OLIMEX© 2012 A13-OLinuXino-MICRO User's Manual

CHAPTER 2: SETTING UP THE OLINUXINO BOARD

2. Introduction to the chapter

This section helps you set up the OLinuXino development board for the first time. Please consider
first the electrostatic warning to avoid damaging the board, then discover the hardware and software
required to operate the board.
The procedure to power up the board is given, and a description of the default board behavior is
detailed.

2.1 Electrostatic warning

OLinuXino is shipped in a protective anti-static package. The board must not be exposed to high
electrostatic potentials. A grounding strap or similar protective device should be worn when
handling the board. Avoid touching the component pins or any other metallic element.

2.2 Requirements

In order to set up the OLinuXino optimally, the following items are required:
- 5V, 5W required (5V @ 1A) – for optimal power
- LCD (preferably with touchscreen panel) display for the LCD_CON OR TV monitor with RGB
port (or suitable connector) – note the maximum display resolution should be 800x600
- USB hub (for splitting the USB) – else you will be unable to connect your USB devices
- A USB mouse – if you use touchscreen LCD you might skip the mouse
Additional items include:
- USB keyboard – for convenience with text input
- USB-SERIAL-CABLE-F – for serial communication with UART1 connector (note that it has to
be female)
- USB-MINI-CABLE – for connecting with the USB OTG and being able to firmware update to
power A13-OLinuXino-MICRO
- Wireless internet connectivity or USB modem – for browser access and access to the Android
market
Page 8 of 30
