Rear View - Bticino Polyx Memory Display Installation Manual

2.6

Rear view

5
4
1 - Mini-USB connector for connection to the PC
2 - Configurator socket
3 - Connector for extra power supply
4 - Stretch end ON/OFF microswitch
5 - Connection to the BTicino 2-wire digital system BUS
