6. Remove and save the four indicated 5/16" x

3/4" Screws (4).

Identify the Left and Right Base Covers (82, 83).
Slide the Left Base Cover onto the Left Upright
(89), and slide the Right Base Cover onto the
Right Upright (90). Do not press the Base
Covers into place yet.
7. Identify the left handrail assembly (C). Attach
the left handrail to the Left Upright (89) with two
5/16" x 2 1/2" Screws (28) and two 5/16" Star
Washers (11); do not fully tighten the Screws
yet.
Then, remove and discard the indicated screw
(D).
6
4
89
82
7
11
D
C
10
4
90
28
89
83
