OLIMEX© 2012 A13-OLinuXino-MICRO User's Manual

CHAPTER 7: SCHEMATICS

7. Introduction to the chapter

In this chapter are located the schematics describing logically and physically A13-OLinuXino-
MICRO.

7.1 Eagle schematic

OLinuXino schematic is visible only for reference here. You can also find it on the OLinuXino's
GitHub repository: https://github.com/OLIMEX/OLINUXINO. They are located in HARDWARE
section.
You are allowed to view and edit the schematics as long you keep them free and you mention at
least the source address (e.g. https:// www.olimex.com ), as according to Creative Commons
Attribution-Share.
The EAGLE schematic is situated on the next page for quicker reference.
Page 25 of 30
