8. Set the console assembly (F) face down on a
soft surface to avoid scratching the console
assembly. Remove and save the four 5/16" x
1/2" Screws (4).
9. Set the console assembly (F) on the Left and
Right Handrails (86, 87). Make sure not to
pinch any wires (G, 81).
Attach the console assembly (F) with the four
5/16" x 1/2" Screws (4) that you removed in step
8 and four 5/16" Star Washers (11); do not fully

tighten the Screws yet.

10. Attach the console assembly (F) to the Left and
Right Handrails (86, 87) with four #10 x 3/4"
Screws (9) and four #10 Star Washers (5) as
shown; start all four Screws, and then tighten
them.
8
4
9
G
87
11
81
4
10
F
9
5
86
11
F
4
F
86
11
4
9
5
87
