  • Page 1 XM5 WEH 6.5 User Manual Technology at Work ®...

  • Page 2: Table Of Contents

    Install the Battery ························································································ 2-2 Charging the Battery ··················································································· 2-4 Attach the Handstrap ··················································································· 2-8 LED Indicators ··························································································· 2-8 Turn the XM5 On ························································································ 2-9 Screen Alignment ····················································································· 2-10 Startup Screen ························································································· 2-11 Fundamental Navigation ············································································ 2-12 Status Icons and Controls ·········································································· 2-13 Turning the XM5 Off ··················································································...
  • Page 3 Battery Power/Battery Conservation ····························································· 3-15 Opening Applications ················································································ 3-19 Removing Programs ················································································· 3-19 Communication Ports ················································································ 3-20 RESETTING THE XM5 ········································································ 4-1 Resetting the XM5 ······················································································ 4-1 Soft Reset (Warm Boot) ··············································································· 4-1 Hard Reset (Cold Boot) ················································································ 4-2 Master Reset ····························································································· 4-2 DATA ENTRY ···················································································...
  • Page 4 11. BLUETOOTH ·················································································· 11-1 Overview ································································································ 11-1 Enabling the Bluetooth Radio ······································································ 11-2 Pairing Bluetooth Devices ·········································································· 11-2 12. USING THE XM5 DEMOS ·································································· 12-1 Scan Demo ····························································································· 12-1 Image Demo ···························································································· 12-3 Print Demo ······························································································ 12-4 GPS Demo ······························································································ 12-4 PING Demo ·····························································································...

  • Page 5: Introduction

    The XM5 redefines productivity and is built to withstand the rigors of heavy-duty use in the field. It combines the latest technological advancements in mobile devices with a sleek and rugged design to provide the power and flexibility that enterprise and government customers demand.

  • Page 6: Hardware Overview

    Introduction User Manual Hardware Overview Janam Technologies LLC 1―2...
  • Page 7 Introduction User Manual Hardware Overview (continued) Janam Technologies LLC 1―3...

  • Page 8: Getting Started

    ― One available serial or USB port Janam XM5 Series SDK The Janam XM5 Series Software Development Kit enables programmers to develop applications for Janam XM5 Series rugged mobile computers running Android 4.2.2 operating system. It contains details and instructions for developing applications that access Janam XM5 Series libraries, including scanning, imaging and hardware utilities.

  • Page 9: Install The Battery

    User Manual Install the Battery The XM5 mobile computer is shipped with the battery packaged separate from the unit. Follow the steps below to install the battery. Remove the battery compartment door by moving the Battery door’s lock to the up position while pulling on the extended rib on either side of the battery door.
  • Page 10 NOTE: The battery door must be installed prior to booting the unit. WARNING: Use only Janam-approved Li-Ion battery packs. Unauthorized battery may result in damage not covered by the warranty. Changing the Main Battery Pack Before installing a battery pack, press the Power key to put the terminal in Suspend Mode so that Janam Technologies LLC 2―3...

  • Page 11: Charging The Battery

    Charge the Battery XM5 mobile computers ship with only the main battery pack significantly charged. Charge the main battery pack with the XM5 charging cable for a minimum of 4 or 6 hours depending on your battery before initial use.
  • Page 12 When you remove a battery pack, insert another charged battery pack in the XM5. If the main battery pack is low, insert the terminal into a charging peripheral to power the terminal and begin recharging the battery.
  • Page 13 If the main battery is low and the terminal is in Suspend Mode, pressing the Power button does not wake the XM5; you must replace the discharged battery with a fully charged battery or apply AC power to the terminal.
  • Page 14 If the battery pack is replaced with an improper type, there is risk of explosion. Use only a Janam approved power supply. The use of an alternative power supply will void the product warranty, may cause product damage and may cause it to explode or ignite.

  • Page 15: Attach The Handstrap

    User Manual Attach the Handstrap 1. Insert the metal fastener  on the handstrap facedown into the XM5 handstrap retainer clip pressing down and back until it clicks securely into place. 2. Extend the other end of the handstrap toward the base of the XM5.

