1U 17in Rack Mount LCD Console with Integrated 16 Port KVM Switch

StarTech ID: RACKCONS1716

This 1U Rack Mount LCD KVM Console features an integrated 16 Port Multi-Platform KVM Switch module, 17in active

matrix LCD monitor, full 106-key keyboard and mouse touchpad neatly combined into 1U of space in any standard rack

or cabinet 30in (or greater) in depth.

The KVM console offers a design similar to that of a rackmounted laptop computer - when the console is not in use, it's

as simple as folding the LCD display and keyboard/mouse up and sliding it back into the server rack on the sturdy

mounting rails (included).

A highly-scalable server control solution, each KVM console/switch module can control up to 136 computers by

cascading 8 additional 16 port KVM switches. To ensure further versatility, the console is compatible with virtually any

existing KVM switch as well as with most PC, Mac and Sun servers/systems.

Applications and Solutions

• Centralized control of up to 136 Servers

• Improving the internal space efficiency of existing cabinets

• Managing cabinet mounted servers

Table of Contents

Do you have a question about the RACKCONS1716 and is the answer not in the manual?

Page 1 This 1U Rack Mount LCD KVM Console features an integrated 16 Port Multi-Platform KVM Switch module, 17in active matrix LCD monitor, full 106-key keyboard and mouse touchpad neatly combined into 1U of space in any standard rack or cabinet 30in (or greater) in depth.
Page 2 Features • Auto Scan Mode lets you switch between computers for easy monitoring • Cascadable design • Compatible with PC, Mac and Sun servers and systems • Durable design • Hot-pluggable • Login authentication restricts access to authorized users • On Screen Display (OSD) •...
Page 3 Technical Specifications • Maximum Cascaded Computers: 136 • Maximum Analog Resolutions: 1280X1024 (SXGA) • OSD & Hotkey Support: Yes • Power Adapter Included: Yes • Power Adapter - Amperage: 4 • Power Adapter - DC Voltage: 12 • Carton Quantity: 1 •...
