Model No. PETL38817.0
Serial No.
Write the serial number in the space
above for reference.
Serial
Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
iconeurope.com
Advertisement
Table of Contents
Related Manuals for Pro-Form PETL38817.0
Summary of Contents for Pro-Form PETL38817.0
- Page 1 Model No. PETL38817.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd.
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product. - Page 4 21. The treadmill is capable of high speeds. frame securely in the storage position. Do Adjust the speed in small increments to not operate the treadmill while it is folded. avoid sudden jumps in speed. 26. Do not change the incline of the treadmill by 22.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the new PROFORM 105 CST reading this manual, please see the front cover of this ® treadmill. The 105 CST treadmill offers a selection of manual. To help us assist you, note the product model features designed to make your workouts at home number and serial number before contacting us. -
Page 6: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly. -
Page 7: Assembly
ASSEMBLY • Assembly requires two persons. • Left parts are marked “L” or “Left” and right parts are marked “R” or “Right.” • Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing •... - Page 8 3. Attach the Left and Right Handrails (71, 72) to the Uprights (76) with four M10 x 45mm Screws (2); start all four Screws, and then tighten them. 4. With the help of a second person, hold the con- sole assembly (A) near the Uprights (76). Insert the Upright Wire (78) and the Ground Wire (95) through the looped tie (B) on the back of the console assembly (A).
- Page 9 6. Raise the Frame (55) to the upright position. Have a second person hold the Frame until step 7 is completed. Remove the M8 Nut (33) and the M8 x 35mm Bolt (7) from the bracket on the Base (85). Next, orient the Storage Latch (77) as shown.
-
Page 10: How To Use The Treadmill
HOW TO USE THE TREADMILL HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord into the tion or break down, earthing provides a path of least socket on the treadmill. - Page 11 CONSOLE DIAGRAM Thumb Heart Rate Monitor Clip FEATURES OF THE CONSOLE To turn on the power, see page 12. To use the man- ual mode, see page 12. To use an onboard workout, see page 14. To connect your tablet to the console, The treadmill console offers a selection of features see page 15.
- Page 12 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
- Page 13 4. Follow your progress with the display. Scan mode—The console also has a scan mode that will display workout information in a repeating The display can show the following workout cycle. To turn on the scan mode, press the Scan information: button (B);...
- Page 14 5. Measure your heart rate if desired. HOW TO USE AN ONBOARD WORKOUT You can measure your heart rate using either the 1. Insert the key into the console. thumb heart rate monitor or a compatible heart rate monitor. For information about purchasing an See HOW TO TURN ON THE POWER on page 12.
- Page 15 HOW TO CONNECT YOUR TABLET TO THE If the speed setting for the current segment is too high or too low, you can manually override the CONSOLE setting by pressing the Speed buttons; however, when the current segment of the workout ends, The console supports BLUETOOTH connections to the treadmill will automatically adjust to the tablets via the iFit Bluetooth Tablet app and to compat-...
- Page 16 5. Disconnect your tablet from the console if THE SETTINGS MODE desired. 1. Select the settings mode. To disconnect your tablet from the console, first select the disconnect option in the iFit Bluetooth To select the settings mode, press the Settings Tablet app.
- Page 17 Display Test—This screen is intended to be used Demo Mode—The currently selected demo mode by service technicians to identify whether the option will appear in the display. The console display is working correctly. features a demo mode, designed to be used if the treadmill is displayed in a store.
- Page 18 THE OPTIONAL CHEST HEART RATE MONITOR HOW TO CHANGE THE INCLINE OF THE TREADMILL To vary the intensity of your exercise, you can change Whether your the incline of the treadmill. There are two incline levels. goal is to Before changing the incline, remove the key and burn fat or to unplug the power cord.
-
Page 19: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL Before folding the treadmill, remove the key and Before moving the treadmill, fold it as described at the unplug the power cord. CAUTION: You must be left. -
Page 20: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING MAINTENANCE c. Check the power switch located on the treadmill frame near the power cord. If the switch protrudes Regular maintenance is important for optimal per- as shown, the switch has tripped. To reset the formance and to reduce wear. Inspect and properly power switch, wait for five minutes and then press tighten all parts each time the treadmill is used. - Page 21 SYMPTOM: The displays of the console do not SYMPTOM: The walking belt slows when walked on function properly a. If an extension cord is needed, use only a 3-con- a. Remove the key from the console and UNPLUG ductor, 14-gauge (2 mm ) cord that is no longer THE POWER CORD.
- Page 22 SYMPTOM: The walking belt is off-center SYMPTOM: The walking belt slips when walked on a. IMPORTANT: The walking belt should be cen- a. First, remove the key and UNPLUG THE POWER tered between the foot rails. If the walking belt CORD.
-
Page 23: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy. -
Page 24: Part List
PART LIST Model No. PETL38817.0 R1217A Key No. Qty. Description Key No. Qty. Description 3/8" x 2 1/4" Screw #8 Nut M10 x 45mm Screw Belt Guide M4.2 x 19mm Screw Walking Belt 1/4" Washer Drive Roller/Pulley M4 x 13mm Washer Head Screw... -
Page 25: Exploded Drawing
EXPLODED DRAWING A Model No. PETL38817.0 R1217A... - Page 26 EXPLODED DRAWING B Model No. PETL38817.0 R1217A 26 12...
- Page 27 EXPLODED DRAWING C Model No. PETL38817.0 R1217A...
-
Page 28: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
