Connectors, Switches, and LEDs
Table 4-14: Server Blade and Diagnostic Adapter LEDs
Item
1
2
3
4
5
6
4-20
HP CONFIDENTIAL Codename: Kerr Part Number: 249066-004 Last Saved On: 5/12/03 3:07 PM
LED Status
Unit Off
Identification
Blue
Health Off
Green
Amber
Red
NIC 1 Off
Green
Blinking green
NIC 2 Off
Green
Blinking green
Drive activity Off
Blinking green
Power Off
Amber
Green
Blinking green
Description
Unit not identified
Identification of server blade
Server blade off and health last good
Server blade on and health good
Server blade degraded, or power-up
prohibited by the Integrated Administrator
Server blade critical
No connection
Linked to network
Linked and activity on the network
No connection
Linked to network
Linked and activity on the network
No drive activity
Drive activity
No AC power to server blade
Enclosure on and health good
Server blade power turned on
Server blade in standby
