Model No. PETL15618.0
Serial No.
USER'S MANUAL
Write the serial number in the space
above for reference.
Serial Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
iconeurope.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power 1295i and is the answer not in the manual?

Questions and answers

Related Manuals for Pro-Form Power 1295i

Summary of Contents for Pro-Form Power 1295i

  • Page 1 Model No. PETL15618.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 4, Westgate Court Silkwood Park OSSETT...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . . 2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 21. The treadmill is capable of high speeds. 25. When folding or moving the treadmill, make Adjust the speed in small increments to sure that the storage latch is holding the avoid sudden jumps in speed. frame securely in the storage position. Do not operate the treadmill while it is folded.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this PROFORM POWER 1295 I treadmill. The POWER manual. To help us assist you, please note the product ® 1295 I treadmill offers an impressive selection of fea- model number and serial number before contacting us.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • Left parts are marked “L” or “Left” and right parts are marked “R” or “Right.” • Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing •...
  • Page 8 2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (81) to the front of the Base (94). Next, identify the Right Upright (90). Have a sec- ond person hold the Right Upright near the Base (94).

  • Page 9: 3/8" Star Washers (13) As Shown; Do Not Fully

    4. Hold the Right Upright (90) against the Base (94). Make sure not to pinch the Upright Wire (81). Attach the Right Upright (90) and a Wheel (97) with two 3/8" x 2 1/4" Screws (7), a 3/8" x 1 1/4" Screw (63), a 3/8"...
  • Page 10 6. Identify the Right Handrail (87). Hold the Right Handrail (87) near the Right Upright (90). Insert the Upright Wire (81) through the hole in the bottom of the Right Handrail as shown, and then remove the wire tie (A) from the Upright Wire.

  • Page 11: Tighten The Screws Yet

    8. Set the console assembly (F) face down on a soft surface to avoid scratching the console assembly. Remove and save the four 5/16" x 1/2" Screws (4). 9. Set the console assembly (F) on the Left and Right Handrails (86, 87). Make sure not to pinch any wires (G, 81).
  • Page 12 11. See the inset drawing. Connect the Upright Wire (81) to the console wire (G). The connec- tors should slide together easily and snap into place. If they do not, turn one connector and try again. IF YOU DO NOT CONNECT THE CONNECTORS PROPERLY, THE CONSOLE MAY BECOME DAMAGED WHEN YOU TURN ON THE POWER.

  • Page 13: 3/4" Screws (25

    13. Slide the Left Bottom Handrail Cover (85) up against the Left Handrail Cover (79), and attach the Left Bottom Handrail Cover with two #8 x 1/2" Screws (1); do not overtighten the Screws. Attach the Right Bottom Handrail Cover (84) in the same way.
  • Page 14 15. Remove the 5/16" Nut (12) and the 5/16" x 1 3/4" Bolt (6) from the bracket on the Base (94). Next, orient the Storage Latch (53) as shown. Attach the lower end of the Storage Latch (53) to the bracket on the Base (94) with the 5/16" x 1 3/4"...
  • Page 15 17. Firmly tighten the four 3/8" x 2 1/4" Screws (7) and the two 3/8" x 1 1/4" Screws (63). Next, tighten the two 3/8" x 1 3/4" Screws (62); the Wheels (97) must turn freely. Next, set the Left Inner Base Cover (74) onto the lower end of the Left Upright (89).

  • Page 16: 3/4" Screws (25

    19. Carefully slide the Upright Crossbar (88) between the Left and Right Uprights (89, 90). Attach the Upright Crossbar with the four 5/16" x 3/4" Screws (25) that you removed in step 5 and four 5/16" Star Washers (11); start all four Screws, and then tighten them.

