Appendix - Bticino Polyx Memory Display Installation Manual

TECHNICAL DATA
Power supply
Absorption (Max)
Operating temperature
The LCD screen has been manufactured using advanced high precision technology. It is
however possible that sometimes up to 5 small black or coloured dots (red, blue, green)
may appear on the LCD screen. This is an absolutely normal result of the manufacturing
process and is not indicative of a malfunction and/or fault.
BTicino only accepts responsibility for perfect device operation if it is installed to the state of
the art respecting the indications of the product installation manual.
46
from SCS bus: 18 – 27 V
from 1 2 : 18 – 27 V
330 mA (A/V connection - at the minimum operating voltage)
10 mA (in stand-by)
0 – 40 °C
LCD screen note
Technical After-Sales Service
www.bticino.com

8 Appendix
