extronics iSCAN101 User Manual

Wired handheld scanner
Hide thumbs Also See for iSCAN101:
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Wired handheld scanner
iSCAN101
Date: 27.03.2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iSCAN101 and is the answer not in the manual?

Questions and answers

Related Manuals for extronics iSCAN101

Summary of Contents for extronics iSCAN101

  • Page 1 User Manual Wired handheld scanner iSCAN101 Date: 27.03.2015...

  • Page 2: Table Of Contents

      4.2 Step 2 - Connection of ISCANPS power supply ..................13   4.3 Direct connection of the ISCAN101 handheld scanner without plug connection to the power supply with RS232 interface - connection with cable end sleeve ..................14  ...

  • Page 3: Important Notes On Operating Instructions

    1 Important Notes on Operating Instructions 1.1 Safety information Warnings are highlighted by a particular symbol and a different font colour: Non-compliance may result in life-threatening situations. This warning must be heeded. Danger This type of warning concerns dangerous situations that may result in minor injuries. Warning Important and helpful notes and information.

  • Page 4: Notes On The Operating Instructions

    The notes contained in this manual are important for starting up and operating the product. These instructions may be updated at any time. Extronics Limited reserves the right to make changes to this document.

  • Page 5: General Notes Of Caution

    1.3 General Notes of Caution Caution / Notes  The devices may only be operated when fully assembled.  In hazardous areas the devices must not be wiped or cleaned with a dry cloth!  The device must be switched off immediately if it is likely that as a consequence of damaging impact or general peculiarities the device can no longer be safely operated.
  • Page 6 Caution Devices fitted with laser fall under standards US 21 CFR 1040.10 and EN on laser devices 60825-1. The laser's classification is stated on a plate affixed to the device. Class 1 lasers are deemed inherently safe during normal use, but users must not look directly into the light source.

  • Page 7: Product Information

    2 Product Information Extronics Limited Manufacturer 1 Dalton Way Midpoint 18 Middlewich, UK CW10 0HU Device iSCAN101 2.2 Explosion II 2G Ex ib IIC T4 protection II 2G Ex ib IIC T4 Gb II 2D Ex ib IIIC T135C II 2D Ex ib IIIC T135C Db...

  • Page 8: Technical Data

    RS232 5.6V version: 2.3 Technical Data  maximum input voltage Ui 5.6 V  maximum input current li 480 mA  maximum input power Pi 1.25 W  maximum internal inductance Li negligible  maximum internal capacitance Ci 46 µF Note: The input voltage in to the handheld scanner itself is reduced by the associated connection cable ISCAN101CAB5 or 6 from 5.6V to 4.9V.
  • Page 9 Technical Data  Light source: Visible red light, 630nm (Scan engine)  LED safety: LED classification acc. to DIN EN 60825-1  Scan rate: 500 scans per second  Reader distance: 50mm to 800mm (0.5mm) Dimensions  104 x 76 x 185 mm (length x width x height) Ambient temperature -20°C to +50°C Storage temperature...

  • Page 10: Combinations

    2.4 Combinations RS232/RS422 used with connection cable ISCAN101CAB1 or 2 and only for connection to power supply ISCANPS1 or 3 USB version used with connection cable ISCAN101CAB3 or 4 and only for connection to power supply ISCANPS2 or 4 All wired handheld scanners in Stacked PDF version (iSCAN101PDF) can be equally combined.

  • Page 11: System Assembly

    3.1 Description The wired handheld iSCAN101 scanner was designed for use in hazardous areas. Normal operation requires a power supply, a connection cable between power supply and scanner, and a connection cable between power supply and a PC.

  • Page 12: Cable Range In System Assembly

    3.2 Cable range in System Assembly 1.8 or 3.8m or optional with RS232 iSCAN101 iSCANPS Up to 20m Host 4.5m or 6m extension iSCAN101 1.8 or 3,8 m iSCANPS Up to 5m Host Operating Instructions_iSCAN101_001...

  • Page 13: Step-By-Step Guide On Installation And Operation

    4 Step-by-step guide on installation and operation 4.1 Step 1 - General connection of ISCAN101 handheld scanner Insert the RJ45 plug of the cable connecting the handheld scanner with the power supply at the bottom of the scanner. Make sure the plug has engaged fully.

  • Page 14: Step 2 - Connection Of Iscanps Power Supply

    4.2 Step 2 - Connection of ISCANPS power supply The terminal assignment is located underneath the removable cover at the front of the power supply. Caution: Do not open enclosure in the hazardous area. Before operating the device in a hazardous area you have to ensure that the enclosure has been closed fully and all screws have been tightened.

  • Page 15: Direct Connection Of The Iscan101 Handheld Scanner Without Plug Connection To The Power Supply With Rs232 Interface - Connection With Cable End Sleeve

    4.3 Direct connection of the ISCAN101 handheld scanner without plug connection to the power supply with RS232 interface - connection with cable end sleeve Pin assignment RS232 cable Power supply RJ45 pin Connection Wire assignme Definition terminal power Definition colours...

  • Page 16: Direct Connection Of The Scanner Without Plug Connection To The Power Supply With Usb Interface - Connection With Cable End Sleeve

    4.4 Direct connection of the scanner without plug connection to the power supply with USB interface - Connection with cable end sleeve USB cable Pin assignment Power supply RJ45 pin Connection Wire assignme Definition terminal power Definition colours supply Green White Black Brown...

  • Page 17: Attachment

    5 Attachment 5.1 EC type examination certificate: iSCAN101 Operating Instructions_iSCAN101_001...
  • Page 18 Operating Instructions_iSCAN101_001...

  • Page 19: Ec Type Examination Certificate: Iscanps

    5.2 EC type examination certificate: iSCANPS Operating Instructions_iSCAN101_001...
  • Page 20 Operating Instructions_iSCAN101_001...
  • Page 21 Operating Instructions_iSCAN101_001...
  • Page 22 Operating Instructions_iSCAN101_001...

  • Page 23: Contact

    6 Contact Extronics Limited 1 Dalton Way Midpoint 18 Middlewich Cheshire Tel. +44 (0) 845 277 5000 Fax +44 (0) 845 277 4000 info@extronics.com Operating Instructions_iSCAN101_001...
