock - When this setting is chosen, the Although the ENC6800+ does not have a frame synchronizer, genlock source must come from either the Genlock 1 input...
  • Page 63 Appendix B: ENC/ENS6800+ Troubleshooting source. Remember that the jumper determines whether Genlock 1 or the Frame is the source of the second genlock input (see Figure B-1 on page 48). When the genlock input is valid, the D7 Genlock LED on the card Note edge will turn green.
  • Page 64 Appendix B: ENC/ENS6800+ Troubleshooting c. Check that the 20 pin spring connector at the bottom of the back module does not have any bent or pressed in pins. (See Figure B-2.) Even a slightly depressed or bent pin may cause genlock issues.

  • Page 65: Output Issues

    Appendix B: ENC/ENS6800+ Troubleshooting Output Issues If the SDI output has issues such as no output, unstable output or frozen output, proceed with the following checklist. 1. Check that the Video Output Standard Set parameter is set correctly. If a 525 SDI input is present, then the valid output standard choices are NTSC or PAL-M.
  • Page 66 Appendix B: ENC/ENS6800+ Troubleshooting ENC/ENS6800+ Installation and Operation Manual...

  • Page 67: Overview

    Appendix C Communication and Control Troubleshooting Tips Overview Find the following troubleshooting information in this appendix: • “General Troubleshooting Steps” on page 54 • “Software Communication and Control Issues” on page 55 • “Hardware Communication and Control Issues” on page 59 •...

  • Page 68: Appendix C: Communication And Control Troubleshooting Tips

    6800+ series products can notes, erratas, product release notes, and more) can be found on our generally be found in the Web site at www.broadcast.harris.com/leitch (Support section), product-specific manual that along with technical support information, training information, accompanies every module, in product downloads, and the product knowledge base.

  • Page 69: Software Communication And Control Issues

    Appendix C: Communication and Control Troubleshooting Tips Software Communication and Control Issues • “+ Pilot Lite Fails to Communicate with Installed Modules” on page 55 • “+ Pilot Lite Does Not Find All Modules in Frame” on page 56 • “+ Pilot Lite or CCS Software Application Not Responding”...

  • Page 70: Pilot Lite Does Not Find All Modules In Frame

    Appendix C: Communication and Control Troubleshooting Tips A legacy 6800 series product is in the frame. + Pilot Lite cannot • communicate with legacy 6800 series products. They will not be discovered or controlled by + Pilot Lite, although they can be installed in the FR6802+ frame and work using card edge controls.

  • Page 71: Pilot Lite Or Ccs Software Application Not Responding

    Appendix C: Communication and Control Troubleshooting Tips If a module is plugged into the frame after a discovery, + Pilot Lite does not automatically detect the module. Refresh + Pilot Lite (File > Refresh) to discover the newly installed module. If a Legacy 6800 series product is in the frame, + Pilot Lite will not detect it.

  • Page 72: Ccs Software Application Or Remote Control Panel Does Not Communicate With Module

    Appendix C: Communication and Control Troubleshooting Tips CCS Software Application or Remote Control Panel Does Not Communicate with Module CCS software applications (such as Pilot, CoPilot, and Navigator) and remote control panels require the purchase and installation of an ICE6800+ module in an FR6802+XF frame in order to communicate remotely via Ethernet.

  • Page 73: Hardware Communication And Control Issues

    Contacting Customer Service We are committed to providing round-the-clock, 24-hour service to our customers around the world. Visit our Web site at www.broadcast.harris.com/leitch for information on how to contact the customer service team in your geographical region. ENC/ENS6800+ Installation and Operation Manual...
  • Page 74 Appendix C: Communication and Control Troubleshooting Tips ENC/ENS6800+ Installation and Operation Manual...

  • Page 75: Keywords

    Index Symbols chroma gain 22 Keywords chroma phase 23 525 input 48 Chroma/luma delay 37 625 input 48 Chroma/luma gain 37 6800/7000 series frames 11 chrominance 2 CJ1 jumper 12 clip 22 Closed Captioning 51 active bank number 22 CMR voltage 36 active video setup 23 color bars 3 Adjustable vertical blanking 37...
  • Page 76 Index Data I/O Output 38 Genlock 48 DC offset 37 input 2 default parameter settings 21 mode 24 Delay Mode 32 source 13 description, product 2 Differential gain 37 Differential phase 37 H Phase 19 digital filtering 42 hardware version 21 digital internal processing, over-sample rate 2 horizontal high pass filter 43 discovery failure 56...
  • Page 77 Index ports 38 standard 31 LED locations 4 timing 23 LEDs 30 video mode 25 Line 21 51 outputs 2 Line time distribution 37 over-sample rate 2 local control 12 local mode 13 local/Remote control jumper 5 packing list 11 lock reference video 32 PAL-B Pass Filter 42 loss of input signal 3...
  • Page 78 Index Revision history of the manual vii Transient response 37 Rise and fall times 38 troubleshooting 47 – RoHS-compliance x Tx filter 42 rotary switch 20 types of modules 15 Safety precautions xii Unpacking and shipping a product ix SCH offset 2 Unpacking information ix SDI outputs 2 unpacking modules 11...
