- Page 1 HMD501 PORTABLE MAGNETIC DRILL OPERATOR’S MANUAL COVERS DRILL PART NUMBER 0501302 FOR USE WITH “12,000-SERIES” HOUGEN CUTTERS CUTTERS ® ® ®...
-
Page 2: Safety First
Hougen. Your new Hougen Magnet Base Drill now incorporates a Label for the Drill Part Number and Serial Number. Below gives an explanation of the Part Number and the location of the Label is shown on the Drill Breakdown Diagram. - Page 3 3-conductor cord and a 3-prong grounding type Cluttered areas and benches invite injuries. Keep dirt plug to fi t the proper grounding type receptacle. The and chips from under magnet and Hougen Cutter green (or green and yellow) conductor in the cord is the area.
- Page 4 Keep hands and clothing away from all moving parts. The safety chain should be used to prevent the drill unit from Do not use Hougen Cutters where ejected slug falling in the event of a power failure or if the magnet breaks might cause injury (slug ejected at end of cut).
-
Page 5: Installation Of Cutting Fluid Bottle
ON and OFF switches as shown below. should lift off the work surface while cutting. HOUGEN CUTTER INSTALLATION 5. Insert Hougen Cutter until fl ats on cutter shank are 1. Disconnect from power source. aligned with set screw holes and are exactly perpendicular 2. -
Page 6: Operation Of Cutting Fluid Bottle
1. Always Use Safety Chain. 7. Open the cutting fl uid bottle valve. 2. Use Hougen Slick-Stick™ (P/N: 11745-6) or animal-fat 8. Make certain that cutter is clear of workpiece and turn base solid-lubricant applied liberally to cutter. -
Page 7: Hints For Smoother Operation
HINTS FOR SMOOTHER OPERATION 10. Cut overlapping holes as illustrated, using minimum steady 1. Keep insides of Hougen Cutter clear of chips. Chips will pressure. When cutter is removing material whose cross- interfere with cutting to maximum depth as well as impede section is half or less than the cutter diameter, pilot should free oil fl... - Page 8 HMD501 MOTOR - 24205 24066 24114 24153 24207 24080 24206* 24208 24066 24044 24093 24045 90019 40373 * INCLUDES MOTOR CORD Part # Description 24206 Field 24207 Armature 24208 Motor Housing Assy 24044 Cap for Brush 24045 Brush (Package of 2)
-
Page 9: Optional Pressurized Coolant Bottle
ARBOR ASSEMBLY - 24199 24164 24165 Part # Description 24013 Thrust Bearing Seal 24016 24016 Quill 24091 Thrust washer 24094 Thrust Needle Bearing 24164 LH Retaining Ring 24165 Washer 24091 24196 Arbor 40222 Set Screw 24094 24013 24196 40222 OPTIONAL PRESSURIZED COOLANT BOTTLE 24140 24133 24149 24110 24168... - Page 10 04665 01547 01944 10760 01945 24216 90019 24142 04622 10705 01835 04387 90090 51038 40296 04621 HMD501 PANEL PARTS Part # Description Part # Description 01496 Spacer 04647 Wire Assy 01547 Term Strip 04648 Wire Assy 01835 Nylon Nut 04663...
- Page 11 HMD501 HOOK UP DIAGRAM ����� ���� ������� ����� � ����� ��� ���� ���� ���������� �� �������� ����������� �� ��� ��������� ��� ��������� ������ ��� ������� ������ ���� �� ������� ����� �� ������������ REAR HOUSING CAVITY 04647 WIRE HARNESS 04648 WIRE HARNESS...
- Page 13 HMD501 DRILL PARTS LIST Part # Description Part # Description 01116 Screw SHC #10-32 24087 Bearing Bushing 01179 O-Ring 24095 Lip Seal (Gear Box Cover) 04157 Screw FHSCC #10-32 24096 Lip Seal ( Armature Shaft) 04158 Screw Self Thread #10-24...
- Page 14 “12,000-SERIES” HOUGEN CUTTERS Part Number Part Number Cutter Dia. Decimal Cutter Dia. Decimal (Metric) Equivalent (Inches) Equivalent 1” D.O.C. 2” D.O.C. 3” D.O.C. 1” D.O.C. 2” D.O.C. 3” D.O.C. Use with Pilot 10531 10532 Use with Pilot 10531 10532 7/16 .4375...
- Page 15 No other expressed warranty is given or authorized. Hougen Manufacturing, Inc. disclaims any implied warranty of MERCHANTABILITY or FITNESS for any period beyond the expressed warranty and shall not be liable for incidental or consequential damages. Some states do not allow exclusions of incidental or consequential damages or limitation on how long an implied warranty lasts and, if the law of such a state governs your purchase, the above exclusion and limitation may not apply to you.
