SBC82621 Socket370 Half-size All-in-One CPU Card User's Manual
LCD Type
Although the system chipset already supports VGA and
LCD alike, BIOS Features Setup still expands this feature
further with the option to set any of the 15 LCD types. The
available options are:
Type 1/13
Type 2
Type 3
Type 4
Type 5
Type 6
Type 7
Type 8/9/10
Type 11/12
Type 14
Type 15
CRT Screen Expansion
This option allows you to enlarge application screens to full
screen scale onto your display. However this option is not
inversely compatible,
applications screens have resolutions larger than the
display resolution. The available options are Enabled and
Disabled.
Display Type During/After POST
This item configures the viewing area for the POST
sequence. When configured to the incorrect display setting
or Both, it blankets the POST sequence from being viewed.
If you select Default, this option is useless and follows the
VGA BIOS settings. The available options are CRT Only,
LCD Only, Both, and Default.
Award BIOS Utility
1024 x 768
1280 x 1024
640 x 480
800 x 600
640 x 480 (16bit)
640 x 480 (24bit)
1024 x 768
800 x 600
800 x 600
1280 x 1024
1024 x 600
rendering
DSTN
TFT
DSTN
DSTN
TFT
TFT
TFT
TFT
DSTN
DSTN
DSTN
no change when