  • Page 16: Turn The Xm5 On

    See Chapter 4 for additional information about On (Resume), Off (Suspend) and Reset functions. Screen Alignment Upon Initial startup of the XM5 and/or after a clean boot, the device will launch the on-screen align screen instructions. Aligning the Janam Technologies LLC...
  • Page 17 Screen Orientation screen. If, during use, there is a noticeable decrease in stylus response accuracy, the unit may be easily recalibrated. See Chapter 3 for more information about manually initiating the screen alignment procedure. Janam Technologies LLC 2―10...

  • Page 18: Startup Screen

    ― Set ring tone ― Transfer music ― Online Help & how-to ― Add/remove Getting Started Once these XM5 options are set as desired, the Add/remove Getting Started function allows the removal of the Getting Started tab from the home screen menu.

  • Page 19: Fundamental Navigation

    Always use the supplied stylus for tapping or making strokes on the screen. DO NOT use a pen, pencil or any other object on the touch screen. Connectivity Signal Audio Battery Key Status Icons and Controls Notifications Time Home Stop Toggle, Windows Mobile Screen Desktop /Home Screen Lock Janam Technologies LLC 2―12...
  • Page 20 Access the Wireless Manager Open the Scanner option menu Indicates the Keypad value Shows phone signal mode Shows the volume Indicates the Battery Control Panel (CPL) Indicates Clock & Alarm CPL Zoom in/ out Access the Bluetooth radio Janam Technologies LLC 2―13...

  • Page 21: Turning The Xm5 Off

    Indicates WAN (Phone) connection mode Indicates Sound connection mode Indicates LAN / Bluetooth mode Indicates Keypad mode Turning the XM5 Off — Suspending Operation To suspend operation: ― Press and release the red Power button located on the right side. Power button Janam Technologies LLC 2―14...
  • Page 22 Getting Started User Manual XM5 Battery Charging and Power Alert Information Battery Charging and Power Alert Information Question Battery / Power Supply Alert Threshold / Charge Time Main Battery: “Main Battery Low” appears with approx. 20% of battery power remaining.
  • Page 23 Getting Started User Manual Janam Technologies LLC 2―16...

  • Page 24: Setting Up The Xm5

    USB port XM5 Connector The XM5 I/O connector powers the terminal, charges the main battery and facilitates communication. This connector supports High speed USB 2.0 communication (up to 480 Mbps). Through this connector, you can communicate with a host workstation via Microsoft ActiveSync or Windows Device Center (see Sync Communication on paragraph 10.4).

  • Page 25: Usb Port

    This connector supports High speed USB 2.0 communication (up to 480 Mbps). It also supports external power from the MicroUSB Adaptor that is included with the terminal. When connected to the XM5 MicroUSB Adaptor, the terminal is powered and the main battery pack is charging.
  • Page 26 SIM card installed. Contact your wireless telephone service provider for additional SIM card information and refer to Chapter 8 for more about the XM5 phone function. microSD and SIM Card Slots (located beneath removable battery) The product label under the battery has a picture of the microSD and Mini SIM card showing orientation for insertion.

  • Page 27: Lcd Screen Options And Calibration

    Always use the supplied stylus for tapping or making strokes on screen. DO NOT use a pen, pencil or any other object on the touch screen. The XM5 provides a utility that enables users to customize LCD screen orientation and to recalibrate the screen’s tapping function accuracy.

  • Page 28: Setting Basic User Preferences

    The XM5 can be customized in many ways to suit task requirements, security and/or individual user preferences. The following is an overview of a selection of key XM5 settings with instructions on how to make changes. The general navigations and actions used to affect these changes are instructive to other similarly controlled settings.

  • Page 29: Device Password

    Setting Up the XM5 User Manual Key XM5 Option Settings (continued) Note: Picture backgrounds can affect the readability of text within some applications.  Tip: Tapping the Getting Started icon on the Windows Start screen is an equally effective means of navigating to the Getting Started menu.

  • Page 30: Changing Password

    Setting Up the XM5 User Manual Key XM5 Option Settings—Device Password (continued) 4. Tap the down arrow in the Password type box. 5. From the pull-down menu, select the type of password you would like to use – Simple PIN (Personal Identification Number) or Strong alphanumeric. Enter the password and enter in the same password again for confirmation.

