for architects & designers
TC36
series d
5056.9036-A_TC36D
Dimensions | Clearances | Venting
IMPORTANT
This booklet is intended as a basic specification
guide for architects, designers and builders.
Please refer to the Instruction Manual supplied
with the fireplace for detailed information regarding
installation and operation.
Product installation manuals can also be viewed at:
www.townandcountryfireplaces.com
160617-12
Advertisement
Table of Contents
Related Manuals for Town & Country Fireplaces TC36
Summary of Contents for Town & Country Fireplaces TC36
- Page 1 & designers TC36 Dimensions | Clearances | Venting series d IMPORTANT This booklet is intended as a basic specification guide for architects, designers and builders. Please refer to the Instruction Manual supplied with the fireplace for detailed information regarding installation and operation.
-
Page 2: Fireplace Dimensions
fireplace dimensions 3 5/8" 47 3/8" 26 1/16" 47 3/4" 36 1/8" 32 1/2" 32 1/2" 26 9/16 38 1/2" 26 9/16" 38 1/2" Must allow for minimum 1/2 inch gap for drywall/sheetrock and TC36D Cad Drawing Available at facing www.townandcountry replaces.com FRAMING LINTEL... -
Page 3: Mantel Clearance Chart
Mantel clearance chart coMBUstiBLe fraMing and non-coMBUstiBLe Zone. steeL fraMing finish WaLL aBoVe standoffs do not instaLL anY coMBUstiBLe MateriaL, eLectricaL Wiring or gas PLUMBing in this standoffs area. MaY Use coMBUstiBLe ManteL cLearance facing MateriaL in this area chart non-coMBUstBLe finish MateriaL * ManteL cLearance... -
Page 4: Non-Combustible Board Detail
steel stud framing Kit dimensions Kit Framing kit is supplied non-combustible with unit with Fireplace Board detail All other framing can be done with conventional lumber NON-COMBUSTIBLE BOARD 50 1/4" 12” 5 5/8” 48 1/16" NON-COMBUSTIBLE materials must extend 12” above and 5 5/8” to the sides of the framing edges. -
Page 5: Hearth Extension
Proflame 2 control system town and country d series fireplaces use the sit Proflame 2 control system. this includes an elegant hand-held, programmable, multi-function remote control transmitter with an easy to read Lcd display. the fireplace also comes with a town & countrys’ Up to 40 Feet proprietary wall-mounted control panel which allows for simple on/off operation, or can be linked with... -
Page 6: Direct Vent
direct Vent Wall installation direct Vent roof installation 14 1/2" fraMed oPening WaLL shieLd thiMBLe tcVt.thiMa 12" Vent PiPe Min. tcVt.811X12 horiZontaL eLBoW terMinaL tcVt.811XLB90 tcVt.9360 * 68 1/2 Min 24" Vent PiPe tcVt.811X24 * Minimum height from the floor to center of the opening with a maximum horizontal run of 20 1/2”... -
Page 7: Wall Termination Venting Chart
Wall termination Venting chart Pipe length Minimum rise Pipe length Maximum run Max. 68 1/2” 1-24” 20 1/2" 1-12" 72 3/4” 1-12” 1-18" 75 3/4" 1-48" 1-12" 78 3/4” 1-24" 1-12” 11' 2" 2-48" 1-24" 3-48" 1-24" 84 3/4” 1-24” 1-18" 15' 10 1/2"... -
Page 8: Roof Termination Venting Chart
roof termination Venting chart Pipe length Minimum rise Pipe length Maximum run Maximum 68 1/2” 1-24” 29" 1-12" 72 3/4” 1-12” 1-18" 75 1/4" 1-48" 1-12" 78 3/4” 1-24" 1-12” 11' 1 1/2" 2-48" 1-24" 3-48" 1-24" 84 3/4” 1-24" 1-18" 15' 10"... -
Page 9: Vent Terminal Minimum Clearances
Vent terminal clearance Minimum clearances to the vent terminal must be maintained as VENT TERMINAL MINIMUM CLEARANCES shown (See illustration to right & below). Measure clearances to TO ADJACENT STRUCTURES the nearest edge of termination hood. (See pitch table below). NOTE: Vent terminal must not be recessed NOTE: LOCAL CODES OR REGULATIONS MAY REQUIRE 36"... - Page 10 optional Power Vent reach almost any room or commercial setting. Up to 66 feet optional Power Venting allows runs up to of vertical run 110’ from an outside wall or roof surface. Vent horizontally or vertically with up to six 90-degree elbows, including runs up to 3’...
- Page 11 For reFerence only. consult Manual beFore installation 5056.9036-A_TC36D 160617-12...
- Page 12 © 2016 Copyright Pacific Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For personal service pertaining to specific projects, contact: Town & Country Architect Resource Planner architects@townandcountryfireplaces.com www.townandcountryfireplaces.com Phone: (250) 748-1184 2975 Allenby Road, Duncan, BC Canada V9L 6V8...
