4. STEP BY STEP GUIDE ON INSTALLATION AND OPERATION
4.1 Step 1 – general connection of handheld scanner
Extronics Limited
1 Dalton Way, Midpoint 18, Middlewich, Cheshire, UK. CW10 0HU
Tel: +44 (0) 845 277 5000 Fax: +44 (0)845 277 4000 E‐mail: info@extronics.com Web: www.extronics.com
Insert the RJ45 plug of the cable connecting the handheld scanner
with the power supply at the bottom of the scanner.
Make sure the plug has engaged fully.
Cable connected to the wired handheld scanner
Insert the plug of the connection cable into the power supply's plug
connector.
Ensure that the connection is fully secured with the
screw cap after the plug has been inserted.