  • Page 31: Regional Settings

    Key XM5 Series Device Option Settings (continued) Regional Settings The style in which numbers, currency, dates and times are displayed is controlled by Regional Settings. XM5 mobile computers are shipped with regional, language and input settings pre-set to English (United States). To change Regional settings: 1.

  • Page 32: Owner Information

    Setting Up the XM5 User Manual Key XM5 Option Settings (continued) Owner Information Entering owner information: 1. From the Windows Start menu, tap Settings > Personal folder > Owner Information. 2. Select the Identification tab and enter Owner Information. 3. Select the Notes tab to enter additional owner information-related text such as “Reward if Found."...

  • Page 33: Screen Orientation

    Setting Up the XM5 User Manual Key XM5 Option Settings (continued) Screen Orientation The default Screen Orientation is Portrait. If preferable, orientation can be changed to Landscape (right-handed or left-handed). Changing screen orientation: 1. From the Windows Start Screen, Tap Settings (icon) > System (folder) > Screen (icon).

  • Page 34: Device Name

    Setting Up the XM5 User Manual 3. To auto rotate the screen orientation using the XM5 Accelerometer sensor go to Start > Settings > System > Sensor (Icon) > Accelerometer (tab). Select the check box for Auto Display Orientation. Device Name...
  • Page 35 It must begin with a letter, consist of letters from A to Z, numbers from 0 to 9 and cannot contain spaces. Use the underscore character to separate words. IMPORTANT NOTE! To synchronize multiple XM5 mobile computers with the same PC, each device must have a unique name. Janam Technologies LLC 3―12...

  • Page 36: Volume & Alert Adjustments

    Setting Up the XM5 User Manual Key XM5 Series Device Option Settings (continued) Volume and Alert Adjustments The Volume Up and Volume Down button controls each perform multiple functions for device volume and phone volume. Volume Up/Down button SCAN button To adjust device volume: 1.

  • Page 37: Additional Sounds & Notifications

    Setting Up the XM5 User Manual through the On, Vibrate and Off selections. Pressing the Volume Up button up through the On, Vibrate and Off selections. Additional Sounds and Notifications Additional sound-related settings are available, making it possible to adjust select device functions to suit the user’s preference.

  • Page 38: Battery Power/Battery Conservation

     Tip: Whenever practical, you can conserve battery life by: 1. Using the AC adapter to plug the XM5 Series device into an external power source. 2. Manually or auto-suspend device operation as often as is practical 3. Reduce the backlight brightness setting 4.
  • Page 39 Setting Up the XM5 User Manual Battery Power- Conserving Battery Power (continued) Screen Off Function To adjust Screen Off function (device suspend mode): 1. Tap Settings, system on the Windows Start desktop. 2. Tap Power on the Windows Settings desktop.
  • Page 40 Setting Up the XM5 User Manual Battery Power- Conserving Battery Power (continued) Backlight Off Delay Function To adjust backlight off delay function: 1. Tap Settings (icon) on the Windows Start desktop. 2. Tap System (folder) on the Windows Settings desktop.
  • Page 41 Setting Up the XM5 User Manual Keylight Enable and Duration Function To adjust keylight duration function: 1. Tap Settings (icon) on the Windows Start desktop. 2. Tap System > Backlight (tab)> Keypad backlight 3. Enable the keylight function by selecting the check box.

  • Page 42: Opening Applications

    Setting Up the XM5 User Manual Disabling Connectivity In conditions where it is not necessary to maintain Phone, Bluetooth or wireless connectivity, battery power can be conserved and battery life extended by disabling any or all of these connectivity functions.

  • Page 43: Communication Ports

    Communication Ports The table below identifies the XM5 Comm Ports that are currently allocated. When selecting a Virtual Comm Port the Comm Ports below will not be available for use if the XM5 is configured with that function. Will be occupied when the Bluetooth function is...

