Whenever you change the resolution, color, or refresh rate, the image
size, position, or shape may change. This behavior is normal. You can
readjust the image using the monitor on-screen controls. For more
information on the monitor on-screen controls, refer to Panel controls
and OSD functions. For more information on configuring the display
settings, please refer to the manual that accompanied your video card.

Testing the console

To test that the console is working properly, perform the following steps:
1. Power up the LCD Rack Drawer, and then turn on your computer.
2. Make sure the video image is centered within the screen area. Use
the OSD controls to adjust the image (see Panel controls and OSD
functions) or press the Auto button on the right hand side of the
monitor.
* Note: If the unit does not power up when the panel is pulled up, try
pushing the soft power on/off button on the left side of the monitor
panel to power up the unit.
* Note: You can adjust the horizontal and vertical position, contrast,
and brightness to better suit your video card and your personal
preference.
Before you begin, make sure that power to all of the devices you will
be connecting to the console have been turned off. To prevent damage
to your installation due to ground potential difference, make sure that
all of the devices being installed are properly grounded. Once all
peripherals have been connected, please power them on.
