EVAL-SSM4567Z User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 5.
Item Qty Reference Designator
1 2 C17, C24
2 4 C1, C13, C16, C20
3 17 C2, C3, C4, C6, C23, C28, C29, C31,
C32, C34, C35, C36, C37, C38, C39,
C40, C41
4 7 C11, C12, C15, C18, C21, C22, C25
5 4 C5, C7, C14, C19
6 1 C9
7 2 C30, C33
8 2 C26, C27
9 1 C8
10 1 C10
11 1 D1
12 10 J1, J8, J9, J12, J19, J20, J21, J27,
J28, J29
13 10 J6, J10, J11, J22, J23, J7, J24, J13,
J15, J17
14 4 J2, J3, J4, J5
15 3 J14, J25, J26
16 1 J16
17 1 L1
18 4 FB1, FB2, FB3, FB4
19 2 FB5, FB6
20 19 R2, R3, R4, R6, R20, R25, R26, R27,
R28, R29, R31, R32, R33, R34, R35,
R36, R38, R40, R41
21 1 R21
22 1 R1
23 1 R5
24 1 R7
25 13 R8, R9, R10, R11, R12, R13, R14,
R15, R16, R17, R18, R19, R22
26 2 R30, R37
27 1 R39
28 2 R23, R24
29 1 S1
30 7 TP1, TP2, TP3, TP4, TP5, TP6, TP7
31 3 TP12, TP13, TP14
32 1 U2
33 6 U7, U8, U9, U10, U11, U12
Description
Multilayer ceramic 10 V X5R 22 µF 0805
Multilayer ceramic 10 V X5R 10 µF 0805
Multilayer ceramic 16 V X7R 0.1 µF
0603
Multilayer ceramic 16 V X7R 1.0 µF
0603
Multilayer ceramic 50 V X7R 0.01 µF
0603
Multilayer ceramic 50 V X7R 0.022 µF
0603
Multilayer ceramic 50 V NP0 10 pF 0603
Multilayer ceramic 50 V NP0 510 pF
0603
Multilayer ceramic 50 V X7R 1 nF 0603
Cap alum 100 µF 50 V 20% radial
LED 610 NM orn wtr clr 0805 SMD
Conn header .100" sngl str
Conn header .100" sngl str
Post binding grounded type nickel
Conn header 2.54 mm 10 POS gold
Conn header .100" dual str
2.2 µH, 1.85 A, 20%
Ferrite bead 600 Ω 0805
RES 0.0 Ω 1/8 W 0805 SMD
RES 33.0 Ω 1/10 W 1% 0603 SMD
RES 470 Ω 1/10 W 1% 0603 SMD
RES 10.0 K Ω 1/10 W 1% 0603 SMD
RES 0.0 Ω 1/10 W 0603 SMD
RES 3.01 Ω 1/10 W 1% 0603 SMD
RES 47.0 K Ω 1/10 W 1% 0603 SMD
RES 51.0 Ω 1/10 W 1% 0603 SMD
RES 100 K Ω 1/10 W 1% 0603 SMD
RES 2.20 K Ω 1/10 W 1% 0603 SMD
Switch tactile SPST-NO 0.05A 12 V
Test point PC mini .040"D black
Test point PC mini .040"D red
Receiver module fiber optic
Translator 1-bit unidirect SC70-5
Rev. 0 | Page 21 of 23
Manufacturer Mfg Part Number
Taiyo Yuden LMK212BJ226MG-T
Taiyo Yuden LMK212BJ106KG-T
Murata GRM188R71C104KA01D
Taiyo Yuden EMK107B7105KA-T
Murata GRM188R71H103KA01D
Murata GRM188R71H223KA01D
TDK Corporation C1608C0G1H100D
Murata GRM1885C1H511JA01D
Murata GRM188R71H102KA01D
Panasonic EC ECA-1HM101B
Rohm SML-210DTT86
Semiconductor
Sullins Electronics PRPC040SAAN-RC
Corp
Sullins Electronics PRPC040SAAN-RC
Corp
Johnson/Emerson 111-2223-001
Sullins Electronics SBH11-PBPC-D05-ST-BK
Corp
Sullins Electronics PRPC040DAAN-RC
Corp
Vishay Dale IFSC1008ABER2R2M01
Taiyo Yuden BK2125HM601-T
Panasonic EC ERJ-6GEY0R00V
Panasonic EC ERJ-3GEYJ330V
Panasonic EC ERJ-3EKF4750V
Panasonic EC ERJ-3EKF1002V
Panasonic EC ERJ-3GEY0R00V
Panasonic EC ERJ-3EKF3011V
Panasonic EC ERJ-3EKF4702V
Panasonic EC ERJ-3EKF51R0V
Panasonic EC ERJ-3EKF1003V
Panasonic EC ERJ-3EKF2201V
Tyco/Alcoswitch FSM6JSMA
Keystone 5001
Electronics
Keystone 5000
Electronics
Toshiba TORX147(F, T)
Fairchild FXLP34P5X
Semiconductor
UG-704