  • Page 44: Resetting The Xm5

    Resetting the XM5 Series Device User Manual Resetting the XM5 Resetting In addition to On (Resume) and Off (Suspend) functions, XM5 mobile computers provide a range of device reset (boot) procedures whose functions may be called upon when required.  IMPORTANT NOTE! Some device reset options irretrievably delete stored user data! Always read and understand the parameters of selected reset procedures before execution.

  • Page 45: Hard Reset (Cold Boot)

    To master reset (or clean boot): A master reset or clean boot returns the XM5 to factory settings, removing ALL applications and data stored on the device. Any files or programs stored in the \Application folder or a micro SD card will remain.

  • Page 46: Data Entry

    Data Entry―Alpha, Numeric and Importing Entering Information on the XM5 Mobile Computer Information can be entered into the Janam XM5 Series mobile computer in a variety of ways:  Barcode scanning  Scan barcodes to automatically capture data. See Chapter 6 for information about barcode scanning.

  • Page 47: Changing On-Screen Keyboards

    Uppercase Keyboard Numeric Keyboard International Keyboard Custom Key Programming A selection of XM5 keypad function keys can be reprogrammed as shortcuts to an assortment of actions. The selection of reprogrammable keys varies, depending on the XM5 Series configuration (QWERTY or Numeric.) To reprogram function keys: 1 Tap Settings from the Windows desktop.

  • Page 48: Text Size

    The Notes application accepts input from the physical keypad, the on-screen keyboard and accepts handwriting and drawing using the supplied stylus. To draw or write freehand: ― Tap the Notes (icon) from the Windows Start menu. 5―3 Janam Technologies LLC...

  • Page 49: Voice Notes

    4. Tap the red recording dot to begin voice notes capture. 5. Tap the square stop icon to stop voice notes capture. 6. Tap the speaker icon in the main screen area to select a voice note for playback. 5―4 Janam Technologies LLC...

  • Page 50: Data Capture-Barcode Scanning

    This chapter covers each of the available XM5 barcode scanning technologies. Therefore, some of the barcode functions described in this chapter may not apply to the XM5 Series device(s) you are using. For that reason, and depending on the configuration of your XM5 Series device(s), some information in this chapter may not apply.

  • Page 51: Laser-Based Configurations

    Data Capture—Barcode Scanning User Manual A. Laser-Based Configurations This section is specific to XM5 Series configurations equipped with the Honeywell N4300 miniature laser scan engine. Please see Section B for barcode scanning with XM5 Series configurations with Adaptus Imager scanning technology.
  • Page 52 Examples below show laser line positioning to provide you with the best scanning performance. Using Demos The XM5 comes preloaded with software applications that demonstrate the advanced features of the terminal. To access these demos, tap Start > Demos. • Select Scan Demo to verify decoding 1.

  • Page 53: B. 2D Imager-Based Configurations

    B. 2D Imager-based Configurations Overview The XM5 with an N560X 2D imager scanner will read all popular 1D and 2D bar codes and supports omni-directional aiming and decoding. The imager scanner can also capture digital images, such as signatures and pictures.

  • Page 54: To Decode A Bar Code

    4. Center the aimer crosshair over the bar code. The aiming beam should be oriented in line with the bar code to achieve optimal decoding; Omni-Directional Scanning Positions on paragraph 6.10. 5. When the bar code is successfully decoded, the decode LED lights blue and the terminal beeps. 6―5 Janam Technologies LLC...

  • Page 55: Sample Bar Codes

    Activating the Imager Scanner When a scanning application is open, press the Scan key to activate the image engine. Using Demos The XM5 comes preloaded with software applications that demonstrate the advanced features of the terminal. Image Demo and Scan Demo To access these demos, tap Start ->...

  • Page 56: Capturing Images

    The foreground application is the open software application whose window is currently active on the display. Enabling ScanWedge ScanWedge is enabled by default in XM5 Mobile Computers. To review or change ScanWedge settings tap the ScanWedge icon once from the taskbar or go to “Start”, “Settings”, “System”, “Scanner Settings”.
  • Page 57 Add Tab at end of decoded bar code data Auto Scan Enable Auto Scan feature Continuous Scan Enable Continuous Scan feature Setting Open Scanner setting applet Disable Scanner Disable Scanner trigger Close Close Scan wedge The “Label”, Prefix/Suffix values can be any printable characters. 6―8 Janam Technologies LLC...
  • Page 58 Data Capture—Barcode Scanning User Manual The “Transmit Barcode ID” is a user defined value. To assign a value tap the “Detail” tab. Please refer below picture: 6―9 Janam Technologies LLC...

