Town & Country Fireplaces TC36.RHKA Installation And Operation Instructions Manual

Optional remote kit

Advertisement

Quick Links

IMPORTANT:
THESE INSTRUCTIONS ARE TO REMAIN
WITH THE HOMEOWNER
240506-8
OPTIONAL
REMOTE KIT
REMOTE BLOWER
ASSEMBLY
HEAT OUTLET DUCT
TC36.RHKA
INSTALLATION AND
OPERATING INSTRUCTIONS
TC36.RHKA
MAKE-UP AIR INLET DUCT
5056.4277

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC36.RHKA and is the answer not in the manual?

Questions and answers

Summary of Contents for Town & Country Fireplaces TC36.RHKA

  • Page 1: Installation And Operating Instructions

    IMPORTANT: THESE INSTRUCTIONS ARE TO REMAIN WITH THE HOMEOWNER OPTIONAL REMOTE KIT REMOTE BLOWER ASSEMBLY HEAT OUTLET DUCT MAKE-UP AIR INLET DUCT TC36.RHKA INSTALLATION AND OPERATING INSTRUCTIONS 240506-8 TC36.RHKA 5056.4277...
  • Page 2: Replacement Parts

    6..BLOWER FAN BRACKET ......9146 7..BLOWER WALL BRACKET ......9147 ..REMOTE BLOWER ASSEMBLY 8..REMOTE BLOWER BOX ....TC36.9141 ..... (Items 5 to 10) ....... TC36.9141 9..BLOWER ..........5024.65 7 5/16” 15 5/16” 7 3/8” 7 3/8” 070606-8 TC36.RHKA 5056.4277...
  • Page 3: Installation Examples

    Duct clearance to combustible material: - within 36” of unit = 1/2” - more than 36” from unit = 0” MAXIMUM DUCT LENGTH OF 25 FT. ROUND DUCT (6”) RECTANGULAR DUCT (10” X 3 1/4”) MAXIMUM DUCT LENGTH OF 25 FT. 070606-8 TC36.RHKA 5056.4277...
  • Page 4: Wall Or Ceiling Installation

    2) Remove the insulation directly below the opening and remove the lower cover plate. Fig. #2 LOWER COVER PLATE (REMOVED) 4) Attach the Duct Adapter Plate to top of unit using the 4 screws previously removed. Fig. #5 INSULATION (REMOVED) 070606-8 TC36.RHKA 5056.4277...
  • Page 5 10) Run a 6” diameter duct from the adapter to the fi replace. Fasten in place with screws and seal with aluminium foil tape. MAKE-UP AIR 11) Attach fi nishing grills over both inlet and KNOCKOUT outlet using the two screws provided. PANEL 070606-8 TC36.RHKA 5056.4277...
  • Page 6: Electrical Wiring

    The junction box should be mounted (Latest Edition). in a convenient location away from the fi re- place. Fig. #10 BLOWER SPEED 115 VOLTS 60 Hz CONTROL 0.5 AMPERES G (green) L1 (white) L2 (black) 070606-8 TC36.RHKA 5056.4277...
  • Page 7: Maintenance

    Continue to rotate the knob clockwise to reduce the blower speed. To turn the blower OFF, rotate the control knob counter-clockwise until the switch clicks off. Fig. #11 CONTROL KNOB 070606-8 TC36.RHKA 5056.4277...
  • Page 8 TECHNICAL SUPPORT: 1-877-715-2664 Web site: www.townandcountryfi replaces.net 2975 Allenby Road, Duncan, BC Canada V9L 6V8 070606-8 TC36.RHKA 5056.4277...
