SBC82621 Socket370 Half-size All-in-One CPU Card User's Manual
Disable
(default)
Min. Power
Saving
Max. Power
Saving
User Define
NOTE:
In order
protection feature, the Power Management
field should not be set to Disabled.
PM Control by APM
When enabled, an Advanced Power Management device
will be activated to enhance the Max. Power Saving mode
and stop the CPU internal clock. If Advance Power
Management (APM) is installed on your system, selecting
Yes gives better power savings. If the Max. Power Saving
is not enabled, this will be preset to No.
Video Off Option
When enabled, this feature allows the VGA adapter to
operate in a power saving mode.
Always On
Suspend -->
Off
Susp,Stby -->
Off
All Modes -->
Off
48
No power management. Disables all four
modes
Minimum power management. Doze Mode =
1 hr. Standby Mode = 1 hr., Suspend Mode =
1 hr., and HDD Power Down = 15 min.
Maximum power management -- ONLY
AVAILABLE FOR SL CPU'S. Doze
Mode = 1 min., Standby Mode = 1 min.,
Suspend Mode = 1 min., and HDD Power
Down = 1 min.
Allows you to set each mode individually.
When not disabled, each of the ranges is
from 1 min. to 1 hr. except for HDD Power
Down which ranges from 1 min. to 15 min.
and disable.
to enable
Monitor will remain on during power saving
modes.
Monitor blanked when the system enters the
Suspend mode.
Monitor blanked when the system enters
either Suspend or Standby modes.
Monitor blanked when the system enters any
power saving mode.
the CPU overheat
Award BIOS Utility
