Content
Installation ......................................................................2
Installation
Approval
Assembly ..........................................................................3
Instruction for use ........................................................7
Instructions for heating ..............................................8
Maintenance ...................................................................9
Chimney connection, revolving base ....................10
Troubleshooting ............................................................12
I N S TA L L AT I O N
Installation
The house owner is responsible for ensuring that all necessary nati-
onal and local safety measures are observed during installation and
fitting and also responsible for observing the fitting and operating
instructions detailed in this manual.
When you install any kind of fireplace or stove, you must inform the
local authorities. You are also responsible for calling in a chimney
sweep to inspect and authorize the installation.
To ensure best-possible functionality and safety for your installa-
tion, we advise you to call a professional fitter. Our Scan Dealer will
be able to recommend a qualified fitter in your area. For information
on Scan Dealers, please go to www.scan.dk.
Approval
If you intend to connect your stove to an existing chimney, it makes
sense to contact an authorised Scan dealer, or a local chimney sweep
for advice. These experts will also let you know if your flue needs
renovating.
On connecting to a multiple element chimney: follow the vendor's
instructions as applicable to the chimney type (e.g. Leca, Plewa, Ico-
pal, Isokern, Zanda etc.)
No matter whether an authorised Scan dealer installs your stove, or
you do the job yourself, remember that the chimney sweep has to
approve the installation before you start to use it.
Technical data and dimensions
CO Emission at 13% O2:
Støv @ 13% O 2 :
No x @ 13% O 2 :
Efficiency:
Rated heat load:
Chimney temperature:
Flue outlet flow:
Recommended vacuum in flue collar:
Combustion air requirement:
Recommended fuel:
Fuel consumption:
Amount of fuel:
Min./max. heating performance (vendor specification):
Weight:
Flue collar internal diameter:
Flue collar external diameter:
Approval type:
Intermittent fuelling means normal use of a woodstove. In other
words, you should let the fire die down until only the embers are
left, before refuelling.
The Scan 50-series was build in compliance with the homologized
product type specified in the Assembly- and Instructions Manual
provided with the product.
The Scan 50-series
The Scan 50-series comprises the following wood-burning stoves:
Scan 50 and Scan 50 Maxi: Stoves with fixed base.
Scan 50-5 and Scan 50-5 Maxi: Stoves with revolving base.
0.09%
42 mg/Nm 3
114 mg/Nm 3
79%
6 kW
290°C
7.5 g/Sek
16 Pa
21 Nm3/h
Wood
2.25 kg/h
1.7 kg
4-8 kW
125 kg
135 mm
148 mm
Intermittent fuelling