  • Page 59: Setting Up & Deleting Partnerships

    Connect your XM5 to your PC and power the XM5 device on. Synchronization requires any one of the following: ▪ A USB cable connected to a Janam USB Cradle with the XM5 docked in the cradle. ▪ A direct connection between the XM5 and the host PC, using a micro USB “B”...

  • Page 60: Partnership Connection Settings

    Synchronizing the XM5 Series Device User Manual Tap Set Up to proceed. Set Up will start, followed by synchronization between the PC and the XM5. The Windows Mobile Device Center screen on your PC will indicate synchronization progress. To add/remove files to/from the device: Select (mouse over) Mobile Device Settings >...

  • Page 61: Wireless Connectivity

    Depending on the features offered by your wireless service provider and/or opted for, the XM5 may also provide additional services such as voice mail, call forwarding, caller ID and more.

  • Page 62: Volume & Alert Adjustments

    1. Press either the Volume Up or Volume Down button to open the Volume control screen. 2. Select Device or Phone by tapping the corresponding slider on the screen. 3. Pressing the Volume Up or Volume Down button increases or decreases the selected volume in preset increments. Janam Technologies LLC 8―2...

  • Page 63: Using A Headset

    Volume Up button up through the On, Vibrate and Off selections. Muting/Speaker/Hold/Add Call/Contacts Once a call has been answered call control options appear on the XM5 screen to mute, place on speaker, hold, add a call and show contacts. Using a Headset...

  • Page 64: Making Calls

    Wireless Wide Area Networking (WWAN) Making Calls Wireless telephone calls may be initiated on the XM5 series device in a variety of ways, including manually dialing the telephone number, using the on-screen dial pad, selecting a number from stored Contact information or selecting a number from the automatically stored list of recently placed and answered calls.

  • Page 65: Text Messaging

    Text (SMS, Short Messaging System) Messaging is a fast convenient a means of sending and receiving brief (up to 160 characters) character-based messages, using the XM5 device’s wireless telephone number as the message portal. Text messaging is functional only between text message-enabled wireless telephone devices.
  • Page 66 Contact name or mobile telephone number. Tap the text Message content area and enter message. — With content entered, the message can be saved as a Draft by tapping OK and Yes. Tap the Send (icon) to send the text message. Janam Technologies LLC 8―6...

  • Page 67: Connecting To The Internet

    2. Tap “Add a new modem connection” 3. Select modem type “Cellular Line (GPRS) 4. Enter access point name provided by your service provider. 5. Tap OK to complete. 6. Connecting to the internet through Internet Explorer should be available. Janam Technologies LLC 8―7...

  • Page 68: Camera

    XM5 Camera User Manual Camera Introduction The XM5 features an integrated camera for capturing still photographic pictures and video which is useful for documentation of inventory locations, product damage or work procedure and more. Camera Function To activate the Camera: 1.
  • Page 69 XM5 Camera User Manual Camera Adjustments and Options  Still pictures  Brightness (default setting) (+- 2 f-stops)  Resolution (still mode)  Flash (On, Off) –  Picture quality/compression 320x240, 640x480, 1280x960 1MP – – 1600x1200 2MP High –...

  • Page 70: Recording Video

    XM5 Camera User Manual To activate the Camera: 1. From the Windows Start menu, tap the Pictures & Videos (icon). 2. Tap the Camera (icon) or the Camera button to enter the default still picture Camera Viewfinder mode. Camera Function...
  • Page 71 XM5 Camera User Manual To record video clips: 1. With the Camera function activated and in the default still picture Camera Viewfinder mode, tap Menu > Video. 2. Press the enter key to begin video recording . 3. Press the enter key again to end video recording.
  • Page 72 XM5 Camera User Manual Camera Function To view camera pictures or video clips: 1. From the Windows Start menu, tap the Pictures & Videos (icon). From the Camera menu, tap Thumbnails. 2. Tap a picture thumbnail or video icon to view it.

