4.4 Direct connection of the handheld scanner without plug connection to the power
supply with USB interface – connection with cable end sleeve
Pin assignment
Extronics Limited
1 Dalton Way, Midpoint 18, Middlewich, Cheshire, UK. CW10 0HU
Tel: +44 (0) 845 277 5000 Fax: +44 (0)845 277 4000 E‐mail: info@extronics.com Web: www.extronics.com
USB cable
RJ45 pin
Wire
assignm
colours
ent
2 Green
10 White
7 Black
3 Brown
intrinsically safe connection box
of the ISCANPS USB power supply after removal of the
wires of the plug connection
Power supply
Connection
Definitio
terminal power
n
supply
D+ X9
D- X10
X11
GND X12
+UB X13
Definition
D+
D-
PE
GND
+UB
16