  • Page 17: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord into the tion or break down, earthing provides a path of least socket on the treadmill.
  • Page 18 CONSOLE DIAGRAM FEATURES OF THE CONSOLE compatible heart rate monitor. See page 27 for infor- mation about purchasing an optional chest heart The advanced treadmill console offers a selection of rate monitor. features designed to make your workouts more effec- tive and enjoyable.
  • Page 19 HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the treadmill has been exposed to The console features a tablet with a full-color touch cold temperatures, allow it to warm to room tem- screen. The following information will help you become perature before you turn on the power.
  • Page 20 HOW TO SET UP THE CONSOLE 6. Calibrate the incline system. Before using the treadmill for the first time, set up the First, touch the profile button. Next, select the set- console. tings main menu. Then, select the maintenance section, touch the Calibrate Incline button, and then 1.
  • Page 21 3. Start the walking belt and adjust the speed. • Your vertical loss Touch the Manual Start button in the upper-right • The elapsed time corner of the screen or press the Start button on the console to start the walking belt. The walk- •...
  • Page 22 Before using HOW TO USE A MAP WORKOUT the handgrip heart rate mon- Note: To use a map workout, the console must be con- itor, remove nected to a wireless network (see HOW TO USE THE the sheets of WIRELESS NETWORK MODE on page 26). plastic from the metal contacts.
  • Page 23 5. Monitor your progress with the display modes. 4. Save your workout. See step 5 on page 21. Touch the Save New Workout button in the lower- left corner of the screen. If desired, change the title 6. Measure your heart rate if desired. of the workout or add a description, and then press the >...
  • Page 24 Then, navigate to Menu > Schedule to view your 8. Measure your heart rate if desired. schedule. All of the workouts that you have joined will appear on your schedule; you can arrange or See step 6 on page 21. delete the workouts on your schedule as desired.
  • Page 25 HOW TO USE THE EQUIPMENT SETTINGS Touch the Update button to check for firmware SECTION updates using your wireless network. The update will begin automatically. 1. Select the settings main menu. To avoid damaging the treadmill, do not turn off See step 1 on page 24.
  • Page 26 HOW TO USE THE WIRELESS NETWORK MODE When the console is connected to your wireless network, a checkmark will appear next to the wire- The console features a wireless network mode that less network name. Then, touch the back button on allows you to set up a wireless network connection.
  • Page 27 HOW TO CONNECT AN HDMI CABLE HOW TO USE THE TABLET HOLDER To show your console screen on a TV or monitor, rotate IMPORTANT: The tablet holder is designed for use the tablet holder backward, and plug an HDMI cable with most full-size tablets.

  • Page 28: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 29: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE SYMPTOM: The power turns off during use Regular maintenance is important for optimal perfor- a. Check the power switch (see drawing c at the left). mance and to reduce wear. Inspect and properly tighten If the switch has tripped, wait for fi ve minutes and all parts each time the treadmill is used.
  • Page 30 Locate the SYMPTOM: The walking belt slows when walked on Reed Switch Top View (130) and a. If an extension cord is needed, use only a 3-con- the Magnet ductor, 14-gauge (2 mm ) cord that is no longer (129) on the than 5 ft.
  • Page 31 SYMPTOM: The walking belt is not centered SYMPTOM: The tablet holder does not stay in place between the foot rails a. Rotate the tablet holder backwards. Then, tighten a. IMPORTANT: If the walking belt rubs against the the indicated screw slightly until the tablet holder foot rails, the walking belt may become dam- stays in place when it is rotated to the desired aged.

  • Page 32: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
  • Page 33 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 34: Part List

    PART LIST Model No. PETL15618.0 R0618A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw 3/8" Plastic Bushing #8 x 3/4" Screw 3/8" Washer 5/16" x 2 1/4" Bolt Storage Latch 5/16" x 1/2" Screw Drive Motor #10 Star Washer Motor Belt 5/16"...
  • Page 35 Key No. Qty. Description Key No. Qty. Description #8 Star Washer #8 x 3/4" Truss Head Screw #8 x 1/2" Machine Screw Left Rear Cap #8 Nut Right Rear Cap Motor Bushing 1/4" Nut Motor Washer Console Clamp Filter Bracket #8 x 1 3/4"...

  • Page 36: Exploded Drawing

    EXPLODED DRAWING A Model No. PETL15618.0 R0618A...
  • Page 37 EXPLODED DRAWING B Model No. PETL15618.0 R0618A...
  • Page 38 EXPLODED DRAWING C Model No. PETL15618.0 R0618A...
  • Page 39 EXPLODED DRAWING D Model No. PETL15618.0 R0618A...

  • Page 40: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
