- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 01/22/2015...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 Installation ....................1 Hardware Installation ..........................1 Mounting the console ..........................2 How to Use ....................4 Connecting the Console ......................... 4 Turning on the Console .......................... 4 Configuring Display Settings ........................ 4 Testing the Console .......................... -
Page 4: Introduction
Introduction Packaging Contents • 1U LCD Rack Console Drawer • VGA cable • USB cable • Mounting Rails - Set • Power Adapter • Power Cord Installation Hardware Installation Hardware Kit Contents Screw kit (Used to attach Rail Mount to Side Rails with front and rear brackets (2) Console body) •... -
Page 5: Mounting The Console
Mounting the console 1. Adjust the sliding rail until the screw underneath is visible. Loosen (do not release) the two rear screws then adjust the rear bracket to fit the depth of your rack: 2. Install the rail into the rack by attaching them to the front/rear posts using the appropriate screws and nuts for your rack (not included): Instruction Manual... - Page 6 3. Tighten the rear screws that were loosened in Step 1: 4. Install the remaining rail, repeating Steps 1-3. 5. Gently, but firmly insert the console into the left and right rails: 6. Install two screws on each side of the rear console: 7.
-
Page 7: How To Use
How to Use Connecting the Console VGA input Power Connector USB output To connect the LCD console to a computer, perform the following steps: 1. Turn off your computer. 2. Connect the VGA video cable from the VGA output on the computer system to the VGA port on the rear of the rack console. -
Page 8: Testing The Console
Each video card has several controls that allow you to adjust the display settings, however, the software and driver for each video card is unique. In most cases, you can adjust these settings using a program or utility provided by the manufacturer of the video card. -
Page 9: Panel Controls And Osd Functions
Panel Controls and OSD Functions The following controls are located on the left side of the the console monitor: Controls Descriptions Soft power on/off. Adjacent LED is lit when on. Auto Auto-synchronize and scale down display to any valid factory preset timings. -
Page 10: Color
Color 1. Press the Menu button. 2. Use the Down and Up button to scroll. 3. Highlight Color, and press the Menu button to enter, which will launch the following screen: Icon Description 9300°K To set CIE coordinates at 9300°K color 7500°K To set CIE coordinates at 7500°K color 6500°K... -
Page 11: Language
Language 1. Press the Menu button. 2. Use the Down and Up buttons to scroll. 3. Highlight Language, and press the Menu button to select, which will launch the following screen: English German French Italian Spanish 4. Use the Down and Up buttons to scroll, and highlight the preferred language. 5. -
Page 12: Specifications
Specifications RACKCONV1701 RACKCONV1901 RKCONV1701xx Display Size 17” 19” Panel Type Active Matrix TFT LCD Resolution 1280x1024 @ 60Hz (max.) Capabilities Back Light four lamps Supported 16.7M Colors Colors (6-bit with FRC) Rising Time: 2ms Rising Time: 2ms Response Time Decay Time: 14ms Decay Time: 10ms VGA cable (male/male) System Cables... - Page 13 RACKCONV1701 RACKCONV1901 RKCONV1701xx 509.2mm x 477.6mm x 549.2mm x 477.6mm x 43.7mm 43.7mm Dimension (20.1” x 18.8” x 1.7”) (21.6” x 19.8” x 1.7”) Net Weight 10.4kg (22.9lbs) 11.2kg (24.7lbs) Chassis Heavy duty steel Construction Regulatory CE/FCC Certification Instruction Manual...
-
Page 14: Rackconv1701 Dimensions
RACKCONV1701 Dimensions RACKCONV1901 Dimensions Instruction Manual... -
Page 15: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 16 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
