SBC82621 Socket370 Half-size All-in-One CPU Card User's Manual
Video Off Method
This determines the manner in which the monitor is
blanked.
This causes the system to turn off the vertical
V/H SYNC
and horizontal synchronization ports and write
+ Blank
blanks to the video buffer.
Select this option if your monitor supports the
Display Power Management Signaling (DPMS)
DPMS
standard of the Video Electronics Standards to
select video power management values.
Blank
This option only writes blanks to the video buffer.
Screen
Modem Use IRQ
This field names the interrupt request (IRQ) line assigned
to the modem (if any) on your system. Activity on the
selected IRQ always awakens the system. The available
choices are 3, 4, 5, 7, 9, 10, 11, and NA. By default, the
IRQ is set to 3.
Soft-off by PWRBTN
This only works with systems using an ATX power supply.
It also allows user to define the type of soft power OFF
sequence the system will follow.
This option follows the conventional manner
systems perform when power is turned OFF.
Instant-Off
Instant-Off is a soft power OFF sequence requiring
(default)
only the switching of the power supply button to
OFF.
Upon turning OFF system from the power switch,
this option will delay the complete system power
OFF sequence by approximately 4 seconds. Within
Delay 4 Sec.
this delay period, system will temporarily enter into
Suspend Mode enabling you to restart the system
at once.
Wake Up Events
An input signal on the network 2 awakens the system from
a soft-off state.
Award BIOS Utility
49
