Altronix HubWayEX16SP Installation Manual page 7

1U EIA 19" Rack Mount Chassis Mechanical Drawing and Dimensions:
1.625"
16
(41.275mm)
8.5"
(215.9mm)
0.95"
(24.13mm)
The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user to the
presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may be of sufficient
magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- 7 -
1.625" x 19.125" x 8.5" (41.275mm x 486mm x 216mm)
15 14 13 12 11
1 2 3 4 CH 1-4 5
DATA
1-8
(ON)
Fig. 6
Illuminated master power disconnect circuit breaker:
• OFF position Circuit breaker tripped – Switch not illuminated.
• RESET (ON) position – Switch illuminated.
CAUTION: To reduce the risk of electric shock do not open enclosure. There
are no user serviceable parts inside. Refer servicing to qualified service personnel.
REAR
17.125"
(434.97mm)
10 9 8 7
TOP and BOTTOM
FRONT
6 7 8 CH 5-8
28VAC
OFF
24VAC
19.125"
(485.775mm)
6 5 4 3 2
9 10 11 12 CH 9-12 13 14
DATA
9-16
1
AC POWER
15 16 CH 13-16
28VAC
OFF
24VAC
HubWayEX16SP Active Unit
