Town & Country Fireplaces TC36 Installation And Operating Instructions Manual

Modular direct vent fireplace

Advertisement

INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch;
• Do not use any phone in your building.
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier call
the fire department.
Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless
a certified kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room.
250313-48
TC36.CE3 & TC36.CARE3
INSTALLATION AND

OPERATING INSTRUCTIONS

MODEL:
TC36 & TC36AR
SERIES C
MODULAR DIRECT VENT
FIREPLACE
TC36.CE3 &TC36.CARE2
SERIAL #
5056.427CE

Advertisement

Table of Contents
loading

Summary of Contents for Town & Country Fireplaces TC36

  • Page 1: Operating Instructions

    SERIAL # of this or any other appliance. WHAT TO DO IF YOU SMELL GAS • Do not try to light any appliance. • Do not touch any electrical switch; TC36.CE3 & TC36.CARE3 • Do not use any phone in your building. • Immediately call your gas supplier from INSTALLATION AND a neighbour’s phone. Follow the gas OPERATING INSTRUCTIONS supplier’s instructions.
  • Page 2: Table Of Contents

    Locating The Fireplace ..............7 Top Standoffs .................. 7 Framing and Finishing ..............8 TC36 Steel Stud Framing Kit ............10 TC36 Arched Steel Stud Framing Kit ..........12 Adjustable Lintel ................14 Hearth Extension ................15 Maestro Control ................16 Plumbing and Electrical ..............
  • Page 3: Caution

    This appliance must not be connected to a chimney flue serving a separate solid fuel burning appliance. TC36.CE3 250313-48...
  • Page 4: Important Note For The Commonwealth Of Massachusetts

    A copy of all installation instructions for all Product Approved side wall horizontally vented gas fuelled equipment, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. TC36.CE3 250313-48...
  • Page 5: Fireplace Dimensions

    Mantel support ............4 in. (102 mm) Vertical vent pipe ..........1 3/4" in. (45 mm) UNIT MAY BE RECESSED UP TO 6” WITH Horizontal Vent pipe (Top, sides and bottom) 1 3/4" in. (45 mm) NON-CUMBUSTIBLE MASONRY TYPE MATERIAL TC36.CE3 250313-48...
  • Page 6: Installation Requirements

    To ensure glass is properly latched, grasp the top left and right sides of the glass frame, under moderate pressure it should pull forward and return to original position evenly on both sides. 6. Reinstall Trim Kit if required. TC36.CE3 250313-48...
  • Page 7: Locating The Fireplace

    The minimum clearances from the fireplace to combustible surfaces must be adhered to and are shown in Fig #2 and Fig #3. Fig. #7 EXAMPLES OF COMMON LOCATIONS SEE FIG #11 FOR DIMENSIONS TC36.CE3 250313-48...
  • Page 8: Framing And Finishing

    LATION, PLASTIC VAPOR BARRIER OR GAS PLUMBING WITHIN THE STEEL STUD FRAMING ALL OTHER FRAMING CAN BE DONE WITH CONVENTIONAL LUMBER ” IT IS HIGHLY RECOMEND- ED THAT A FULL HEADER BE INSTALLED ABOVE THE METAL FRAMING KIT 48 1/8” TC36.CE3 250313-48...
  • Page 9 MINIMUM COMBUSTIBLE FRAMING DIMENSIONS 56 9/16” 20 13/16” Including Sheetrock 50 1/4” 12 11/16” 56 9/16” 23 3/8” 48 1/4” 29 3/8” 50 1/4” 79 15/16” 3/4” 50 1/4” NOTE: FIREPLACE SHOULD BE IN ITS FINAL LOCATION BEFORE FRAMING. TC36.CE3 250313-48...
  • Page 10: Tc36 Steel Stud Framing Kit

    TC36 Steel Stud Framing Kit TC36.B2FRKITA Each Kit Contains: Item Part # Description Qty. 5049.9912 SCREW, TEKS #8 x 1/2” 9794.2 STUD, SIDES, 48”L 9794.5 STUD, OUTER SIDES, 48”L 9093.22 STUD, CENTER, 15 7/16”L 9193.501 STUD, HEADER, 49 7/8”L 9393.001 STUD, PLATE, 41 1/4”L...
  • Page 11 Secure the frame assembly to existing Brackets framing through the stud header (5) and the stud plates (7). Access holes to mounting screws Fig. #15 5. Install Non-combustible Board • Use drywall screws to install the non-combustible board (Fig #15). TC36.CE3 250313-48...
  • Page 12: Tc36 Arched Steel Stud Framing Kit