  • Page 73: Configuring The Wlan Radio

    User Manual WLAN (802.11 a/b/g/n) Radio The XM5 has a 2.4 GHz and 5GHz 802.11 a/b/g/n WLAN (Wireless Local Area Network) radio. The radio is interoperable with other 802.11a/b/g/n, Wi-Fi compliant products including wireless controllers, access points (APs), workstations via PC card adapters, and other wireless portable devices.
  • Page 74 6. Configuration is complete and accurate when the “Status” changes to “COMPLETE”. The “Status” panel provides usefull information about your wireless connection including the channel, Band and signal strength (RSSI). The IP tab shows your network configuration Janam Technologies LLC ―2...
  • Page 75 The “Settings” tab allows access to higher level radio controls. The default values have been derived and set to accommodate the majority of environmental conditions and should not be changed without a good working knowledge of the subject matter. Janam Technologies LLC ―3...

  • Page 76: Bluetooth

    In order to conserve battery capacity, the Bluetooth, module is off by default. ☞ NOTE: Suspending the terminal powers off the Bluetooth radio and drops the Bluetooth connection. When the terminal resumes, it takes approximately 10 seconds for the Bluetooth radio driver to re-initialize the radio. Janam Technologies LLC 11―1...

  • Page 77: Enabling The Bluetooth Radio

    3. Tap “Mode” to enable the radio 4. Tap “Add new device”, the Bluetooth Manager will search for discoverable devices. Pairing Bluetooth Devices 1. Tap on the desired device in the Bluetooth Manager. 2. Tap the Next Button on the bottom Janam Technologies LLC 11―2...
  • Page 78 4. Enter the same passkey on the other device when prompted. 5. Pairing is complete. 6. The paired device will show as disconnected while viewing the Bluetooth Manager. 7. For devices like serial printers select “Com Ports” and assign a “New Outgoing Port” Janam Technologies LLC 11―3...

  • Page 79: Using The Xm5 Demos

    XM5 Demos User Manual Using the XM5 Demos The XM5 comes preloaded with these helpful demonstration and troubleshooting applications. Scan Demo – Upon successful decode provides the barcode type and scanned result. 1. Basic : Allows setting of trigger mode, Auto/Continuous.
  • Page 80 XM5 Demos User Manual 2. Notification: Sets the enable/disable of scan beep, LED and vibrator indicators. 3. Symbologies: Allows enable or disable of symbology types. 4. Wedge: Allows input of up to 8 characters as a prefix or suffix to the decoded data.

  • Page 81: Image Demo

    XM5 Demos User Manual Image Demo – Overview The Imaging Demo demonstrates the imaging functionality of the on-board image engine, such as picture formatting, saving and printing. To Capture Images Tap Start > Demos > Imaging Demo. The Imaging Demo opens.

  • Page 82: Print Demo

    It may take a few minutes to acquire satellite signals and the best results will be obtained when the XM5 is positioned outside with a clear and unobstructed view of the sky. When indoors or without a clear view of the sky, the acquisition time to get a fixed position will take much longer or the GPS signal may be completely unavailable.
  • Page 83 XM5 Demos User Manual Also the power to the GPS module will turn off when the XM5 suspends, so after resuming there could be a delay in receiving the GPS data depending on where the unit is located upon resuming.

  • Page 84: Ping Demo

    XM5 Demos User Manual Ping Demo – Overview The Ping Demo is a basic Internet program that allows a user to verify that a particular IP address exists and can accept requests. To setup the Ping Demo Tap Start > Demos > Ping Demo. The Ping Tool opens. Ensure you have a WiFi connection using the Portable Wireless Configuration utility (chapter 10).

  • Page 85: Nfc Demo

    1. Start the NFC Tag Demo from “Start”, “Demos”. 2. To read information from a passive tagged item hold the NFC tag close to the scanner window at the top of the XM5 3. Tap the “Start” button to read and populate the application data fields.
