26.8.1 Aligning the mice pointers

When accessing the Target Server, the mice may appear at a distance to each other.
To align the mouse pointers:
From the Toolbar click

26.8.2 Calibrating mice pointers

A Target Server may have a different mouse pointer speed to the Client computer.
Calibrating automatically discovers the mouse speed of the Target Server and
aligns the two pointers.
To perform the calibration when the Target Server Operating system is, Windows
NT4, 2000 or 98:
From the Toolbar click
you need to calibrate the mouse twice per Target Server.
If the Video Noise Level is above zero, calibration may not work. Go to Video
Adjustment and try to eliminate the noise by pressing Auto video adjust and/or
adjusting the bars in Manual video adjust, then perform the mouse calibration.
Note! If the mouse settings on the Target Server were ever changed, you must
synchronize mouse pointers manually, as explained below.

26.8.3 Manual mouse synchronization

If the mouse settings on the Target Server were ever changed, or when the
Operating system on the Target Server is, Windows XP / 2003 Server / Vista /2008
Server, Linux, Novell, SCO UNIX or SUN Solaris you must synchronize the
mouse pointers manually.
To manually synchronize mouse pointers:
1. From the Toolbar click
appears see Figure 35.
USER GUIDE
/ Align (or press Ctrl+M). The mice align.
/ Calibrate. The KVMIP card saves the calibration so
/ Mouse Settings. The Mouse Settings box
36