    TC36 Arched Steel Stud Framing Kit TC36.BRFRKITA Each Kit Contains: Item Part # Description Qty. 5049.9912 SCREW, TEKS #8 x 1/2” 9794.2 STUD, SIDES, 48”L 9794.5 STUD, OUTER SIDES, 48”L 9093.22 STUD, CENTER, 15 7/16”L 9193.501 STUD, HEADER, 49 7/8”L 9393.001...
  • Page 13 Secure the frame assembly to existing Brackets framing through the stud header (5) and the stud plates (7). Access holes to mounting screws Fig. #22 5. Install Non-combustible Board • Use drywall screws to install the non-combustible board (Fig #22). TC36.CE3 250313-48...
  • Page 14: Adjustable Lintel

    5. The lintel assembly can then be adjusted to align flush with your facing material by sliding in or out approximately 1” . 6. Tighten the securing bolts. (Fig.#23). Re-attach the window trim. TRIM Fig. #18 SECURING BOLT TC36.CE3 250313-48...
  • Page 15: Hearth Extension

    FRAMING with trim fitted, must be able to move EDGES freely. No building material is permitted to protrude past the framing edges GLASS attached to the fireplace under ANY FRAME circumstance. NON COMBUSTIBLE FINISH MATERIAL TC36.CE3 250313-48...
  • Page 16: Maestro Control

    Attach the electrical box for the supplied wall control to the framing in the desired location (up to 50 ft. away). (25 ft is supplied with fireplace. An additional 25 ft can be achieved by using the optional kit (Part # 5005.064) available from your distributor). TC36.CE3 250313-48...
  • Page 17: Standing Pilot Function

    (Fig #33) This should be depressed with a paperclip, pencil or other thin object. Once activated the pilot will run continuously. Please check with your local inspector to ensure that this is permitted in your area. LEARN BUTTON STANDING PILOT BUTTON TC36.CE3 250313-48...
  • Page 18 WILL NOT begin until the 10 second pre-purge delay is complete. • Upon receiving any ON command, the green LED will flash (0.5 seconds ON, 0.5 seconds OFF) for 10 seconds so the user will know that the fireplace is operating. TC36.CE3 250313-48...
  • Page 19: Gas Supply

    Please refer to the Burner Installation Manual for gas pressure testing procedure. Correct gas pressure requirement: Natural Gas Propane Min. Pressure 5.0" WC 12.5" WC (For purpose of input adjustment) Max. Pressure 13.9" WC 13.9" WC Manifold Pressure Maximum 3.8" WC 11" WC Minimum 2.1" WC 5.5" WC TC36.CE3 250313-48...
  • Page 20: Venting

    The rise and run must be constrained to the boundaries of the chart shown in Fig. #35. The horizontal run of vent must have a 1/4" rise for every 1 ft. of run towards the termination. TC36.CE3 250313-48...
  • Page 21 Wall/Offset Support ..........TCVT.811XOS Wall Termination Kit ..........TCVT.WTA Roof Termination Kit ..........TCVT.RTA Wall Shield/Ceiling Firestop ........TCVT.THIMA Roof Flashing, Adjustable ........TCVT.811FLADJ Roof Flashing, Flat ..........TCVT.811FLFLT Roof Flashing, Steep ..........TCVT.811FLSTP or any flashing that fits 11" pipe TC36.CE3 250313-48...
  • Page 22: Wall Vent Terminal

    * Minimum height from the floor to center of the opening with a maximum horizontal run of 18" from the center of the flue outlet to the outside face of the outer wall. The height will need to be increased if a longer horizontal pipe is required. TC36.CE3 250313-48...
  • Page 23: Wall Termination Venting Chart

    * 68 1/2” combination of other elbows equalling 90° can be used without reducing horizontal run. For each additional 90° elbow, or an equal combination of elbows, reduce horizontal vent run by 2 feet. Ensure vent pipe is properly supported. TC36.CE3 250313-48...
  • Page 24: Roof Termination Venting Chart

    A total of 4 - 90° elbows or combination of other elbows equalling 90° can be used without reducing horizontal run. For each additional 90° elbow, or an equal combination of elbows, reduce horizontal vent run by 2 feet. Ensure vent pipe is properly supported. TC36.CE3 250313-48...
  • Page 25 Rotate the 90° brackets to accom- modate roof pitch. Attach the brackets to the roof joists with nails or building screws. Tighten the band around the vent pipe and secure in place with screws. ROOF SUPPORT BRACKET (TCVT.93915) TC36.CE3 250313-48...
  • Page 26: Roof Vent Terminal

    (Fig #43). Seal screw heads and joints with caulking to prevent any moisture entering the venting system. Fig. #43 VERTICAL TERMINATION CAP (TCVT.9365) VENT PIPE MASTIC STORM COLLAR (TC42.90665) FLASHING NOTE: ADJUSTABLE FOR VARIOUS ROOF PITCHES, FROM FLAT ROOF TO 12/12 PITCH ROOF. TC36.CE3 250313-48...
  • Page 27: Vent Terminal Clearance

    ** only permitted if veranda, porch, deck, or balcony is fully open on a minimum of 2 sides beneath the floor* * as specified in CGA B149 Installation Codes, Note: local Codes or Regulation may require different clearances * for U.S.A. Installations follow the current National Fuel Gas Code, ANSI Z223.1 TC36.CE3 250313-48...
  • Page 28: Vent Pipe Sealant

    Insulated Collar Shield (Included) After sealing the vent pipe an insulating blanket and cover (Pt# TC36.9709 included) must be installed around the vent pipe, flush with the top of the unit and secured by fitting tabs through slots and bending over tabs 180° as shown in Fig. #60. The parts required are included.
  • Page 29: Vent Restrictor Adjustment

    • Flame soots. Restrictor position is too open if the flame has the following characteristics: • Flame height is low. • Flame has excessive movement. 3" OPEN To adjust the restrictor: FULLY OPEN • Loosen the screw holding the restrictor. • Move the restrictor to its intended opening. • Re-tighten the screw 18" Fig. #43a OPENING VENT RESTRICTOR TC36.CE3 250313-48...
  • Page 30: Firebox Panels Installation

    Firebox Panels Installation PARK AVE. BEIGE HERRINGBONE ..........TCPN.36PAC(TC36) ..................TCPN.36ARPAC(TC36 ARCH) TC36 & TC36 ARCH MOUNT VERNON RED HERRINGBONE ........TCPN.36VRC(TC36) PANELS ..................TCPN.36ARVRC(TC36 ARCH) MANHATTAN BEIGE STACKED BRICK ........TCPN.36MNC(TC36) ..................TCPN.36ARMNC(TC36 ARCH) BLACK PORCELAIN ..............TCPN.757031.C(TC36) ....................TCPN.75702.C(TC36 ARCH) COFFEE BEAN BROWN PORCELAIN ........TCPN.757031CB.C(TC36)
  • Page 31: Finishing Touch Trim Kit Instructions

    2. Place two larger magnets on back of the top and bottom rails. 3. Attach the side rails. Even the ends up with the door frame. 4. Attach the top and bottom rails and adjust so mitres are even at the corners. TC36.CE3 250313-48...
  • Page 32: Lighting Instructions

    It is normal for fireplaces fabricated of steel to give off some expansion and/or contraction noises during the start up or cool down cycle. Similar noises are found with your furnace heat exchanger or cook stove oven. TC36.CE3 250313-48...
  • Page 33: Maestro Control System

    4. Use the up and down arrows to set the “hour” value. 5. Press OK and the “minute” value will flash. 6. Use the up and down arrows to set the “minute” value. HOUR: Press OK and the “day” value will flash. HOLD A2 HOLD A1 TC36.CE3 250313-48...
  • Page 34: Maestro Control System - Operation

    3. Press the OK button and the timer is set and the control is in countdown timer mode. 4. To exit the timer mode press the Program, Manual or Thermostat buttons. Please note that the first press of the Manual button will turn the fireplace off. TC36.CE3 250313-48...
  • Page 35 To switch out of program mode, simply press one of the manual, timer or thermostat mode buttons. Please note that if the manual button is pressed it will turn the fireplace off. TC36.CE3 250313-48...
  • Page 36 5 seconds and then set itself to the temperature displayed. 5. The fireplace is now in thermostatic mode. To exit the thermostatic mode press the program, manual or timer buttons. Please note that the first press of the manual button will turn the fireplace off. TC36.CE3 250313-48...
  • Page 37: Maintenance

    Viewing glass may be cleaned as necessary with fireplace glass cleaner. b) Exterior finish may be cleaned with mild soap and water. CAUTION: Do not use abrasive cleaners on glass or any other part of the fireplace. Do not clean glass when hot. TC36.CE3 250313-48...
  • Page 38: Tc36.Ce3 Replacement Parts

    ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. PANEL SETS TC36 BODY ASSM......TC36.CE PARK AVE. BEIGE HERRINGBONE ....TCPN.36PAC MT.VERNON RED HERRINGBONE ....TCPN.36VRC GLASS ASSM........GLAS.2087ASSY MANHATTAN BEIGE STACKED BRICK ....TCPN.36MNC BLACK PORCELAIN .........TCPN.757031.C FRAMIMG KIT ........TC36.BFRKITA CB BROWN PORCELAIN .........TCPN.757031CB.C...
  • Page 39: Tc36.Care3 Replacement Parts

    (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. TC36 ARCH BODY ASSM....TC36.CARE PANEL SETS PARK AVE. BEIGE HERRINGBONE ....TCPN.36ARPAC MT.VERNON RED HERRINGBONE ....TCPN.36ARVRC GLASS ASSM........GLAS.2088ASSY MANHATTAN BEIGE STACKED BRICK ....TCPN.36ARMNC BLACK PORCELAIN .........TCPN.75702.C FRAMING KIT........TC36.BAR2FRKITA...
  • Page 40: Replacement Parts - Maestro Control System

    WING NUTS (2) 1m TC30 MINIMUM RATE SCREW, NG #4..WALL SWITCH ASSSEMBLY KIT INLET PLATE BATTERY HOLDER INLET PLATE GASKET WALL SWITCH COVER PLATE ELEC BULKHEAD GASKET WALL SWITCH 1/2" BULKHEAD FITTING 1/4" BULKHEAD FITTING ELEC BULKHEAD FITTING TC36.CE3 250313-48...
  • Page 41: Wiring Diagram

    Wiring Diagram Fig. #69 TC36.CE3 250313-48...
  • Page 42: Wall Termination Kit

    TERMINAL 16 1/2" TCVT.9360 16 1/2" WALLSHIELD/CEILING FIRESTOP THIMBLE TCVT.THIMA 9 5/8" Roof Termination Kit TCVT.RTA Fig. #72 16 1/2" VERTICAL TERMINATION CAP TCVT.9365 9" STORM COLLAR TC42.90665 WALL SHIELD / CEILING FIRESTOP ROOF SUPPORT TCVT.THIMA BRACKET TCVT.93915 TC36.CE3 250313-48...
  • Page 43: Vent Pipe Dimensions

    18" PIPE ..16 1/4" 24" PIPE ..22 1/4" 48" PIPE ..46 1/4" 10 15/16" 9 1/2" TCVT.811X12ADJ 11 1/8" TCVT.811X _ _ 13 13/16" 12 9/16" 8 5/16" 1 5/16" 13 1/8" 7/16" 10 5/16" TCVT.811XLB45 15 7/8" TCVT.811XLB90 TC36.CE3 250313-48...
  • Page 44: Vent Offset Chart

    BY 2 1/8" TO 6 3/4" 1 1/4” 20” 20" 1 1/4“ 1 1/4” 18 3/4" 12" PIPE 29" ADDING AN ADJUSTABLE SECTION 18" PIPE 35" TO PIPE WILL INCREASE OFFSET 24" PIPE 41" BY 3" TO 9 1/2" 48" PIPE 65" TC36.CE3 250313-48...
  • Page 45: Light Replacement

    Use latex gloves or paper towel to remove bulb and replace. 5. Replace cover and secure with screw previously removed. Fig. #76 GREEN GREEN TERMINAL TERMINAL BLOCK BLOCK (FLOOR LIGHTS) (UPPER LIGHTS) GLASS COVER GROUND GROUND WALL WALL SWITCH SWITCH TC36.CE3 250313-48...
  • Page 46 Notes TC36.CE3 250313-48...
  • Page 47: Safety Label Location

    AVERTISSEMENT: Une installation, un réglage, une modifi cation, une réparation ou un entretien mal effectué peut causer des dommages matériels ou des blessures. Voir la notice de l’utilisateur qui accompgne l’appareil. Pour de l’aide ou des renseignements supplémentaires, consultez un installateur, un technicien agréé ou le fournisseur de gaz. 291012 5050.7205.CE3 1-TC36-C TC36.CE3 250313-48...
  • Page 48 Technical support: 1-250-748-1184 Web site: www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
